Refrigerat or
INSTRUCTION MANUAL
KI130SD
General
This type of refrigerator is widely used in places such as hotels, offices, student dormitories and
houses. It is mostly suitable for refrigerating and preserving foods such as fruits and beverages. It
enjoys the advantages of being small in size, lightweight and low electricity consumption and easy to
use.
Instructions for Installation
1. Do not tilt the refrigerator for more than 45 degrees of its upright position during moving. Do not
apply force on parts such as condenser and door to prevent the refrigerator from deforming, or else it
will influence its performance.
2. Let the refrigerator have enough space to work well.
3. Do not install it in high temperatures of humidity, place so as to avoid being damaged, dampened
and rusted.
Cautions for Safety
1. Before the refrigerator is plugged in, check that the electricity voltage to be used fits the same as
the rated voltage. The power plug should have an independent socket. The adapter may cause the
socket to overheat.
2. Do not store flammable materials such as ether, benzene, LP gas and glue etc in the refrigerator.
3. Do not splash water on the refrigerator, it may cause a malfunction or electric shock.
4. When gas leaks from its container, do not pull the plug out or plug it in, it may cause sparks and
fire.
Instructions for Use
1. When operating the refrigerator for the first time, run it without loading any food until it is at the
desired temperature. Usually it takes 2 3 hours, then set the thermostatic dial at the setting desireor d
and put foods in the refrigerator.
2. The temperature of the refrigerator can be adjusted by turning the thermostat dial. A medium
setting of the thermostat dial is the most suitable for general operation. Set the thermostatat“6”only
when ice cubes are made or frozen food is stored in the freezing compartment.
3. Defrost the freezing compartment whenever the layer of frost on the surface of the evaporator
reaches 3 4 mm. When defrosting remove all food and ice cube trays and set the thermostat at the or
“OFF”position.Putthedriptrayundertheevaporatortocollectmeltedwater.Afterthefrosthas
melted, discard the melted water and dry up the interior of the refrigerator. The refrigerator can then
be restarted by turning the thermostat to the desired setting.
4. Instruction r making and removing ice cubes. fo
Fill water into the ice making case below the graduated line, put it into the freezing compartment, and
thensetthethermostatat“6”.Ittakesabout2 or 3 hours to make ice cubes. Ice cubes can be
removed by twisting the ice making case. Do not cut up and down, otherwise it may be broken.
Cautions for Use
1. The more food stuff put in or the more and longer the door is opened, the more it needs electric
consumption, which may lead malfunction.
2. It is best not to place objects which are too heavy, pointed or corrosive the table board. on
3. Re-plugging in the power plug at the interval of over ten minutes.
4. Do not store bottled drink in the freezer, so as to prevent from being broken and damaging the
refrigerator.
5. Open the door as little as possible during power-cut.
6. When defrosting, never use any sharp or metallic objects to remove the frost on the surface of the
evaporator as it will damage the evaporator.
7. Do not touch foods and containers in the freezing compartment with wet hands to prevent frostbite.
Maintenance
1. While cleaning the refrigerator, pull out the electric power plug, rub carefully with a piece of cloth
soaked with natural cleanser then wipe with clean water. The abrasive cleaning power, alkali cleansers,
chemical cloth, thinner, alcohol, acid petroleum product and hot water are not suitable for cleaning the
refrigerator; they may damage the painting cover and plastics.
2. door gasket is dirty and fogged easily, so clean it frequently. The
3. If the refrigerator is out of use for a long time, please pull out the plug, clean and dry the freezing
compartment then close the door tightly.
The following cases are not malfunctio ns
1. A flowing water sound:
Flowing water sound will be heard under normal operation.
2. Outside condensation:
Outside condensation is normal in high humidity condition. You may wipe it up yourself.
3. It takes some time for the temperature of the freezer and refrigerator compartments to become cold
after the refrigerator starts to operate: If the temperature of the two compartments is higher while the
refrigerator is operating, it takes some time for the temperature of the two compartments to become
cold. If the environmental temperature is higher, it takes a long time to make the compartments cold.
4. The surface of the compressor becomes hot:
The surface of the compressor may become hot under normal operation. Do not touch it with your
hands.
Methods of inspecting a malfunction
In any case of malfunction, please inspect and dispel it according to the methods shown in the
following table.
case
Inspection
Not
refrigerating
Is there no electric current?
Is the voltage normal or not?
Has the socket fused?
Has the plug been put in effectively?
