OWNER’S L MANUA

THE FCC REGULATION WARNING (for the USA)

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

If items such as cables are included with this equipment, you must use those

included items.

s authority

to operate this equipment.

CAUTION

The normal function of the product may be disturbed by Strong Electro Magnetic

Interference. If so, simply reset the product to resume normal operation by

following the owner’s manual. In case the function could not resume, please use

the product in other location.

PRECAUTIONS

Location

Using the unit in the following locations can result in a malfunction.

• In direct sunlight

• Locations of extreme temperature or humidity

• Excessively dusty or dirty locations

• Locations of excessive vibration

•

Power Supply

Please connect the designated AC adapter to an AC outlet of the

correct voltage.

Do not connect it to an AC outlet of voltage other than that for

which your unit is intended.

Interference with other electrical devices

Radios and televisions placed nearby may experience reception

interference.

Operate this unit at a suitable distance from radios and televisions.

Care

If the exterior becomes dirty, wipe it with a clean, dry cloth. Do

not use liquid cleaners such as benzene or thinner, or cleaning

Handling

To avoid breakage, do not apply excessive force to the switches or

controls.

Keeping foreign matter out of your equipment

Never set any container with liquid in it near this equipment. If

electrical shock.

Be careful not to let metal objects get into the equipment.

1. Please make sure the KM88 is properly connected to a

computer via USB, or to a power supply via optional DC adapter.

2. Press the switch on the rear panel. The Joystick LED [POWER]

will light up.

3. Connect an external MIDI instrument to the KM88 via the USB /

MIDI OUT jacks.

4. Move the slider to set to the volume to a desired level.[VOLUME]

[POWER] switch. The Joystick

Note: When you power on the KM88, it will use the last selected

Multi and Global settings.

Kurzweil_KM88_OM03EN

Connecting to the Kurzweil KM88 Editor on a

Computer

You can use the KM88 Editor application on a computer edit

various settings and send them to the instrument for performance.

You can connect the KM88 to the application via USB.

Please refer to the application’s owner’s manual for

connection and operation details.

Note: Kurzweil KM88 Editor application :

Mac OS version: 10.12.0 or greater.

PC (Windows 10) OS version: 1809 or greater.

Packing list

• Music stand 1PC

• Music stand block 1PC

• Manual 1PC

• USB cable 1PC

Keep this manual

After reading this manual, please

keep it for later reference.

Rear Panel

1. EXPRESSION

For connecting a CC pedal.

2. SW PEDAL

For connecting a switch pedal.

3. SUSTAIN PEDAL

For connecting a sustain pedal.

4. MIDI OUT

;OPZWPUQHJRPZMVYJVUULJ[PUNHUL_[LYUHS40+0KL]PJL

5. USB

For connecting to computer.

6. POWER Jack

For connecting the power adapter (optional).

7. POWER Switch

;\YU[OLWV^LYVUVYVɈ

Button Functions

After connecting the instrument to the KM88 Editor application on a

computer, you can select and assign various functions to the 6 front panel

buttons.

1. Multi X

This function allows you to specify a Multi number which will be

selected when the button is pressed. This is useful for selecting

frequently used favorite Multis.

2. Multi + and Multi –

;OLZLM\UJ[PVUZZLSLJ[[OLUL_[VYWYL]PV\Z4\S[PPU[OLSPZ[^OLU[OL

button is pressed.

3. Transposition + and Transposition -

These functions tune the pitch of all Zones in all Multis in semitones

when the button is pressed.

4. MMC Play and MMC Stop

These functions send MMC Play or MMC Stop messages when the

button is pressed. MMC Play and MMC Stop messages can be used

to start or stop playback in connected hardware or software

sequencers (such as a hardware drum machine or a DAW on a

computer).

5. Programmable Button

;OPZM\UJ[PVUHSSV^Z`V\[VJVU[YVSH=PY[\HS:^P[JOHZZPNUTLU[40+0

CC number) when the button is pressed.

6. Mute/Activate a Zone

;OPZM\UJ[PVUHSSV^Z`V\[VZ^P[JOHAVUL»Z:[H[\ZIL[^LLU4\[LHUK

Active when the button is pressed.

7. MIDI Panic

:LUK(SS5V[LZ6ɈHUK(SS*VU[YVSSLYZ6ɈHUKYLSVHKZ[OLZLSLJ[LK

Multi.

Restoring Factory Defaults

Caution: This will delete all user Multi data. Before restoring

defaults, you may wish to use the KM88 Editor application to

ZH]LHIHJR\WÄSLVM`V\Y\ZLYKH[H;VYLZ[VYLMHJ[VY`KLMH\S[Z

hold down the rightmost key on the keyboard then power on

the KM88. Keep holding down the rightmost key until all of the

front panel buttons light. The KM88 will reset to factory default

settings, and delete all user Multi data.

:WLJPÄJH[PVUZ

Keyboard

RPHA - 88 fully-weighted Real Piano Hammer-Action Keys

Multis

128 (8 factory preset + 120 user editable)

Power

+*=(

Dimension (L W H)_ _

__TT

Weight

18.5 kg

Front Panel

1. VOLUME Slider

Adjust the master volume. This slider is programmable via the

KM88 Editor application.

2. Buttons

These buttons are programmable via the KM88 Editor application.

)`KLMH\S[[OLI\[[VUZHKQ\Z[;YHUZWVZP[PVU

3. Joystick

This Joystick is used to control pitch bend (when moving

horizontally) and modulation (when moving vertically).

Termékspecifikációk

Márka:	Kurzweil
Kategória:	billentyűzet
Modell:	KM88
