Oldal 1/48
1
INSTALLATION, MAINTENANCE
AND USE INSTRUCTIONS
FOR COOKERS
Pag.2
90x60 cm (TYPE M9/M9V)
NOTICE D’INSTALLATION, D’ENTRETIEN
ET MODE D’EMPLOI DE LA CUISINIERE A GAZ
page 14
90x60cm (MODELE M9/ M9V)
code 310504
2
PLEASE READ THE INSTRUCTIONS BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE.
These instructions are only for those countries whose symbols appear on the front of the booklet
and on the serial no. plate of the appliance.
The manufacturer may not be held liable for any damage to objects or people, resulting from the
improper or erroneous installation of the appliance.
The manufacturer is not responsible for any inaccuracies, due to printing or typing errors, in this booklet.
The drawings (in the figures) are indicative only.
The manufacturer may make product modifications when considered necessary and useful, without this
changing essential safety and operating characteristics.
HEIGHT-ADJUSTABLE FEET (figure) 1)
The feet are packed in the top box.
The feet should be installed with the cooker close to its final installation position; the feet are not safe to
move the cooker long distances.
After unpacking the cooker, lift it with your foot, to fit the cooker feet in the bases at the bottom. Slowly lower
the cooker so its weight is resting on the feet and on the assembly fixings. We recommend using a lifting
device or pallet instead of tilting the cooker.
INSTALLING THE TOEKICK PANEL (only available for some models)
After installing the feet, install the cooker skirt as shown in the pictures in Figure 2. 2
INSTALLING THE (UPSTAND) RISER
Remove the 2 screws securing the hob at the rear, as shown in (figure 3)
Put the upstand in place and secure at the bottom with the two screws, as shown in (figure 3)
Secure the middle of the upstand using the screws provided with the upstand (figure 3)
INSTALLING THE HOB RAIL AND OVEN HANDLE
The rail and handle are packed with the upstand.
The rail is only available on some models.
Assemble the hob rail and oven handle as shown in the pictures (figures 4A – 4B- 4C)
CONNECTING THE APPLIANCE TO THE GAS MAINS
Before connecting the appliance to the gas mains, make sure the data on the rating plate affixed inside the
warming drawer or at the rear of the oven correspond to those of the gas mains.
A label on the last page of this booklet and inside the warming drawer (or at the rear) of the appliance
gives information for adjusting the appliance: type of gas and operating pressure.
IMPORTANT: this appliance must be installed in compliance with current national standards in force and
used only in a well-ventilated room.
NOTE: The gas union of the appliance has a ½ cylindrical male gas thread, conforming to UNI-ISO 228-1
standards.
To connect the appliance to the gas mains using a flexible rubber pipe, an additional rubber union is
required (Figure 6 ) supplied with the appliance, conforming to the UNI 7141 standard.
ADJUSTMENT FOR DIFFERENT TYPES OF GAS
BEFORE CARRYING OUT ANY MAINTENANCE, UNPLUG THE APPLIANCE FROM THE GAS AND
ELECTRICITY MAINS
REPLACING NOZZLES FOR OPERATION WITH ANOTHER TYPE OF GAS:
To change the hob burner nozzles, proceed as follows:
1. Unplug the appliance from the mains, to avoid all electrical contact.
2. Remove the pan supports from the hob (Figure 7).
3. Remove the burner heads (Figure 7).
4. Use a 7 mm tubular hex wrench to loosen the nozzles and replace them with those suitable for the new type of
gas (Figure 8) as indicated in table no. 1.
To change the oven burner nozzle proceed as follows:
1. Remove the hob by removing screws G (Figure 9) and then the hob.
2. Loosen screw and remove the burner from its housing, taking care to avoid damaging the spark ignition and V
thermocouple (Figure 10).
3. Use a 7 mm tubular hex wrench to replace nozzle R with a nozzle suitable for the new type of gas as indicated
in table no. 1.
3
To change the grill burner nozzle proceed as follows:
1. Loosen the grill screw and remove the burner from its housing, taking care to avoid damaging the spark ignition
and thermocouple (Figure 11).
2. Use a 7m tubular hex wrench to replace nozzle R with a nozzle suitable for the new type of gas as indicated in
table no. 1.
NOTE: After replacing the nozzles, the installer shall adjust the burners as described below, seal any
regulation and pre-regulation devices, and affix the new gas regulation label, to replace the existing one.
This new label is in the bag with the spare nozzles.
TABLE NO. 1
Burner Types of Gas Pressure Nozzle
Diameter
Rater Capacity
mbar 1/100 mm. g/h l/h kw kcal/h
Natural G20 20 77 - 95 1 860
Auxiliary Butane G30 30 50 73 - 1 860
Propane G31 37 50 71 - 1 860
Natural G20 20 101 - 167 1,75 1505
Semi-Rapid Butane G30 30 66 127 - 1,75 1505
Propane G31 37 66 125 - 1,75 1505
Natural G20 20 129 - 286 3 2580
Rapid Butane G30 30 87 218 - 3 2580
Propane G31 37 87 214 - 3 2580
Natural G20 20 In 70 - 476 5 4300
Out 110
Dual Butane G30 30 In 46 334 - 4,6 3956
Out 69
Propane G31 37 In 46 328 - 4,6 3956
Out 69
(model with gas oven and gas grill with double controls)
Natural G20 20 135 - 352 3,7 3182
Oven Butane G30 30 90 269 - 3,7 3182
Propane G31 37 90 264 - 3,7 3182
Natural G20 20 115 - 191 2 1720
Grill Butane G30 30 68 145 - 2 1720
Propane G31 37 68 143 - 2 1720
(model with gas oven and gas grill with single control, or gas oven and electric grill)
Natural G20 20 150 - 429 4,5 3870
Oven Butane G30 30 90 327 - 4,5 3870
Propane G31 37 90 321 - 4,5 3870
Natural G20 20 115 - 191 2 1720
Grill Butane G30 30 68 145 - 2 1720
Propane G31 37 68 143 - 2 1720
ADJUSTING THE BURNERS
Adjusting the ”MINIMUM” of the burners:
Hob burner adjustment: follow the instructions below to adjust the minimum of the hob burners:
1. Light the burner setting the knob to the MINIMUM position (small flame).
2. Turn the knob of the tap, secured by simple pressure on the rod.
3. If the cooker does not have safety valves on the hob burners, insert a small slotted screwdriver in the hole of
the tap rod (Figure 12) and turn the choke screw to the right or left, until the burner flame is at the minimum; if
the cooker has safety valves, the choke screw is not situated on the rod hole, but on the body of the tap (Figure
13).
4. For the gas valve of dual burner the choke valve is located on the valve body (fig.14), the A srew adjust the
outer ring, the B screw adjust the inner ring.
5. Make sure the flame does not go out, when switching quickly from the MAXIMUM to the MINIMUM position.
Oven burner adjustment: follow the instructions below to adjust the minimum of the burners:
1. Unplug the appliance before making the adjustment
2. Remove the knobs
3. Remove the control panel by removing the screws from the below the panel
4. Insert the thermostat knob
5. Light the burner setting the knob to the MAXIMUM position (manual lighting with a match)
6. Close the oven door and operate the oven for at least 10 minutes.
7. Set the knob to the MINIMUM position (120°) and then remove it.
8. Use a slotted screwdriver on the choke screw (Figure 15) and, while observing the flame at the same time
through the cooker porthole, evaluate the consistency of the flame so it remains on when switching quickly from
the MINIMUM to the MAXIMUM position.
9. Reassemble the front panel, proceeding as above in point 3, in reverse
