Coaxial loudSpeaker Manual
Manuel de Coaxial
Features:
Models: RX4CX, RX46CX, RX5CX RX57CX, RX65CX, RX69CX
• -Advancedlaminatingprocessproducesexcellentstinesstoweightratio,superiordampingqualitiesLAMINATE-TREATED PAPER CONE
• -Excellentreproductionofhighfrequencies19mm BALANCED DRIVE MYLAR TWEETER
• -Hightemperaturelight-weightvoicecoilstructureforincreasedsensitivityPOLYMIDE VOICE COIL FORMER
• -PremiumdesignforexcellentsensitivityandlongtermreliabilityTRIPLE-LAYER UV TREATED FOAM SURROUND
• RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment
Coaxial Speaker Owner’s Manual
© 2013 Phoenix Gold • www.phoenixgold.com
RX4CX RX46CX RX5CX RX57CX RX65CX RX69CX
RMSPowerHandling(watts) 40W 40W 40W 50W 50W 60W
PeakPowerHandling(watts) 80W 80W 80W 100W 100W 120W
Impedance(ohms) 4 4 4 4 4 4
CutOutDimension(mm)/in. (93)3.7 (143X88)5.6X3.5 (120)4.75 (188X131)7.4X5.2 (144)5.7 (221X154)8.7X6.1
MountingDepth(mm)/in. (50)2.0 (51.5)2.1 (55)2.2 (71)2.8 (64)2.5 (76)3.0
BASIC INSTALLATION
SelectingtheplacementofyournewRXCoaxialspeakerscouldbeaseasyas
usingtheexistingfactorylocationsormayrequireyoutocreateanewlocation.
Speakerplacementinthedoor,dash,orreardeckisthemostcommon.See
yourlocalPhoenixGoldDealerforadditionallocationandmountingassistance.
DOORS/REARDECK
1.Manyvehiclesalreadyhavefactorylocations(Figure1)tohousethe“DROP
IN”featureoftheRXCoaxialspeakers.Ifnoexistinglocationsareavailable
orarenotused,checkthedesiredlocationforadequatecutoutareaand
anydepthobstructions.Makesuretoallowsucientclearanceforwindow
tracks,structuralbraces,trunklidsprings,etc.
2.Assumingenoughareaanddepthisavailable,usetheprovidedtemplate
andtracethespeakercutoutandmountingholesontothesurfaceofthe
mountinglocation.
3.Ifthemountingsurfaceisnotstructurallystrongenoughtoaccommodate
screws,(i.e.plastic,cardboard)usetheprovidedspeedclipswhichwillact
asanutforthesuppliedscrews.
4.Alwaysprovidewaterprotection,ifnotsuppliedinthevehicle.Wesuggest
usingarainshieldorequivalent.Ifindoubt,pleasecontactyour
PhoenixGoldDealer.
SPEAKERINSTALLATIONWITHOUTGRILL
PhoenixGoldhasprovidedafoammountinggasket.Wheninstallingyour
newcomponentspeakersinafactorylocationmakesuretousethefoam
mountinggasketasshowningure1.Forreversemountedspeakersplacethe
foamgasketinfrontofthespeaker.ThiswillensureanairtightsealforyourR
speakers.
Formorecustomapplications,orcaseswherethefactorygrillwillnotbeused,
ahighexcursionprotectivegrillhasbeenprovided.Wheninstallingyournew
componentspeakerswiththeprovidedRXgrillusegure2.
SPECIFICATIONS: Duetocontinualproductimprovement,allspecicationssubjecttochangewithoutnotice.
Figure 1
Mountingthespeakerinafactorylocation.
Figure 2
Mountingthespeakerinacustomapplication.
© 2013 Phoenix Gold • www.phoenixgold.com
Coaxial Speaker Owner’s Manual
INSTALLATION DE BASE
Lasélectiondel’emplacementdevosnouveauxhaut-parleurscoaxiauxRX
peutêtreaussifacilequel’utilisationdesemplacementsdefabrication
oupeutnécessiterlacréationd’unnouvelemplacement.L’emplacementle
pluscourantestdanslesportes,letableaudebordouàl’arrièredupont.
ConsultezvotreconcessionnairePhoenixGoldpourunemplacementde
montagesupplémentaireetdel’assistance.
INSTALLATIONDESHAUT-PARLEURSPORTES/PLAGE
ARRIÈRE
1.Denombreuxvéhiculesontdéjàdesemplacementsd’usine(Figure1)
pourlafonctionnalité“DROPIN”delalignecoaxialRX.Siaucundes
emplacementsexistantsn’estdisponibleous’ilsnesontpasutilisés,
vérierl’emplacementdésirépourladécoupeadéquateetdesobstaclesen
profondeur.Assurez-vousdelaissersusammentdedégagementpourles
pistesdelafenêtre,lesferruresstructurales,l’amortisseurarrière,etc
2.Ensupposantqu’ilyasusammentdesurfaceetdeprofondeur,utiliser
lemodèlefournietretracerladécoupeduhaut-parleuretlestrousde
montage sur la surface de l’emplacement de montage
3.Silasurfacedemontagen’apasunestructuresusammentsolidepour
accueillirlesvis,(parex.plastique,carton)utiliserlesclipsrapidesfournis
quiservirontd’écrouspourlesvisfournies
4.Toujoursassurerlaprotectionpourl’eau,siellen’estpasfourniedans
levéhicule.Nousvoussuggéronsd’utiliserunehoussedepluieou
l’équivalent.Encasdedoute,veuillezcontactervotrerevendeurPhoenix
Gold.
INSTALLATION DU HAUT PARLEUR SANS GRILLES
PhoenixGoldafourniunjointstatiquedemontageenmousse.Lorsde
l’installationdevosnouveauxhaut-parleurscoaxiauxdansuneusine,
assurez-vousd’utiliserlesjointsstatiquesdemontageenmoussecommele
montrelagure1.Pourleshaut-parleursmontésàl’envers,placezlejointen
mousseenfaceduhaut-parleur.Ceciassureraunjointétancheàl’airpour
voshaut-parleursRX.
INSTALLATION DU HAUT PARLEUR AVEC GRILLES
Pour plus d’applications sur mesure, ou des cas où la grille d’usine n’est pas
utilisée,unegrilledeprotectiondehautedéviationaétéfournie.Assurez-
vousd’utiliserlejointencaoutchoucand’obtenirunjointétancheàl’air.
Lorsdel’installationdevosnouveauxhaut-parleurscoaxiauxaveclagrilleRX
fournie,utilisezlagure2.
NB:Lesspécicationssontsujettesàchangersanspréavisenraisonde
l’améliorationcontinuelleduproduit.
Figure 1
Figure 2
Pour Les Modele: RX4CX, RX46CX, RX5CX, RX57CX, RX65CX, RX69CX
