Operations Guide
CONNECT - REGISTER - WIN
Register your product online so we can notify you about the latest option parts, product
updates, tech tips, service bulletins and more. Visit WWW.LOSI.COM and follow the
Product Registration link to stay connected.
For registering your Losi Product you will be automatically entered for a chance to win
the Losi Pick Your Prize Sweepstakes. The winner will be allowed to select a total prize
package of $1,000 (retail value) based on his/her preference.
Introduction
Thank you for choosing the Micro Rock Crawler from Losi. This guide contains the basic instruc-
tions for operating your new Micro Rock Crawler. While the Micro Rock Crawler is great for rst-
time RC drivers, it does require some mechanical experience. It is critical that you read all of the
instructions and all accompanying printed material in order to operate your model correctly and
avoid unnecessary damage. Please take a moment to look them over before running your model.
© 2009 Losi, A Division of Horizon Hobby, Inc.
Warning
Although the best materials and components are used, and due to the size of this model, using anything other
than genuine Losi replacement and performance parts specically designed for the Losi Micro Rock Crawler could
cause damage.
2
1. Your Losi Micro Rock Crawler includes 2 complete
sets of batteries. The heavy-duty non-alkaline batter-
ies are for the transmitter.
2. Remove the battery cover by sliding it in the
direction noted on the cover. Install (8) AA alkaline
batteries into the bottom of the charger. Pay close
attention to the correct direction of the positive
(+) and negative(-) ends as marked. Reinstall the
battery cover.
3. Plug the battery lead into the charger lead. The
RED LED on the charger will light up and stay solid
while charging. When the battery is fully charged the
light will shut off (approximately 20 minutes). If the
charger light only lights up for about a minute, the AA
batteries inside the charger are low and should be
replaced.
4. Remove the transmitter battery cover by sliding it
in the direction noted on the cover. Install four (4) AA
batteries into the battery holder. Pay close attention to
the correct direction of the positive (+) and negative
(-) ends as marked. Once all 4 batteries have been
installed, reinstall the battery cover.
5. Plug in the battery lead into the speed controller
lead and replace the body. Secure the body with the
included body clips.
6. ALWAYS turn on the transmitter rst by sliding the
switch “ON”. The small red and green lights above the
switch should both light up. If not, please check for
low or incorrectly installed batteries.
7. Once the transmitter has been turned on, turn on the Losi Micro Rock Crawler by sliding the switch to the
“On” position (located at the rear of the chassis). If the wheels spin, adjust the “TH. Trim” knob located to
the lower right of the steering wheel until they stop. To go forward pull the trigger back. If you should need to
reverse, wait for the model to stop then push the trigger forward. When going forward the model should move
in a straight line. If not, adjust the “ST.Trim” so that it tracks in a straight line without having to turn the steer-
ing wheel. After you are nished running, turn the Losi Micro Rock Crawler off FIRST by sliding the switch to
the “Off” position. After the model has been turned off, turn off the transmitter.
RTR Getting Started
Charger
3
Charger
1. Your Losi Micro Rock Crawler includes a complete
set of batteries for the portable charger. 2. Remove the battery cover by sliding it in the
direction noted on the cover. Install (8) AA alkaline
batteries into the bottom of the charger. Pay close
attention to the correct direction of the positive
(+) and negative(-) ends as marked. Reinstall the
battery cover.
3. Plug the battery lead into the charger lead. The
RED LED will light up and stay solid while charging.
When the battery is fully charged the light will shut off
(approximately 20 minutes). If the charger light only
lights up for about a minute, the AA batteries inside
the charger are low and should be replaced. 4. Plug in the battery lead into the speed controller
lead and replace the body.
5. While pressing the white “Bind” button, slide the
switch to the “On” position. When the green LED
begins to ash rapidily release the bind button.
6. Switch on the transmitter and you should notice
a blinking LED on the back of the transmitter with a
translucent cover (MTX-Pro or LSR-3000). NOTE:
If using other Spektrum transmitters, please consult
your instruction manual for help with this process.
7. Once the transmitter has been bound with the Micro Rock Crawler on, if the wheels spin, adjust the “TH.
Trim” on your transmitter until they stop. To go forward pull the trigger back. If you should need to reverse,
push the trigger forward. When going forward the model should move in a straight line. If not, adjust the “ST.
Trim” so that it tracks in a straight line without having to turn the steering wheel. After you are nished run-
ning, turn the Losi Micro Rock Crawler off FIRST by sliding the switch to the “Off” position. After the model
has been turned off, turn off the transmitter.
Spektrum DX2, DX3 and radios equipped with Spektrum modules
are also compatible with Bind-N-Drive
Getting Started
