Oldal 1/2
Page 3 Page 4Page | 2
Mirror Digital Alarm Clock
Model: W72425
DC: 010524
Power Up
Insert the included 5-Volt USB Power Cord into a power brick or
other USB powering device (not included), and then into the back
of the clock. Optional: Install 2 “AAA” batteries (not included) to
backup time and alarm settings.
Made in China
Set Time
1. Hold the SET button until the display changes to enter the
Settings Menu.
2. Press and release the UP or DOWN button to adjust the values.
3. Press and release the SET button to move to the next item.
Settings Menu Order:
• 12/24 Hour Time
• Hour
• Minutes
• Month
• Day
• Year
• Temperature ºF/ºC
Note: After 5 seconds without a button
press, the clock will return to the regular
time display.
Custom Display
Hold the UP button to choose your custom display:
• Time only
• Rotate Time (10 seconds) Calendar (3 seconds) and Indoor
Temperature (3 seconds).
TIME TEMPERATUREMONTH/DATE
Alarm Time
1. Hold the DOWN button until the display changes to enter the
Alarm Settings.
2. Press and release the UP or DOWN button to adjust the values.
3. Press and release the SET button to move to the next item.
Alarm Settings Order:
• Hour
• Minutes
• Snooze Duration
(5 to 60 minutes)
Note: The alarm will sound for one minute if not turned o or
snoozed.
Activate/Deactivate Alarm or Snooze:
Press and release the DOWN button to active or deactivate the
Alarm or Snooze. The dot above the colon indicates the alarm is
active.
Snooze:
When the alarm sounds press any button to snooze the alarm for
the previously set snooze duration. The dot above the colon will
flash while snoozing. Hold any button for two seconds to turn o
the alarm and snooze.
HOUR MINUTES SNOOZE
Display Brightness
Press and release the UP button to choose your brightness:
L- SL - Sleep mode. Offers four levels or automatic brightness based
on the ambient light. The dimmest level of illumination is offered for
sleeping.
L- AU - Automatic brightness. Offers three levels or automatic brightness
based on the ambient light.
L- 03 - Levels 01, 02, 03 of brightness.
OFF - Screen is blank and looks like a mirror, Press any button to see the
time displayed.
PM
Indicator
Alarm/Snooze
Indicator
Alarm/Snooze
Indicator
Page 6Page 5 Page 7 Page 8
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Caution: To prevent electrical shock do not use this (polarized) plug with an
extension cord, receptacle, or other outlet unless the blades can be fully inserted
to prevent blade exposure.
S A F E TY I N S TRU CTIO N S
1. Read Instructions - All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions - The safety and operating instructions should be retained for future
reference.
3. Water and Moisture - The appliance should not be used near water - for example, near
a bathub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimmimng
pool and the like.
4. Ventilation - The appliance should be situated so that its location or position does not
interfere with its proper ventilation. For Example, the appliance should not be situated
on a bed, sofa, rug or similar surface that may block the ventilation opening. Avoid fully
enclosed bookcases or cabinets that may impede the airflow through the ventilation
openings.
5. Heat -The appliance should be situated away from heat sources such as radiators, heat
registers, stoves, or other appliances (including amplifiers) that produce heat.
6. Power Sources - The appliance should be connected to a power supply only of the type
described in the operating instructions or as marked on the appliance.
7. Grounding or Polarization - Precautions should be taken so that the grounding or
polarization means of an appliance is not defeated.
8. Power Cord Protection - Power supply cords should be routed so that they are not likely
to be walked on, or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenience recepticles, and at the point where they exit from
the appliance.
9. Cleaning - The appliance should be cleaned only as recommended by the manufacturer.
10. Object and Liquid Entry - Care should be taken so that foreign objects do not fall and
liquids are not spilled into the appliance through the openings.
11. Damage Requiring Service - The appliance should be serviced by qualified service
personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain.
D. The appliance does not appear to operate normally or exhibits a marked change in
performance.
E. The appliance has been dropped, or the enclosure damaged.
12. Servicing -The user should not attempt to service the appliance beyond that described
in the operating instructions. All other servicing should be referred to qualified service
personnel.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Increase separation between equipment & receiver.
• Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other antenna or
transmitter.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized changes or modifications to this equipment. Such changes or modifications
could void the user authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or
duplicated or processed using electronic, mechanical or chemical process without the
written permission of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly
checked and corrections are included in subsequent editions. We disclaim any
responsibility for any technical error or printing error, or their consequences. All
trademarks and patents are recognized.
F C C S TAT E M E N T
Equity provides a 2-year limited warranty on this product from the date of consumer
purchase against defects for material and workmanship. During this period such defects
will be repaired, or the product will be replaced at Equity’s option, without charge. This
warranty does not cover damage caused by misuse or negligence.
ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES
OR FITNESS AND MERCHANTABILITY, ARE LIMITED IN DURATION TO A PERIOD
ENDING TWO YEARS FROM DATE OF PURCHASE.
Some states do not allow limitations on how long an implied warranty lasts so the above
limitation may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from State to State.
If your product is not working properly, please send your product, and letter explaining
the problem and $5.00 for postage and handling to:
Equity by La Crosse
Warranty Department
2830 26th St S.
La Crosse, WI 54601
www.lacrossetechnology.com/support
WA R R A N T Y & S U P P O RT
• Always purchase the correct size and grade of battery most suitable for intended
use.
• Clean the battery contacts and also those of your clock prior to battery
installation.
• Ensure the battery is installed with correct polarity (+ and -).
• Promptly remove an expired battery.
• Please help in the preservation of the envioronment and return used batteries to
an authorized depot.
• Remove the battery from the clock if you do not intend to use it for an extended
period of time.
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
CA R E & M A I N T E N A N C E
Indoor Temperature Range: 14ºF to 122ºF (-10ºC to 50ºC)
Power: USB Power Cord SG-0501000AU(required).
Optional: 2-AAA Akaline Batteries.
Dimensions: 3.14” L x 1.69” W x 3.14” H ( 8cm L x 4.3cm W x 8cm H)
S PE C I F I C AT I O N S
If you need support, Scan the QR code
or visit: bit.ly/contact_techsupport WARNING: This product can expose you to chemicals including acrylonitrile,
1, 3-butadiene, and styrene, which are known to the State of California to
cause cancer and birth defects or other reproductive harm.
For more information go to: www.P65Warnings.ca.gov
