PCE-IT100 Insulation Tester

User Manual

User manuals in various languages (français,

italiano, español, português, nederlands, türk, polski,

русский, 中文

中文

中文中文) can be found by using our

product search on: www.pce-instruments.com

Last change: 7 October 2019

v1.0

English

Contents

1 Safety notes ........................................................................................... 1

1.1 Safety symbols ................................................................................................................. 2

1.2 Safety categories 3 .............................................................................................................

2 Delivery contents .................................................................................. 4

3 Specications ........................................................................................ 4

4 Device description ................................................................................ 7

5 Turn on meter ........................................................................................ 8

6 Connect the test leads .......................................................................... 8

6.1 Set zero point ................................................................................................................... 8

7 Insulation measurement ....................................................................... 8

7.1 Measuring AC motors ....................................................................................................... 8

7.2 Measuring DC motors ...................................................................................................... 8

7.3 Measuring insulated cables .............................................................................................. 8

8 Continuity test/resistance measurement 9 ...........................................

9 Voltage measurement AC/DC .............................................................. 9

10 Automatic Power O function ............................................................. 9

11 Keys ........................................................................................................ 9

11.1 Hold reading ..................................................................................................................... 9

11.2 MAX/MIN 9 ..........................................................................................................................

11.3 Freehand measurement (LOCK key) ................................................................................ 9

12 Backlight .............................................................................................. 10

13 Replace the batteries .......................................................................... 10

14 Replace the fuse .................................................................................. 10

15 Warranty ............................................................................................... 10

16 Disposal ............................................................................................... 10

1 Safety notes

Please read this manual carefully and completely before you use the device for the rst time. The

device may only be used by qualied personnel and repaired by PCE Instruments personnel.

Damage or injuries caused by non-observance of the manual are excluded from our liability and

not covered by our warranty.

• The device must only be used as described in this instruction manual. If used otherwise,

this can cause ngerous situations for the user and damage to the meter. da

• The instrument may only be used if the environmental conditions (temperature, relative

humidity, …) are within the ranges stated in the technical specifications. Do not expose

the device to extreme temperatures, direct sunlight, extreme humidity or moisture.

• Do not expose the device to shocks or strong vibrations.

• The case should only be opened by qualied PCE Instruments personnel.

• Never use the instrument when your hands are wet.

• You must not mak any technical changes to the device. e

• The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,

no abrasives or solvents.

• The device must only be used with accessories from PCE Instruments or equivalent.

• Before each use, inspect the case for visible damage. If any damage is visible, do not

use the device.

• Do not use the instrument in explosive atmospheres.

• The measurement range as stated in the specications must not be exceeded under

any circumstances.

• Non-observance of the saf y notes can cause damage to the device and injuries to et

the user.

• Remove the batteries when the meter is not used for more than 60 days.

• Turn o the meter when not in use.

Do not use the full measurement range.

• Set your meter before connecting the test l ds. ea

• Before replacing the batteries or the fuse, turn o the meter and remove the test leads.

• Be particularly careful with voltages over 30V AC RMS, 42 V AC peak or 60V DC to

avoid electric shocks.

• Make sure the test object does not carry any voltage when making a resistance or diode

test.

• Do not touch the measuring tips.

• Always use personal protective equipment when measuring live wires to avoid an

electric arc.

• Do not use the meter when it no longer works awlessly.

We do not assume liability for printing errors or any other mistakes in this manual.

We expressly point to our general guarantee terms which can be found in our general terms of

business.

If you have any questions please contact PCE Instruments. The contact details can be found at

the end of this manual.
