B A S S C U B E 2 . 0
U s e r M a n u a l
BASS CUBE 2.0
USER MANUAL
CONSTANT USABLE BASS ENHANCEMENT For bassheads that
believe life begins below 80Hz. Bass Cube 2.0 will give your system
the extra boost of clean, articulate bass you crave. Bass Cube
features the precision tuning that allows you to dial in your bass to
perfection.
BASS CUBE 2.0
//////////
SPECIFICATIONS
- Parametric Bass Equalization
- Variable Center Frequency Control
- Selectable Ground Isolation Switch
- 2 Channel Digital Bass Restoration
- Selectable Balanced / Unbalanced
- RCA Input and Output
- Variable Output Gain Control
- Selectable Output Gain Limiter
- Remote Bass Control
- Selectable Sub-Sonic Filter
FEATURES:
10HZ - 25KHZ;
+/- 1DB
12V rms
9V peak
0.002%
127dB
1 Amp
Maximum Input Level
Total Harmonic Distortion
Maximum Output Level
Frequency Response
Signal to Noise Ratio
Fuse Rating
1. REM / 12V / GND:
Connects to a 12V+ switched source.
Connects to a 12V constant source. (1 amp in-line fuse is required)
D: Connects to a chassis ground.
UND ISOLATION: Alternator whine may appear in the system because the
unit and amplifier may use different grounds. To help in this situation, we ha
ed alternative grounding options. TURN THE SYSTEM OFF BEFORE SWITCHING
NORMAL SELECTION.
PUT GAIN CONTROL: Control the amount of signal you are sending through t
UTPUTS to your amplifier(s). It is important to note that the Bass Cube 2.0 has
line driver capable of sending 9 volts of signal output to your amplifier(s). Be
sure to reference the amplifier gain control.
4. CENTER FREQUENCY: Select the frequency you want the Bass Cube 2.0 bass
restoration circuit to enhance.
5 FREQUENCY BANDWIDTH: Adjust the range of frequencies from your center poin.
All the way to the left will include the maximum frequencies to enhance, while all t
way to the right will enhance only a limited amount of frequencies near your CENT
FREQUENCY.
6 RCA INPUT: For RCA cables, 99.99999% of the time you will select UNBALANCED.
*In rare occasions some processors or ultra high end head-units will have balanced
outputs. If you have one of these, you’re a big baller and you get to select BAL-
ANCED
7 INPUT: RCA's from source unit.
8. OUTPUT: RCA's from the Bass Cube 2.0 connect to the inputs of your amplifier(s).
9 REMOTE: The Bass Cube 2.0 Digital Bass Enhancer dash mount control connects .
here. This remote allows for complete control of your audible subwoofer level alon
with a LED indicator which brightens as you increase bass enhancement.
BASS CUBE 2.0 USER MANUAL
