1. TRUE BYPASS Footswitch:
Push down the footswitch to toggle
between on and bypass status.
2. ON/OFF LED:
Shows the on/off status of Blues
Mood, when the LED is lit the
effect is engaged.
3. DC IN Power Jack:
For power supply, use a 9-volt
DC regulated AC adapter (plug
polarity is positive on the barrel
and negative in the center).
4. INPUT Jack:
1/4 mono audio jack, for
connecting guitar.
5. OUTPUT Jack:
1/4 mono audio jack, outputs
the signal.
Very small and compact design
True bypass switch
DC 9V adapter power supply
PLEASE READ CAREFULLY BEFORE PROCEEDING
Power Supply
Connections
Always turn off the power of this and all other equipment before connecting or
disconnecting, this will help prevent malfunction and / or damage to other devices.
Also make sure to disconnect all connection cables and the power cord before
moving this unit.
Cleaning
Clean only with a soft, dry cloth. If necessary, slightly moisten the cloth.
Do not use abrasive cleanser, cleaning alcohol, paint thinners, wax, solvents,
cleaning fluids, or chemical-impregnated wiping cloths.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception interference.
Operate this unit at a suitable distance from radios and televisions.
Location
To avoid deformation, discoloration, or other serious damage, do not expose
this unit to the following conditions:
Direct sunlight Heat sources
Magnetic fields Extreme temperature or humidity
Excessive dusty or dirty location High humidity or moisture
Strong vibrations or shocks
Please connect the designated AC adapter to an AC outlet of the correct voltage.
Please be sure to use only an AC adapter which supplies 9V (±10%) DC, center
minus. The maximum working voltage shall not exceed 12V, otherwise may be
dangerous equipment damage, fire or other problems.
Unplug the AC power adapter when not using or during electrical storms.
Precautions
FCC certification
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
Power Requirements: AC adapter 9V DC (center minus plug),
recommended to use Mooer Micro Power
Wide range frequency response blues style overdrive sound, also
sounds good on bass
2 Working Modes: Bright/Fat
Full metal shell
Main Features
6. Mode Switch:
7. LEVEL Knob: Adjusts the output level.
8. TONE Knob: Adjusts the brightness of tone.
9. GAIN Knob: Adjusts the gain.
Switch between Bright mode and
Fat mode.
GAIN
TONE
4
5
9
3
6
87
Working Mode: 2 (Bright/Fat)
Input: 1/4 monaural jack (impedance: 1M Ohms)
Output: 1/4 monaural jack (impedance: 1k Ohms)
Current Draw: 14 mA
Dimensions: 93.5mm (D) 42mm (W) × × 52mm (H)
Weight: 160g
Accessories: Owner’s Manual
* Disclaimer: Any specification’s update won't be amended in this manual.
Bright: Transparent tube-like overdrive tone.
Fat: Add a bit of natural low end to get a rich and vigorous sound.
Blues Drive Pedal
