Gracias por comprar una Secadora LG.

Por favor lea su manual correctamente, p1-ya que contiene

informaciòn importante de una instalaciòn segura, Uso y

mantenimiento. Guarde el modelo y nùmero de serie y

conserve su manual para futuras referencias.

TD-V10050E/TD-V10050G

TD-V10055E/TD-V10055G

TD-V10051E/TD-V10051G

TD-V12055E/ TD-V12055G

TD-V12056E/ TD-V12056G

TD-V14056E/TD-V14056G

Thank you for buying a LG Dryer.

Please read your manual carefully,as it provides

instructions on safe Installation,Use and Maintenance.

Record the Model and Serial Numbers,and retain the

manual for future reference.

P/No.: 3828EL3003F

TD-V10050E/TD-V10050G

TD-V10055E/TD-V10055G

TD-V10051E/TD-V10051G

TD-V12055E/ TD-V12055G

TD-V12056E/ TD-V12056G

TD-V14056E/TD-V14056G

PRODUCT FEATURES

TABLE OF CONTENTS

PART1. SPECIFICATIONS .....................................................................................................................................3

PART2. IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS .................................................................4-6

PART3.INITIAL STEPS FOR INSTALLING YOUR DRYER .............................................................................7-12

PART4.ACCESSORIES INSTALLATION .......................................................................................................13-14

PART5. ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYER ...............................................................15-18

PART6. ELECTRICAL REQUIREMENTS FOR GAS DRYERS ............................................................................19

PART7. GAS REQUIREMENTS AND INSTRUCTIONS........................................................................................20

PART8. EXHAUST REQUIREMENTS AND MAINTENANCE..........................................................................21-22

PART9. OPERATING YOUR DRYER...............................................................................................................23-28

PART10. TROUBLESHOOTING GUIDE ..........................................................................................................29-31

OUTSTANDING PERFORMANCE

Not to mention unmatched big capacity, you can benefit from good

time efficiency, quiet operation and energy saving system.

STAINLESS STEEL DRUM

The Drum is coated with both a metal and a polymer coating in order to guarantee high

durability and long life.

ARTISTIC DESIGN

Modern front panel look and big crystal-clear glass door make your house look stylish.

DIGITAL FABRIC CARE

Multi-Level temperature control takes better care of your clothes

EASY OF USE

An entire selection of user-friendly functions make operating the dryer easy.

Part 1 SPECIFICATIONS

■Name : Electric and Gas Dryer

■Power supply : Please refer to the rating label regarding detailed

information.

■Size : 27 x 29.9 x 38.7 (inch)

■Dryer capacity : Refer to Rating Label

■Weight : 126(Ibs)

Specifications are subject to change by manufacturer.

■ ACCESSORIES

Dryer rack (1 each)

See page 26 for how to use. See page 13 for how to use. See page 14 for how to use.

Stacking kit (1 each)

Purchased Separately

Pedestal (1 each)

Purchased Separately

Part 2

IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

SEEKING WARRANTY ASSISTANCE

WARNING!

For your safety, the recommendations in this manual must be followed. To reduce the risk

of fire or explosion, electric shock, or to prevent property damage, personal injury, or

death when using your appliance, follow basic precautions, including the following.

The Warranty for your Dryer is located at the end of this manual.Warranty Service is available by

contacting your nearest LG Service Center. If this product is installed and operated per this manual,

LG will repair or replace any parts defective in material or workmanship throughout the Warranty

period, beginning the Date of Purchase.

Warranty Restriction: If the dryer is subjected to other than private family use, all warranty

coverage is effective for only 90 days.

You will need the complete Model and Serial Number when requesting Warranty Service.

Proof of purchase date is required.

Use the space below to record the model number and serial number of your new LG dryer.

Model No.

Serial No.

Date of Purchase

❈ Staple your receipt HERE.

Part 2 IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

1) Read all instructions before using the appliance.

2) Do not dry articles that have come into contact with

gasoline, dry-cleaning solvents, or other flammable

or explosive substances, as they give off vapors that

could ignite or explode.

3) Do not allow children to play on or in the appliance.

Close supervision of children is necessary when

using the appliance.

4) Before the appliance is removed from service or

discarded, remove the door to the drying

compartment.

5) Do not reach into the appliance if the drum is

moving.

6) Do not install or store this appliance where it will be

exposed to the weather.

7) Do not tamper with controls.

8) Do not repair or replace any part of the appliance or

attempt any servicing unless specifically

recommended in the user-maintenance instructions.

9) Do not use heat to dry articles containing foam

rubber or similarly textured rubber-like materials.

10) Clean lint screen before or after each load.

11) Keep area around the exhaust opening and adjacent

surrounding areas free from the accumulation of

lint, dust, and dirt.

12) The interior of the appliance and exhaust duct

should be cleaned periodically by qualified service

personnel.

13) Do not place items exposed to cooking oils in your

dryer. Items contaminated with cooking oils may

contribute to a chemical reaction that could cause a

load to catch fire.

14) Do not use fabric softners or products to eliminate

static unless recommended by the manufacturer of

the fabric softner or product.

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of

malfunction or breakdown, grounding will reduce the

risk of electric shock by providing a path of least

resistance for electric current. This appliance is

equipped with a cord having an equipment-grounding

conductor and a grounding plug. The plug must be

plugged into an appropriate outlet that is properly

installed and grounded in accordance with all local

codes and ordinances.

WARNING - Improper connection of the equipment-

grounding conductor can result in a risk of electric

shock. Check with a qualified electrician or service

person if you are in doubt as to whether the appliance is

properly grounded.

Do not modify the plug provided with the appliance: if

it will not fit the outlet, have a proper outlet installed by

a qualified electrician.

This appliance must be connected to a grounded metal,

permanent wiring system or an equipment-grounding

conductor must be run with the circuit conductors and

connected to the equipment-grounding terminal or lead

on the appliance.

WARNING!

To help reduce any risk of electric shock, fire, or other personal or property injury

when using your dryer, please exercise care and follow basic safety precautions,

including the following:

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Part 2

IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

• Do not try to light a match or cigarette, or turn

on any gas or electrical appliance.

• Do not touch any electrical switches. Do not

use any phone in your building.

• Clear the room, building or area of all

occupants.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions carefully.

• If you cannot reach your gas supplier, call the

fire department.

To reduce the risk of fire or explosion, electric

shock, property damage, personal injury or death

when using this appliance, please follow all

instructions and information, including those in

this manual and instructions and information

provided by your gas supplier, including the

following:

• Do not store or use any gasoline, dry-cleaning

solvents any other flammable vapors or

liquids in the area surrounding this appliance.

• Do not dry anything that has ever had anything

flammable on it, even after washing.

• No washer can completely remove oil. Do not

dry any articles that have ever had any kind of

oil on them, including cooking oil.

• Articles containing foam, rubber, rubber-like

materials, plastic or similar materials should be

dried on a clothesline or by using an air cycle.

• Failure to follow these instructions can result in

fire, death or serious injury.

• A qualified service person or company must

perform installation and service of this

appliance.

WHAT TO DO IF YOU SMELL

GAS:

WARNING!

• Keep flammable materials and vapors, such

as gasoline, away from dryer.

• Place dryer at least 18 inches above the floor

for a garage installation.

• Failure to do so can result in death,

explosion or fire.

WARNING

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

The following instructions will help guide you through the initial steps of setting up your dryer for use.

Please note that every section of this manual provides important information regarding the preparation and

use of your dryer, and it is important that you review this entire manual before proceeding with any

installation or use. More detailed instructions concerning electrical connections, gas connections, and

exhaust requirements are provided at other parts of this manual.

Choose a location with a solid floor for your dryer.

Place the dryer at least eighteen inches above the

floor for a garage installation. After placing the

dryer in the desired location, please make sure that

it has the required clearances shown below, and

sections on Exhaust and Maintenance requirements.

If you are installing your dryer in a manufactured or

mobile home, please refer to STEP 9 below for

additional instructions.

Certain minimum clearances are required

above, behind,and to the sides of the unit,as

shown below. Those required minimum clearances

are set forth in the picture below. Please also keep the

following instructions in mind when installing in a

closet or recessed area:

• Consider allowing additional clearance for

installation and servicing.

• Wall,door and floor molding may forceadditional

clearances.

• An additional inch of clearance is recommended to

minimize noise transfer

• Consider space needed for companion appliances.

• For closet installations, the picture below shows the

minimum required ventilation openings for the door.

A louvered door with comparable ventilation openings

is also acceptable.

* Most installations require a minimum 5 1/2 in.

(14 cm) clearance behind the dryer for the exhaust

vent with elbow.

<Closet-Side view><Closet door>

ventilation

hole

ventilation

hole

<Closet-Front view>

38.7”

(98.3 cm)

27”

(68.6 cm)

29.9”

(76.1 cm)

49.8”

(126.4 cm)

STEP 1 Positioning the Dryer.

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

Once in position, adjust the leveling legs of the dryer

until it is level from left to right and from front to

back. The leveling legs must remain firmly on the

floor and the dryer should not rock. The maximum

slope of the dryer from left to right or from front to

back should not exceed 2.5 cm (1 inch). If the dryer

is not level, and if the slope exceeds 2.5 cm (1 inch),

a load may not tumble properly and internal sensors

may malfunction. Note: Other sections of this

manual also provide important information

concerning the placement of and clearances for your

dryer. Please review this entire manual before

proceeding with any installation.

The door on your dryer can be installed to open

either to the left or the right. Follow these

procedures to reverse the direction in which your

door opens:

STEP 2 Procedure for Reversing

the Door

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

In addition to the following warnings, please refer

to manual section on Exhaust Requirements and

Maintenance. IMPORTANT: To reduce the risk of

fire, combustion, and gas accumulation, the dryer

must be vented to the outdoors. Please follow the

instructions (and all others in this manual) very

carefully.

• Do not use thin plastic or foil ducting.

• Use 4" (10.2 cm) diameter rigid or flexible metal

duct (note: venting materials are not supplied with

the dryer, and you should obtain the venting

materials necessary for proper installation)

• Position the Dryer such that the exhaust duct run is

as short as possible.

• Clean old ducts before installing this dryer

• The male end of each section of exhaust duct must

point away from the dryer

• Use as few elbow joints as possible.

• Use duct tape on all duct joints

• Insulate ductwork that runs through unheated

areas in order to reduce condensation and lint

build-up on pipe walls; and

• PLEASE BE AWARE THAT FAILURE TO

EXHAUST THE DRYER CORRECTLY WILL

VOID THE DRYER’S WARRANTY.

WARNING!

• Use a heavy metal vent.

• Do not use a plastic vent.

• Do not use a metal foil vent.

• Failure to follow these instructions can

result in death or fire.

• Clean old ducts before installing this dryer

■ ALTERNATE EXHAUST DIRECTIONS

1. Remove a screw and exhaust duct.

2-1. Detach and remove the knockout that

matches the desired venting direction

(Right side not available on Gas Dryers)

, , the order of work.

2-2. Reconnect the duct to the blower

housing and attach the duct to the

base.(Duct is a SVC part)

3-1. Pre-assemble 4" elbow with 4" duct.

Wrap duct tape around joint.

3-2. Insert elbow duct assembly first through the

side opening and connect the elbow to the

internal duct.

STEP 3 Connecting the Exhaust

and Venting System.

1 0

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

(Gas dryer only). In addition to the following,

please refer to manual section on Gas Requirements

and Instructions.

1. Confirm that the type of gas available in your

laundry room is appropriate for the dryer. The

dryer is prepared for Natural Gas with a 3/8"

NPT gas connection.

2. Remove the shipping cap from the gas

connection at the back of the dryer. Make sure

that you don’t damage the threads of the gas

connection pipe when you remove the shipping

cap.

3. Connect the dryer to your laundry room’s gas

supply using a new flexible stainless steel

connector (as noted below, only use a new

stainless steel flexible connector if allowed by

your local codes).

4. Securely tighten all connections between the

dryer and your laundry room’s gas supply. Turn

on your laundry room’s gas supply and check all

pipe connections (both internal and external) for

gas leaks with a non-corrosive leak detection

fluid.

5. For LP (Liquefied Petroleum) gas connection,

refer to this manual’s section entitled Gas

Requirements and Instructions.

1. New stainless steel flexible connector. Use this type of

connector only if allowed by local codes. Use Design AGA

Certified Connector.

2. 1/8" NPT Pipe Plug (for checking inlet gas pressure)

3. Equipment Shut-Off Valve-

Installed within 6’ (1.8 m) of dryer

4. Iron Pipe. Shorter than 20’ (6.1 m)

Use 3/8" pipe. Longer than 20’ (6.1 m) - Use 1/2" pipe.

5. 3/8" N.P.T. Gas Connection

Following are several warnings and instructions

concerning making the electrical connection for

electric dryers. More detailed information

concerning the electrical connection is provided at

the manual section entitled Electrical Requirements

For Electric Dryer and it is important that you

thoroughly review that section, and the remainder of

this manual, before taking any steps to install or use

this dryer.

1. Use only a new U.L. listed No. 10 (copper wire

only) three conductor power supply cord kit rated

240 Volts (minimum) 30 Amperes and labeled as

suitable for use in a clothes dryer.

2. Four-wire cord is required for manufactured

(mobile) home installations and use and where

local codes do not allow grounding of this

appliance through neutral.

3. Electrical Plug Connections

4. For additional instruction on connecting the dryer

to an electrical power source, please refer to this

manual’s section on Electrical Requirements and

Electric Dryer.

WARNING!

• Use a new UL approved 30 amp power

supply cord or 10 gauge solid copper wire.

• Use a UL approved strain relief.

• Disconnect power before making electrical

connections.

• Connect neutral wire(white or center wire)

to center terminal.

• Ground wire(green or bare wire) must be

connected to green ground connector.

• Securely tighten all electrical connections

• See installation instructions for complete

instructions.

• Failure to do so can result in fire or

electrical shock.

STEP 4

Connection of Gas Supply

STEP 5

Electrical Plug Connections.

1 2

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

The following instructions are applicable to

installations of the dryer in a manufactured or

mobile home. Any installation in a manufactured or

mobile home must comply with the Manufactured

Home Construction and Safety Standards Title 24

CFR, Part 32-80 or Standard CAN/CSA0Z240 MH

and local codes and ordinances. If you are

uncertain whether your proposed installation will

comply with these standards, please contact a

service and installation professional for assistance.

The following instructions apply to any installation

of the dryer in a manufactured or mobile home:

1) The gas dryer must be permanently attached to

the floor.

2) The electrical connection for an electric dryer

must be a 4-wire connection. More detailed

information concerning the electrical connection

is provided at the manual section entitled

Electrical Requirements for Electric Dryer

3) To reduce the risk of combustion and fire, the

dryer must be vented to the outside.

4) Electric dryers may be vented to the outside

using the back, left, right, or bottom panel.

5) Gas dryers may be vented to the outside using the

back, left, or bottom panel. Gas dryer may not be

vented to the outside using the right side panel

because of the burner housing.

6) The dryer exhaust duct must be affixed securely

to the manufactured or mobile home structure,

and the exhaust duct must be made of a material

that will resist fire and combustion, and it is

recommended that you use a rigid or flexible

metal pipe.

7) DO NOT connect the exhaust duct with any other

duct, vent, chimney, or other exhaust duct.

8) Make sure the dryer has adequate access to

outside fresh air to ensure proper operation. The

opening for outside fresh air must be at least 25

in2(163 cm2).

9) It is important that the clearance of the duct from

any combustible construction be at least 2 inches

(5 cm), and, when venting the dryer to the

outdoors, the dryer can be installed with a

clearances of 1 inch at the sides and back of the

dryer.

10) Please be aware that venting materials are not

supplied with the dryer. You should obtain the

venting materials necessary for proper

installation.

WARNING!

DO NOT connect exhaust ducts with

metal screws or fasteners that extend

into the duct.

WARNING!

DO NOT vent the exhaust duct under the

manufactured or mobile home.

STEP 9

Additional Instructions

for Installation of Your

Dryer in a Manufactured

or Mobile Home.

1 3

Part 4 ACCESSORIES INSTALLATION

To ensure safe and secure installation, please

observe the instructions below.

Place washer firmly on a stable, even and

solid floor.

Peel protective paper off the tape from the

stacking kit side bracket.

Fit the stacking kit side bracket firmly to the

side of top plate by attaching the double-

faced tape to top plate as picture shows.

Secure stacking kit side bracket to the

washer with a screw on the back of bracket.

Repeat Steps 2, 3, 4 for the other side.

Place the dryer on top of the washer by fitting

legs as shown in the picture. Avoid finger

injuries - be careful not to pinch fingers

between the washer and dryer. Slide washer

slowly backwards to the stopper of kit.

Insert the front stacking kit. Push the front

stacking kit back to the stoppers of side

stacking kit.

Screw both sides of the front kit.

• Do not use stacking kit with a gas dryer in

potentially unstable conditions like a mobile

home.

Stacking kit

Incorrect Installation can cause serious

accidents.

The weight of the dryer and the height of

installation makes the stacking procedure

too risky for one person. This procedure

should be performed by 2 or more

experienced service personnel.

WARNING

Stacking Kit Installation Instructions

Part 4

1 4

ACCESSORIES INSTALLATION

Pedestal Installation Instructions

1 4

1) Shut off Gas

2) Unplug Power Cord

3) Disconnect Gas Line from Dryer

4) Pull away and loosen vent clamp.

Disconnect venting.

1 5

Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS

Following are additional instructions regarding electrical connections and requirements for electric dryers.

Important Warning: To help prevent fire, electric shock, serious injury or death, the wiring and grounding

must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70 and all applicable local

regulations. Please contact a qualified electrician to check your home’s wiring and fuses to ensure that your home

has adequate electrical power to operate the dryer.

Chile 220V/50Hz Mexico 220V/60Hz, 127V/60Hz

Panama 120V, 240V/60Hz Peru 220V/50Hz • 120V, 240V/60Hz

Colombia 120V, 60Hz

Instructions for Grounding of your Electric

Dryer:

a) Please note that the wiring diagram is provided

inside the dryer cabinet.

b) This dryer must be connected to a grounded

metal, permanent wiring system; or an

equipment-grounding conductor must be run

with the circuit conductors and connected to the

equipment-grounding terminal or lead on the

dryer.

c) If branch circuit to dryer is fifteen feet (4.50 m)

or less in length, use U.L. (Underwriters

Laboratories) listed No. 10 A.W.G. wire (copper

wire only), or as required by local codes. If over

fifteen feet (4.50 m), use U.L. (Underwriters

Laboratories) listed No. 8 A.W.G. wire (copper

wire only), or as required by local codes. Allow

sufficient slack in wiring so dryer can be moved

from its normal location when necessary.

d) The power cord (pigtail) connection between

wall receptacle and dryer terminal block IS

NOT supplied with dryer. Type of pigtail and

gauge of wire must conform to local codes and

with instructions mentioned on the following

pages.

e) The method of wiring the dryer is optional and

subject to local code requirements. Refer to

examples on next page.

f) You must select the method by which to wire

your dryer according to local code and ordinance

requirements. Sample methods are included in

the following pages.

WARNING!

Label all wires prior to disconnection

when servicing the dryer, because

wiring errors can cause serious injury

to you and your dryer.

1 6

Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS

Use the instructions at this section if your home has

a 3-wire receptacle (NEMA type 10-30R) and you

will be using a UL listed, 120/240 volt minimum,

30 amp, dryer power supply cord.

Review the following options to determine the appropriate electrical connection

for your home:

If this type is available at your home. you will be

connecting to a fused disconnect or circuit breaker

box

Important : use 4-wire connection in the places such

as mobile homes and areas where 3-wire connections

is not available.

Prepare minimum 5ft(1.52m) of length in order for

dryer to be replaced.

First, peel 5 inch (12.7cm) of covering material from

end. Make a 5 inch of ground wire bared. After cutting

/2inch (3.8cm) from 3 other wires. peel insulation

back 1inch (2.5cm). Make ends of 3 wires a hook

shape.

Then, put the hooked shape end of the wire under the

screw of the terminal block(hooked end facing rightward)

and pinch the hook together and screw tightly.

Use the instructions at this section if your home has

a 4-wire receptacle (NEMA type 14-30R) and you

will be using a UL listed, 120/240 volt minimum,

30 amp, dryer power supply cord.

If this type is available at your home. you will be

connecting to a fused disconnect or circuit breaker

box

1. Connect neutral wire(white) of power cord to center

terminal block screw.

2. Connect red and black wire to the left and right

terminal block screws.

3. Connect ground wire(green) of power cord to external

ground screw and move neutral ground wire of

appliance and connect it to center screw.

4. Make sure that the strain relief screw is tightened.

and be sure that all terminal block nuts are on tight and

power cord is in right position.

3-wire direct

4-wire receptacle

(NEMA type14-30R)

3-wire receptacle

(NEMA type10-30R)

4-wire direct

4-wire connection : Direct wire

1 7

Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS

Important : use 3-wire connection in the places

such as mobile homes and areas where 3-wire

connections is not available.

Prepare minimum 5ft(1.52m) of length in order for

dryer to be replaced.

First, peel 3 1/2inch (8.9cm) of covering material

from end and bare 1 inch from the ends.

1. Connect neutral wire(white) of power cord to

center terminal block screw.

2. Connect red and black wire to the left and right

terminal block screws.

3. Make sure that the strain relief screw is tightened

and be sure that all terminal block nuts are on

tight and power cord is in right position.

Then, put the hooked shape end of the wire under

the screw of the terminal block(hooked end facing

rightward) and pinch the hook together and screw

tightly.

3-wire connection : Direct wire

1. Connect neutral wire(white) of power cord to

center terminal block screw.

2. Connect red and black wire to the left and right

terminal block screws.

3. Connect ground wire(green) of power cord to

external ground screw and move neutral ground

wire of appliance and connect it to center screw.

4. Make sure that the strain relief screw is tightened.

and be sure that all terminal block nuts are on

tight and power cord is in right position.

• lf your local codes or ordinances do not allow the

use of a 3 wire connection, or you are installing

your dryer in a mobile home, you must use a 4-

wire connection.

Option 1: 4-wire connection with

a Power supply cord.

1 8

1. Connect neutral wire(white) of power cord to

center terminal block screw.

2. Connect ground wire of appliance and neutral

wire of power cord to center terminal block

screw.

3. Connect red and black wire to the left and right

terminal block screws.

4. Make sure that the strain relief screw is tightened.

and be sure that all terminal block nuts are on

tight and power cord is in right position.

5. Connect a independent ground wire from external

ground connector to proper ground.

Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS

lf your local codes or ordinances permit the

connection of a frame-grounding conductor to the

neutral wire, use these instructions. If your local

codes or ordinances do not allow the connection of

a frame-grounding conductor to the neutral wire,

use the instructions under Section 3: Optional

3-wire connection.

Option 2: 3-Wire Connection with

a Power Supply Cord

• If your local codes or ordinances do not allow the

connection of a frame-grounding conductor to the

neutral wire, use the instructions under this

section.

Option 3: Optional 3-wire

connection.

1 9

Part 6 ELECTRICAL REQUIREMENTS FOR GAS DRYERS

Chile 220V/50Hz Mexico 127V/60Hz

Panama 120V, 240V/60Hz Peru 220V/60Hz

Following are additional instructions regarding electrical connections and requirements for gas dryers.

Important Warning: To help prevent fire, electric shock, serious injury or death, the wiring and grounding

must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical

Code, CSA C22.1, and all applicable local regulations. Please contact a qualified electrician to check your home’s

wiring and fuses to ensure that your home has adequate electrical power to operate the dryer.

Electrical Requirements for Your Dryer:

a) Please note that the wiring diagram is provided

inside the dryer cabinet. Label all wires prior to

disconnection when servicing the dryer, because

wiring errors can cause serious injury to you and

your dryer.

b) Use separately fused circuits for washers and

dryers, and DO NOT operate a washer and a

dryer on the same circuit.

a) The dryer has a three-prong plug to help guard

against shock. The plug should be plugged

directed into a properly grounded three-prong

receptacle that is rated 120 Volts AC (alternating

current) 15 Amps. This plug, in order to be

properly and fully effective, must be plugged into

a properly installed outlet that is grounded in

accordance with all local codes and ordinances.

b) The dryer must be grounded in order to reduce

the risk of electric shock, including a

malfunction or breakdown.

c) If your laundry room does not meet the

specifications required by this manual, or if you

are uncertain whether or not your laundry room

meets these specifications, please have a

qualified service person or company, for example

a qualified electrician or your local electric

company, review your laundry room’s electrical

supply for any problems.

WARNING!

Do not overload the circuit by operating

other appliances on the same circuit when

this appliance is operating, by using an

extension cord to connect the dryer to the

power source, or by using any adapter to

allow additional cords to connect to the

same outlet.

STANDARD 120 VOLT, 60 HERTZ, 3-WIRE

EFFECTIVELY GROUNDED CIRCUIT

1L1

2Ground

3Neutral Side

4Round Grounding Prong

5Neutral

WARNING!

DO NOT modify the plug provided with

the dryer. If it does not fit the outlet in your

laundry room, a proper outlet will need to be

installed in your laundry room by a qualified

service person or company.

2 0

Part 7 GAS REQUIREMENTS AND INSTRUCTIONS

Following are important instructions and information concerning the requirements for the gas supply and service for

gas dryers. Important Warning: The gas supply and service for a gas dryer must comply with all local codes

and ordinances. In the absence of any local codes or ordinances in your area, the gas supply and service for your gas

dryer must comply with the latest edition of the National Fuel Gas Code, ANSI Z223.1/NFPA 54.

1. Gas supply requirements: Liquefied Petroleum

(L.P.) Gas (2,500 Btu/ft3 (93.1 MJ/m3)) service

must be provided at 10 + 1.5 in. water column

pressure.

2. Do not attempt to connect Dryer to Liquified

Petroleum (LP Gas)Gas service without a

qualified professional.

3. Isolate the dryer from the gas supply piping

system by closing its individual manual shut-off

valve, during any pressure testing of the gas

supply system at test pressure equal to or less

than 2/1 psi (3.45 kPa).

4. Supply Line Requirements. Your laundry room

must have a rigid gas supply line to your dryer.

In the United States, an individual manual shutoff

valve MUST be installed within at least 6 feet

(1.8m) of the dryer, in accordance with the

National Fuel Gas Code ANSI Z223.1. A 1/8 in.

N.P.T. pipe plug must be installed as shown.

5. If using a rigid pipe, the rigid pipe should be 1/2

inch IPS. If acceptable under local codes and

ordinances and when acceptable to your gas

supplier, 3/8 inch approved tubing may be used

where lengths are less than 20 feet (6.1m).

Larger tubing should be used for lengths in

excess of 20 feet (6.1m). It is also important that

you use pipe joint compound that is insoluble in

LP gas.

6. To reduce the danger of gas leaks, explosion, and

fire, please follow and observe the following

instructions and WARNINGS:

• Connect the dryer to the type of gas shown on the

nameplate;

• Use new flexible stainless steel connectors;

• Use Teflon tape and pipe joint compound

insoluble in LP gas on all pipe threads;

• Purge gas supply of air and sediment before

connecting the gas supply to the dryer; in order to

prevent gas valve contamination, before tightening

connection between gas supply and dryer, purge

remaining air until odor of gas is identified; and

• DO NOT use an open flame to inspect for gas

leaks; instead, use a non-corrosive leak detection

fluid.

WARNING!

• Use a new AGA or CSA approved gas

supply line.

• Install a shut-off valve.

• Securely tighten all gas connections.

• If connected to LP, have a qualified person

make sure gas pressure does not exceed

13 in. water column.

• Examples of a qualified person include

licensed heating personnel, authorized gas

company personnel, and authorized service

personnel.

• Failure to do so can result in death,

explosion, or fire.

WARNING!

DO NOT attempt any disassembly of the

dryer, any disassembly requires the

attention and tools of an authorized and

qualified service person or company.

2 1

Part 8 EXHAUST REQUIREMENTS AND MAINTENANCE

Following are important instructions and information concerning the exhaust requirements for your dryer.

Important Warning: To reduce the risk of fire, combustion, or accumulation of combustible gases, DO NOT

exhaust dryer air into an enclosed and unventilated area, such as an attic, wall, ceiling, crawl space, chimney, gas

vent, or concealed space of a building. To reduce the risk of fire, DO NOT exhaust the dryer with plastic or thin foil

ducting.

Exhaust Requirements and Instructions:

1. Venting materials are not provided with the dryer

and you should obtain the necessary venting

materials locally. For example, the outer end of

exhaust pipe must have a weather hood with

hinged dampers to prevent back-draft when the

dryer is not in use.

2. The exhaust duct must be four inches (10.2 cm)

in diameter with no obstructions. The exhaust

duct should be kept as short as possible. Make

sure to clean any old ducts before installing your

new dryer.

3. Rigid metal duct is recommended. Do not install

flexible duct in concealed spaces.

Non-combustible flexible metal duct is

acceptable. Do not use plastic or thin foil ducting.

4. DO NOT use sheet metal screws on exhaust pipe

joints or other fastening means which extend into

the duct that could catch lint and reduce the

efficiency of the exhaust system. Secure all joints

with duct tape.

5. To maximize operating results, please observe the

duct length limitations noted in the chart above.

Number of 90°

Elbows

Weather Hood

Type

Recommended

Maximum length of 4”

(10.2 cm) diameter rigid

metal duct

Maximum length of 4”

(10.2 cm) diameter

flexible metal duct

NOTE : Deduct 6 feet (1.8 m) for each additional elbow.

It is not recommended to use more than 4 90° elbows.

Use Only for Short Run

Installations

65 feet (19.8 m)

55 feet (16.8 m)

47 feet (14.3 m)

36 feet (11.0 m)

28 feet (8.5 m)

45 feet (13.7 m)

35 feet (10.7 m)

30 feet (9.1 m)

25 feet (7.6 m)

20 feet (6.1 m)

55 feet (16.8 m)

47 feet (14.3 m)

41 feet (12.5 m)

30 feet (9.1 m)

22 feet (6.7 m)

35 feet (10.7 m)

27 feet (8.2 m)

21 feet (6.4 m)

17 feet (5.2 m)

15 feet (4.5m)

4”

(10.2 cm)

4”

(10.2 cm)

2-1/2”

(6.35 cm)

2 3

Part 9 OPERATING YOUR DRYER

1. Clean lint screen before or after each cycle.

2. Place laundry into dryer and shut door. See

3. Turn the knob to select the drying cycle you want.

The preset settings for Sensor Dry Cycles or

Manual Cycles will glow. The estimated or actual

cycle time (in minutes) will show in the display.

Following are instructions for starting and using your new dryer. Please refer to specific sections of this manual for

more detailed information. Important Warning: To reduce the risk of fire, electric shock, or injury to person, read

this entire manual, including the , before operating this dryer.Important Safety Instructions

WARNING!

Fire Hazard

No washer can completely remove oil.

Do not dry anything that has ever had any

type of oil on it (including cooking oils).

Items containing foam, rubber, or plastic

must be dried on a clothesline or by using

an Air Cycle. Failure to follow these

instructions can result in death or fire.

WARNING!

Explosion Hazard

Keep flammable materials and vapors, such

as gasoline, away from dryer.

Do not dry anything that has ever had

anything flammable on it (even after

washing). Failure to follow these instructions

can result in death, explosion, or fire.

TD-V10050E/TD-V10050G/TD-V10055E/TD-V10055G/TD-V12055E/ TD-V12055G/TD-V12056E/TD-V12056G/TD-V14056E/TD-V14056G

TD-V10051E/TD-V10051G

1. Using Your Dryer

2 4

Part 9 OPERATING YOUR DRYER

• Select a Manual Dry Cycle.

• Press MORE TIME or LESS TIME until the

desired drying time is displayed. Tap MORE

TIME or LESS TIME and the time will change by

1 minute intervals.

NOTE: The MORE TIME or LESS TIME

feature can be used with Manual Dry, Time Dry,

and Rack Dry Cycles.

• Press TEMP. CONTROL until the desired

temperature indicator glows.

• (OPTIONAL STEP) If desired, select OPTIONS.

For more details, see Options.

• Press START/PAUSE. Be sure the door is closed.

• If you do not press START/PAUSE within 10

minutes of selecting the cycle, the dryer

automatically shuts off.

• If you wish to end your drying cycle after pressing

START/PAUSE, press START/PAUSE again.

When loading your dryer:

• Determine load size by the amount of space the

load requires rather than the weight of the load.

• Avoid overloading the dryer.

Following these instruction can help reduce your

utility bill, prolong the life of your clothes, and

decrease the likelihood of uneven drying and

wrinkle.

Heavy Work Clothes

4 jeans

4 workpants

4 work shirts

2 sweatpants

2 sweatshirts

Cotton/Towels

10 bath towels

10 hand towels

14 wash cloths

Mixed Load

3 sheets (1 king, 2 twin)

4 pillowcases

3 shirts

3 blouses

9 T-shirts

9 shorts

10 handkerchiefs

Following are sample loads for Super Capacity

Dryers:

To stop your dryer at any time

Press START/PAUSE or open the door.

To pause the dryer at any time

Open the door or press START/PAUSE once.

To restart the dryer

Close the door. Press START/PAUSE.

NOTE: Drying will continue from where the cycle

was interrupted if you close the door and press

START within 10 minutes. If the cycle is

interrupted for more than 10 minutes, the dryer will

shut off. Select new cycle settings before restarting

the dryer.

• Select an Sensor Dry Cycle.

• Select DRY LEVEL to adjust

how dry you want the load. As

the cycle runs, the control

senses the dryness of the load

and adjusts the time

automatically for the selected

dryness level.

• Select the desired Options.

• Press START/PAUSE

NOTE: DRY LEVEL selections can only be

made while using Sensor Dry Cycles. Selecting

MORE Dry or LESS Dry automatically adjusts the

sensed time needed.

2. To use a Sensor Dry Cycle 4. Stopping Your Dryer

5. Loading

3. To use a Manual Dry Cycle

2 5

Part 9 OPERATING YOUR DRYER

Select the drying cycle that matches the type of load

you are drying.

(See Sensor Dry or Manual Preset Cycle Settings

charts.)

Sensor Dry Cycles allow you to match the cycle to

the load you are drying. Each cycle dries certain

fabrics at the recommended temperature. A sensor

detects the moisture in the load and automatically

adjusts the drying time for optimal drying

• Heavy Duty

Use this cycle to get high heat for heavy fabrics such

as jeans, corduroys, or work clothes

• Cotton/Towels

Use for drying denims, towels, heavy cottons

(medium-high heat)

• Normal

Use for drying sturdy fabrics such as work casual

clothes (medium heat)

• Perm press

Use for permanent press and synthetic items

(medium-heat)

• Delicates

Use for drying synthetic fabrics, washable knit

fabrics, and no-iron finishes (low heat)

• Ultra Delicate

Use to gently dry items such as workout wear, shear

and lace items (ultra low heat)

* Estimated Time with SENSOR DRY LEVEL

(Normal) setting.

Sensor Dry

Cycles Load Type Temp.

High

Medium

High

Medium

Low

Ultra

Low

Time*

(Minutes)

Use Manual Cycles to select a specific amount of

drying time and a drying temperature. When a

Manual Cycle is selected, the ESTIMATED TIME

REMAINING display shows the actual time

remaining in your cycle. You can change the actual

time in the cycle by pressing MORE TIME or LESS

TIME.

• Speed Dry

Use for small loads or loads that need a short

drying time.

• Freshen Up

Use this cycle to remove wrinkles from items,

such as clothes packed in a suitcase or items

wrinkled from being left in the dryer too long.

• Air Dry

Use the Air Dry Modifier for items that require

drying without heat such as rubber, plastic and

heat-sensitive fabrics.

HEAVY DUTY

Jeans, heavyweight

COTTON/TOWELS

Towel, denim pants

NORMAL

Work clothes,corduroys

PERM PRESS

Synthetics , permanent

press

DELICATES

Lingerie, sheets, blouses

ULTRA DELICATE

Shear, workout wear

and lace items

Sensor Dry Preset Cycle Settings

This feature allows you to lock

your settings to prevent children

from changing them. You can

also use the child lock feature

to prevent unintended cycle or

option changes during dryer operation.

To enable the Child Lock feature:

Press and hold RACK DRY for 3 seconds. A single

BEEP Tone is heard, and CL is displayed. To

unlock, press and hold RACK DRY for 3 seconds.

The indicator light turns off.

6. Cycle Descriptions

2 6

Part 9 OPERATING YOUR DRYER

• Time Dry

Use this cycle to complete drying if items are still

damp after an Sensor Dry Cycle. Time dry is also

useful for drying heavyweight and bulky items,

such as bedspreads and work clothes.

When you select the damp dry

beep option, a beep will alert you

when your load is Approximately

80% dry.

This notice will allow you to

remove lightweight items that are dry or other items

that you may wish to iron.

When you select the wrinkle free

option, the dryer will periodically

tumble for up to three hours after

to the cycle has completed.

This option helps to prevent the

wrinkle that form when a load remains in the dryer

after the cycle is completed. The wrinkle care

option ends after the three hours when you push the

wrinkle care option button on, when you open the

dryer door

This chart shows examples of items that can be

dried using AIR DRY.

* Reset cycle to complete drying, if needed.

• Check to see that coverings are securely stitched.

• Shake and fluff pillows by hand periodically

during the cycle.

• Dry item completely. Foam rubber pillows are

slow to dry.

NOTE: Air Dry is not available with Sensor Dry

Cycles.

Manual Dry

Cycles Load Type Temp.

High

Medium

High

Air Dry

Default Time*

(Minutes)

SPEED DRY

SMALL LOADS

FRESHEN UP

Remove Wrinkles

AIR DRY

Manual Preset Cycle Settings

Type of Load Default Time*

(Minutes)

Foam rubber-pillows,

padded bras, stuffed toys

20 - 30

40 - 50

10 - 20

Plastic-Shower curtains,

tableclothes

Rubber-backed rugs

Olefin, polypropylene,

shear nylon

You can customize your cycles by selecting options.

Use Modifiers to select temperatures for the Manual

Cycles. Press TEMP. CONTROL until the desired

temperature setting glows. Temperature modifiers

cannot be used with the Sensor Dry Cycles.

7. Options

8. Modifiers

2 7

Part 9 OPERATING YOUR DRYER

The dryer rack is shipped in place

in your dryer. Remove and

discard any packing material

before use.

The RACK DRY is designed for

use with items that you do not want to tumble dry,

including sweaters and similar items. The heated

dryer rack allows the heated air inside the dryer to

flow in a concentrated pattern, allowing effective

and consistent drying. Use RACK DRY to select

the desired time.

NOTE: Check the lint screen and remove any lint

accumulated from items dried on the rack.

Suggested Items

for Rack Drying

Temperature

Setting

Suggested

Time*

(Minutes)

Washable wool items

Low 20

20/30

50/30

Low/Ultra

Low

Air Dry/

Ultra Low

Air Dry

Stuffed toys with

cotton or polyester

fiber filling

Stuffed toys, foam

rubber filled.

Foam rubber pillows

Athletic shoes

* Reset time as needed to complete drying.

• When drying washable wool items, block and shape

the items to lay flat on the dryer rack.

• Select RACK DRY and MORE TIME or LESS

TIME. Reset time as needed to complete drying.

Refer to the following table.

• Select the desired temperature setting to match the

fabrics in your load by pressing TEMP. CONTROL

(Air Dry-Ultra Low-Low). Items containing foam,

rubber, or plastic must be dried on a clothesline or by

using the Air Dry temperature setting. Refer to the

following table.

• Start the dryer.

1.Open the door.

Hold the dryer rack

with both hands.

2. Put the dryer rack

into the drum

3. Make sure Dryer

RACK is evenly

spaced the drum

inside and door

rim.

This option can only be used

with the HEAVY DUTY,

COTTON/TOWELS, and

NORMAL cycles.

This option reduces certain

types of bacteria.

The ANTI BACTERIAL process produces high

temperature during the cycle.

NOTE: Do not use this cycle on delicate fabrics.

9. Rack Dry

10. Anti Bacterial

2 8

Part 9 OPERATING YOUR DRYER

Clean lint filter

Clean the lint filter after each use and check it

before use. Not cleaning or emptying the filter

will increase drying time and energy

consumption, therefore dryer life expectancy

could be shortened after all.

Set up your favorite combination

of settings and save them here

for one-touch recall.

To store a CUSTOM

PROGRAM.

1. Select a cycle

2. Change DRY LEVEL and TEMP. CONTROL.

3. Select OPTIONS you want.

4. Press and hold the CUSTOM PROGRAM.

To recall your stored CUSTOM PROGRAM

Press CUSTOM PROGRAM button, then press

START/PAUSE.

1.Open the door

and pull the filter

straight up

1. Wipe out the

door opening.

Otherwise, build-

ups of dirty and

foreign objects

will damage

sealing of door.

2. Clean the

transparent glass

door to keep

inside view clear

through the

glass.

Run the fingers

across the filter

2.Clean the filter using one of following ways in cases.

Vacuum the lint

filter

Wash the lint

screen in

warm,soapy

water.

Dry thoroughly

and replace.

The BEEPER controls the

volume of the beep that is made

when you press any of the

buttons on the control panel and

the termination of any cycle is

indicated.

Press BEEPER to adjust the

sound level or turn off the signal.

■ Clean the door and its opening

11. Custom Programming 12. Beeper

Maintenance

2 9

Part 10 TROUBLESHOOTING GUIDE

Troubleshooting Tips

Save time and money! Review the charts on the following

pages first and you may not need to call for service.

1.Problem:My Dryer Won ’t Start

• Is the dryer plugged in?

• Is the fuse blown, or is the circuit

breaker tripped?

Confirm that the dryer’s plug is securely and completely pushed into the laundry

room’s power outlet

Check your home’s or laundry room’s fuse box/circuit breaker box and replace the

fuse or reset the circuit breaker. (IMPORTANT: electric dryers generally use two

fuses or breakers.)

Question What to Do

2.Problem:My Dryer Doesn ’t Heat

Question What to Do

• Is the fuse blown, or is the circuit

breaker tripped?

• Is the gas supply or service

blocked or off?

If the fuse is blown or the circuit breaker tripped, the dryer might tumble but not

heat. Check your home’s or laundry room’s fuse box / circuit breaker box and

replace the fuse or reset the circuit breaker. (IMPORTANT: electric dryers generally

use two fuses or breakers.)

Confirm that the house gas shutoff and the dryer gas shutoff are both fully open.

3.Problem:There are Greasy Spots on My Clothes

Question What to Do

• Did you follow the instructions on

your fabric softener product?

• Are you drying clean and dirty

clothes together?

• Were your clothes entirely clean?

Confirm and follow the instructions provided with your fabric softener product.

Make sure to use your dryer to dry only clean items, because dirty items can soil

clean clothes placed in the same load or later placed in the dryer drum.

Stains on dried clothes are actually stains that weren’t cleansed during the washing

process. Please review and confirm that you are following your washing

instructions and that the clothes are being completely cleaned.

3 0

Part 10 TROUBLESHOOTING GUIDE

5.Problem:There is static in my clothes after drying

Question What to Do

4.Problem:There is Lint on my Clothes

Question What to Do

Please refer to the manual section on cleaning the lint filter, and please confirm that the

lint filter is clean. It is important that the lint filter is clean before each new load of

laundry.

In order to reduce the amount of lint in a load of laundry, sort lint producers (like a

fuzzy white cotton towel) separately from clothes that might catch lint (such as a pair

of black linen pants).

See comments below under There is static in my clothes after drying.

Divide your larger load into smaller loads.

Sometimes a person might forget to take a piece of paper or a tissue out of the pocket

of a pair of pants, and this paper, tissue, or similar material can cause excess lint in a

load of laundry. Confirm that the pockets of pants, shirts, and other articles of clothing

are empty before washing and drying.

• Is your lint filter full?

• Did you properly sort your load of

laundry?

• Do your clothes have excess static

electricity?

• Did you overload your dryer?

• Did you place any paper, tissue, or

other similar material in the load?

• Did you use fabric softener?

• Did you over dry the load of

laundry?

• Are you drying synthetic, permanent

press and blends?

Try using a fabric softener to reduce static electricity.

Over-drying a load of laundry can cause a build up of static electricity. Try

using a fabric softener or adjust your settings and use a shorter drying time.

These materials can cause static to build up in a load of dried clothes. Try

using a fabric softener.

6.Problem:The drying time is not consistent

Question

• Are you using consistent heat

settings and consistent load sizes?

The drying time for a load will vary depending on the heat setting, the type of heat

used (electric, natural or LP gas), the size of the load, the type of fabrics, the wetness

of the clothes and the condition of the exhaust ducts and lint filer.

What to Do

3 1

Part 10 TROUBLESHOOTING GUIDE

7.Problem:It takes too long for my clothes to dry

Question What to Do

• Did you properly sort your loads of

laundry?

• Are you drying large loads of heavy

fabrics?

• Are the dryer controls properly set?

• Is the lint filter clean before each

new load of laundry?

• Are the exhaust ducts clear and

properly configured?

• Is the fuse blown, or is the circuit

breaker tripped?

• Did you overload your dryer?

• Did you under load your dryer?

Separate heavy weight items from light weight items when creating loads.

Heavy fabrics take longer to dry because they tend to retain more moisture. To help

reduce and maintain more consistent drying times for large and heavy fabrics,

separate these items into smaller loads of a consistent size.

Use the appropriate control settings for the type of load you are drying.

Please confirm that the lint filter is clean prior to each new load of laundry.

Confirm through review of the appropriate sections of this manual that the exhaust

venting ductwork is properly configured. Confirm that the venting is free of

obstructions. Confirm that the outside wall dampers are moving freely, that the

dampers are not pushed in, and that nothing has been set against the dampers.

Check your home’s or laundry room’s fuse box/circuit breaker box and replace the

fuse or reset the circuit breaker. (IMPORTANT: electric dryers generally use two

fuses or breakers.)

Divide your larger load into a number of smaller loads.

If you are only drying a handful of items, add a few extra pieces to help ensure

proper tumbling action.

8.Problem:My clothes are wrinkled

Question What to Do

• Are you over drying your laundry?

• Are you removing your laundry

from the dryer soon after the

drying cycle is complete?

Over drying a load of laundry can lead to wrinkled clothes. Try a shorter drying

time, and remove items while they still retain a slight amount of moisture.

Remove your laundry from the dryer after the drying cycle ends and either hang or

fold the items.

9.Problem:My clothes are shrinking

Question What to Do

• Are you following the care

instructions for your garment? To avoid shrinkage, please carefully follow the care and use instructions for your

garment, because some fabrics will naturally shrink when washed. Other fabrics

can be washed but will shrink when dried in a dryer.

CARACTERÍSTICAS DEL PRODUCTO

CONTENIDO

PARTE 1. ESPECIFICACIONES. ..............................................................................................................................3

PARTE 2. GARANTÍA E INSTRUCCIONES DE SEGURIDAD IMPORTANTES. .................................................4-6

PARTE 3. PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA..................................................7-12

PARTE 4. INSTALACIÓN DE ACCESORIOS.. .................................................................................................13-14

PARTE 5. REQUERIMIENTOS ELÉCTRICOS PARA SECADORA ELÉCTRICA............................................15-18

PARTE 6. REQUERIMIENTOS ELÉCTRICOS PARA SECADORAS A GAS........................................................19

PARTE 7. REQUERIMIENTOS E INSTRUCCIONES SOBRE EL GAS .................................................................20

PARTE 8. REQUERIMIENTOS Y MANTENIMIENTO SOBRE EL ESCAPE ....................................................21-22

PARTE 9. USANDO SU SECADORA................................................................................................................23-28

PARTE 10. GUÍA PARA LA SOLUCIÓN DE PROBLEMAS.............................................. ...............................29-31

DESEMPEÑO EXTRAORDINARIO

Sin mencionar su incomparable gran capacidad, puede beneficiarse por su Eficiencia en

tiempo, operaciòn silenciosa y su sistema de ahorro de energìa

TINA DE ACERO INOXIDABLE

El Tambor està cubierto por metal y por polìmero para garantizar alta durabilidad y larga vida.

DISEÑO ARTÍSTICO

El moderno Diseño del Panel Frontal y su gran puerta de cristal hacen que su hogar se vea con

màs estilo.

CUIDADO DIGITAL

El control de temperatura multi nivel cuida mejor su ropa

USO SENCILLO

Una completa selecciòn de funciones amigables hacen la operaciòn del secado mucho màs

fàcil.

Parte 1 ESPECIFICACIONES

■Nombre : Secadora Eléctrica y de Gas

■Suministro de Energìa : Favor de consultar la etiqueta de medición

referente a la información detallada

■Tamaño : 27 x 29.9 x 38.7 (pulg.)

■Capacidad de la Secadora : Refiera a la etiqueta del grado

■Peso : 126(Ibs)

Las especificaciones son sujetas a cambio por el fabricante.

■ ACCESORIOS

Parrilla de secado (1) Kit para Apilar (1)

comprado separadamente

Pedestal (1)

comprado separadamente

Vea la página 26 para su uso Vea la página 13 para su uso Vea la página 14 para su uso

Parte 2

GARANTÍA E INSTRUCCIONES DE SEGURIDAD IMPORTANTES

1) Lea todas las instrucciones antes de usar el artefacto.

2) No seque artículos que hayan estado en contacto con

gasolina, solventes para lavado en seco, o cualquier

otra sustancia inflamable o explosiva, p37-ya que

despiden vapores que pueden incendiarse o explotar.

3) No permita que los niños jueguen sobre o dentro del

artefacto Es necesario que supervise de cerca a los

niños cuando utiliza el artefacto.

4) Antes de que el artefacto sea removido del servicio o

desechado, quite la puerta del compartimiento de

secado.

5) No meta la mano en el aparato si el tambor está en

movimiento.

6) No instale o almacene este artefacto donde esté

expuesto a la intemperie.

7) No fuerce los controles.

8) No repare o reemplace ninguna pieza del artefacto ni

intente darle servicio a menos que esté

específicamente recomendado en las instrucciones de

mantenimiento para el usuario

9) No use calor para secar artículos que contengan hule

espuma o materiales de textura similares al hule.

10) Limpie la malla para pelusas antes o después de

cada carga.

11) Mantenga el área alrededor de la abertura de escape

y las áreas adyacentes libres de acumulación de

pelusa, polvo y sucio.

12) El interior del artefacto y el ducto de escape deben

ser limpiados periódicamente por personal de

servicio calificado.

13) No coloque artículos que hayan sido expuestos a

aceite de cocina dentro de la secadora. Artículos

contaminados con aceite de cocina pueden

contribuir a una reacción química causante de

incendiar una carga.

14) No use suavizantes de telas o productos para

eliminar la estática a menos que sea recomendado

por el fabricante de estos productos.

INSTRUCCIONES DE CONEXIÓN A TIERRA

Este artefacto debe estar conectado a tierra. En caso de

mal funcionamiento o avería, la conexión a tierra

reduce el riesgo de choque eléctrico al proveer una ruta

de menor resistencia a la corriente eléctrica. Este

artefacto está equipado con un cordón que contiene un

conductor equipo-tierra y un enchufe con conexión a

tierra. El enchufe debe ser conectado a un tomacorriente

adecuado, debidamente instalado y conectado a tierra

de acuerdo con todos los códigos locales y ordenanzas.

ADVERTENCIA- Una incorrecta conexión del

conductor equipo-tierra puede resultar en un riesgo de

choque eléctrico.

Verifique con un electricista calificado o un técnico de

servicio si tiene alguna duda si el artefacto está

debidamente conectado a tierra.

No modifique el enchufe suministrado con el artefacto;

si éste no encajase en el tomacorriente, haga que le

instalen un tomacorriente adecuado por un electricista

calificado.

ADVERTENCIA!

Para ayudar a reducir el riesgo de choque eléctrico, incendio, o lesión personal o

daño a la propiedad cuando use su secadora, por favor sea precavido y siga las

precauciones de seguridad básicas, incluyendo las siguientes:

INSTRUCCIONES DE SEGURIDAD IMPORTANTES

GUARDE ESTAS INSTRUCCIONES

Parte 2

GARANTÍA E INSTRUCCIONES DE SEGURIDAD IMPORTANTES

• No intente encender un fósforo, o cigarrillo, o

encender ningún artefacto de gas o eléctrico.

• No toque ningún interruptor eléctrico. No use

ningún teléfono en su casa o edificio.

• Evacúe la habitación, edificio o el área de

todos los ocupantes.

• Llame inmediatamente a su proveedor de gas

desde el teléfono de un vecino. Siga

cuidadosamente las instrucciones de su

proveedor de gas.

• Si no puede contactar a su proveedor de gas,

llame al departamento de bomberos.

Para reducir el riesgo de incendio o explosión,

choque eléctrico, daño a la propiedad, lesiones

personales, o muerte cuando use este artefacto, por

favor siga todas las instrucciones e información,

incluyendo las de este manual y las instrucciones e

información suministradas por su proveedor de

gas, incluyendo las siguientes:

• No almacene o use gasolina, solventes para

lavado en seco, o cualquier otro vapor o líquido

inflamable en el área adyacente a este artefacto.

• No seque nada que alguna vez haya tenido

contacto con algo inflamable, aún después de

lavarlo.

• Ninguna lavadora puede remover completamente

el aceite. No seque ningún artículo que haya

tenido contacto con cualquier clase de aceite,

incluyendo aceite de cocinar.

• Artículos que contienen espuma, hule, materiales

similares al hule, plástico, o materiales similares

deben secarse en el tendedero o utilizando el

ciclo de aire.

• La falta de cumplimiento de estas instrucciones

puede resultar en incendio, muerte o lesiones

serias.

• Un técnico o una compañía calificada debe

efectuar la instalación y proveer el servicio a este

artefacto.

QUE HACER EN CASO DE OLER

GAS:

ADVERTENCIA!

• Mantenga los materiales y vapores

inflamables, como la gasolina, lejos de la

secadora.

• Coloque la secadora al menos 18 pulgadas

sobre el piso para instalación en el garaje.

• Si no cumple con estas instrucciones puede

resultar en muerte, explosión o incendio.

ADVERTENCIA

Parte 3

PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA

Las siguientes instrucciones le servirán de guía a través de los pasos iniciales para la preparación de su

secadora para el uso. Por favor note que cada sección de este manual proporciona información importante

sobre la preparación y uso de su secadora, y es muy importante que lea este manual completamente antes de

proceder con cualquiera instalación o con su uso. Instrucciones detalladas adicionales concernientes a las

conexiones eléctricas, conexiones del gas, y los requerimientos sobre el escape son suministrados en otras

partes de este manual.

Escoja una ubicación para su secadora donde el piso

sea sólido. Coloque la secadora al menos 18

pulgadas por arriba del piso para una instalación en

el garaje. Despuès de colocar la secadora en el lugar

deseado, asegùrese de que tenga despejado como se

muestra debajo junto con las secciones en desague y

requerimientos de Mantenciòn. Si está instalando su

secadora en una casa prefabricada o móvil, favor

refiérase al PASO 9 abajo para instrucciones

adicionales.

Ciertos mìnimos despejes son requeridos arriba,

abajo y a los lados de la unidad, como se muestran

abajo. Esos espacios mínimos requeridos están

expuestos en la imagen inferior. Por favor mantenga

estas instrucciones en su mente cuando instale en

algún closet o área restringida:

• Considere dejar un espacio para su instalación y

servicio.

• La moldura de la pared, puerta y piso pueden

necesitar despejes adicionales.

• Una pulgada extra de despeje es recomendado para

minimizar la tranferencia de ruido.

• Considere espacio para aplicaciones que acompañen

su producto.

• Para instalaciones en closet, la siguiente imagen

muestra el mínimo requerimiento de ventilación para la

puerta. Una puerta de rejillas con aperturas de

ventilación comparables son tambièn es acceptable.

* La mayoría de las instalaciones requieren un

mínimo de 5 1/2 pulgadas de espacio libre

(14 cm) detrás de la secadora para el conducto de

escape con el codo.

38.7”

(98.3 cm)

27”

(68.6 cm)

29.9”

(76.1 cm)

49.8”

(126.4 cm)

PASO 1 Colocación de la

Secadora

Agujero de

Ventilación

Agujero de

Ventilación

Parte 3

PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA

Una vez en posición ajuste las patas niveladoras de la

secadora hasta que esté nivelada de izquierda a

derecha y del frente hacia atrás. Las patas

niveladoras deben permanecer firmes en el piso y la

secadora no debe mecerse. La máxima inclinación de

la secadora de izquierda a derecha o del frente hacia

atrás no debe ser mayor de 2.5 cm (1 pulgada). Si la

secadora no está nivelada, y si la inclinación excede

los 2.5 cm (1 pulgada), la carga puede que no gire

adecuadamente y los sensores internos pueden no

funcionar correctamente. Nota: Otras secciones de

este manual también proveen información importante

sobre la ubicación y los espacios libres para su

secadora.Por favor lea este manual completamente

antes de proceder con cualquier instalación.

La puerta de su secadora puede ser instalada de

manera que abra hacia la izquierda o hacia la

derecha. Siga estos procedimientos para invertir la

dirección en que su puerta abre:

PASO 2 Procedimiento para

Invertir la Puerta

Parte 3

PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA

Además de las siguientes advertencias, por favor

refiérase a la sección del manual sobre Requerimientos y

Mantenimientodel Escape. IMPORTANTE: Para

reducir el riesgo de incendio, combustión y acumulación

de gas, la secadora debe estar ventilada hacia la

intemperie. Por favor siga las siguientes instrucciones

(y todas las otras en este manual) muy cuidadosamente.

• No use ductos de plástico o de lámina delgada.

• Utilice ducto rígido o flexible de metal de 4"

(10.2 cm) de diámetro (nota: Los materiales para

ventilación no son suministrados con la secadora, y

usted debe obtenerlos por separado para una adecuada

instalación)

• Coloque la secadora en tal posiciòn que el ducto corra

de la menor forma posible.

• Limpie los ductos viejos antes de instalar esta

secadora.

• El extremo macho de cada sección del ducto de escape

debe apuntar contrario a la secadora.

• Use las menores conyucturas posibles

• Utilice cinta selladora de ductos en todas las uniones de

ductos.

• Aísle la instalación de escape que pase a través de áreas

sin calentamiento con el fin de reducir la condensación

y la acumulación de pelusas en las paredes de la

tubería; y

• POR FAVOR TENGA CUIDADO YA QUE DE NO

INSTALAR CORRECTAMENTE EL SISTEMA DE

ESCAPE ANULARÁ LA GARANTÍA DE LA

SECADORA

ADVERTENCIA!

• Utilice material para ventilación de metal pesado

• No utilice material para ventilación de plástico.

• No utilice material para ventilación de lámina de

metal

• Si no cumple con estas instrucciones puede

resultar en muerte o incendio.

■ DIRECCIONES ALTERNAS PARA EL ESCAPE

1. Quite el tornillo y el ducto de escape.

2-1. Separe y remueva el botòn que iguala la

direcciòn de ventilaciòn deseada. (El lado

derecho no es disponible en Secadoras de

Gas) , , es el órden de trabajo.

2-2. Reconecte el ducto a la salida de la

manguera y junte el ducto a la base.

(El ducto es una parte de SVC)

3-1. Arme previamente un codo de 4 con un ducto

de 4". Envuelva la cinta selladora para ducto

alrededor de la unión.

3-2. Inserte el montaje del ducto, el codo

primero a través de la abertura lateral y

conecte el codo al ducto interno de la

secadora.

PASO 3 Conexión del Sistema

de Escape y Ventilación

1 0

Parte 3

PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA

(Secadora a Gas solamente). Además de lo siguiente, por

favor refiérase a la sección del manual sobre

Requerimientos e Instrucciones del Gas.

1. Confirme que el tipo de gas disponible en su cuarto

de lavado sea el adecuado para su secadora. La

secadora está preparada para Gas Natural con una

conexión de gas NPT de 3/8".

2. Remueva la tapa protectora de la conexión de gas

detrás de la secadora. Asegúrese de no dañar la

rosca de la tubería de la conexión de gas cuando

remueva la tapa protectora.

3. Conecte la secadora al suministro de gas en su

cuarto de lavado utilizando un conector nuevo

flexible de acero inoxidable (como se mencionó

antes, sólo use un conector nuevo flexible de acero

inoxidable si es permitido por códigos locales)

4. Asegúrese de apretar todas las conexiones entre la

secadora y el suministro de gas en su cuarto de

lavado. Abra el suministro de gas en su cuarto de

lavado y verifique todas las conexiones de la tubería

(internas y externas) para detectar fugas de gas

utilizando un detector líquido de fugas no corrosivo.

5. Para una conexión a gas LP (Petróleo Licuado),

refiérase a la sección de este manual sobre

Requerimientos e Instrucciones del Gas.

1. Conector flexible nuevo de acero inoxidable. Utilice este tipo de

conector sólo si es permitido por los códigos locales. Use un

conector de diseño AGA Certificado.

2. Conector de tubo NPT de 1/8" (para verificar la presión de

entrada de gas)

3. Válvula de Cierre de Equipo instalada a una distancia de

6’ (1.8 m) de la secadora.

4. Tubería de hierro. Más corta de 20’ (6.1 m) Use tubería de 3/8" .

Más larga de 20’ (6.1 m) - Use tubería de 1/2".

5. Conexión de Gas N.P.T de 3/8" .

A continuación encontrará advertencias e

instrucciones concernientes a la confección de la

conexión eléctrica para secadoras eléctricas.

Información detallada adicional concerniente a la

conexión eléctrica es suministrada en la sección del

manual Requerimientos Eléctricos para la Secadora

Eléctrica y es importante que usted lea esta sección

completamente, así como el resto del manual, antes de

tomar algún paso para instalar o usar esta secadora.

1. Use solamente un cordón de alimentación nuevo

listado No. 10 por U.L.(alambre de cobre

únicamente) de tres conductores clasificado para

240 Voltios (mínimo) 30 Amperios y que está

indicado de uso aceptable para una secadora de

ropa.

2. Un cordón de 4 alambres es requerido para

instalaciones y uso en casas prefabricadas (móvil) y

donde los códigos locales no permitan conexión a

tierra de este aparato a través del neutral.

3. Conecciòn Elèctrica

4. Para instrucciones adicionales de como conectar la

secadora a una fuente eléctrica, favor refiérase a la

sección de este manual sobre Requerimientos

Eléctricos para Secadora Eléctrica.

ADVERTENCIA!

• Use un cordón de alimentación nuevo aprobado

por U.L. de 30 amp.o alambre de cobre sólido

calibre 10.

• Use un liberador de tensión aprobado por UL .

• Desconecte la corriente antes de hacer las

conexiones eléctricas.

• Conecte el alambre neutral (alambre blanco o

central) al terminal central.

• El alambre a tierra alambre verde o descubierto)

debe conectarse al conector a tierra verde.

• Asegúrese de apretar todas las conexiones

eléctricas.

• Vea las instrucciones de instalación para unas

instrucciones completas.

• De no seguir estas advertencias puede resultar

en incendio o choque eléctrico.

PASO 5 Conecciòn Elèctrica

PASO 4

Conexión del Suministro

de Gas

Parte 3

PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA

Antes de usar por primera ves esta secadora, utilice

un producto limpiador para todo propósito, o una

solución de detergente y agua, con un paño húmedo

para remover de la parte interior del tambor de la

secadora /compartimiento de secado cualquier polvo

o sucio que se haya podido acumular dentro de la

secadora. Enchufe su secadora después de haber

revisado las siguientes partes en los Requerimientos

Eléctricos de su secadora.

La efectiva operación de la secadora requiere de un

flujo de aire adecuado. El flujo de aire adecuado

puede ser medido evaluando la presión estática. La

presión estática en el ducto de escape puede ser

medida con un manómetro, colocado en el ducto de

escape aproximadamente a a 2 pies (60.9 cm) de la

secadora. La presión estática en el ducto de escape

no debe exceder 0.6 pulgadas (1.5 cm). La secadora

debe ser verificada cuando está operando sin carga.

Confirmación de la Fuente de Calor en

Secadoras a Gas

Cierre la puerta al tambor / compartimiento de

secado de la secadora y después de haber

completado todos los pasos de este manual para la

instalación correcta de esta secadora, encienda la

secadora en temperatura caliente, como mejor se

describe en las instrucciones de operación provistas

con la secadora. Después que la secadora se

enciende, el encendedor resplandecerá en rojo y el

quemador principal encenderá.

Advertencia: Si no todo el aire es purgado fuera de

la línea de gas, el encendedor podría apagarse antes

de que el gas y el quemador principal se hayan

encendido. Si esto sucede, el encendedor intentará

encender el gas después de aproximadamente dos

minutos.

Confirmación de la Fuente de Calor en

Secadoras Eléctricas

Cierre la puerta al tambor / Compartimiento de

secado de la secadora y después de haber

completado todos los pasos en este manual para una

instalación correcta de esta secadora, encienda la

secadora en temperatura caliente, como mejor se

describe en las instrucciones de operación provistas

con la secadora. El aire de escape o el tubo de

escape deben calentarse después que la secadora

haya operado por tres minutos.

Medición de la Presión Estática.

0.6 pulgadas (1.5 cm)

PRESIÓN ESTÁTICA

MÁXIMA EN

COLUMNA DE AGUA

PASO 8

Flujo de Aire

PASO 7

Confirmación de la Operación

de la Fuente de Calor.

PASO 6

Preparación de la

Secadora

Man ó ro

Ducto de Escape

Termékspecifikációk

Márka:	LG
Kategória:	mosógép
Modell:	TD-V14056E

Szüksége van segítségre?

Ha segítségre van szüksége LG TD-V14056E, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek

Az Ön neve*

Az Ön e-mail címe*

Írja ide kérdését

Útmutatók mosógép LG

LG F4WR5009S1W Útmutató

5 Január 2025

LG F4WR3011S6W Útmutató

5 Január 2025

LG F4WR7011SYB Útmutató

5 Január 2025

LG F4WR7511SYW Útmutató

5 Január 2025

LG F4WR7509SYW Útmutató

5 Január 2025

LG F4X1009NWB Útmutató

5 Január 2025

LG F4WR7009S2W Útmutató

5 Január 2025

LG F4X1008NWH Útmutató

5 Január 2025

LG WTL1-85W Útmutató

2 Január 2025

LG WF-79X3 Útmutató

23 December 2024

Útmutatók mosógép

Legújabb útmutatók mosógép

Electrolux EWT1366EDW Útmutató

10 Április 2025

Miele Novotronic W 153 F Útmutató

10 Április 2025

Miele WER 875 WPS PWash & TDos & 9kg & WiFi Útmutató

10 Április 2025

Hanseatic WA 1200-5 Útmutató

10 Április 2025

Friac wa 1231 e Útmutató

9 Április 2025

Zanussi-electrolux fjs 1486 x Útmutató

9 Április 2025

Miele WSE383 WCS Útmutató

9 Április 2025

AEG-Electrolux 74604 oko lavamat Útmutató

8 Április 2025

Hotpoint NDB 10748 WA Útmutató

8 Április 2025

Whirlpool FFB 7269 BV Útmutató

8 Április 2025
