Oldal 1/8

HU60

HU80

230Vac - 50Hz

Exhausting cooker hood. The equipment is constructed in

accordance with European Standards and with the requirements

included in the following Directives: 2006/95EC ( Low Voltage

Directive), 2004/108 (Electromagnetic Compatibility).

1 INSTALLATION

Read the instruction manual before installing and/or using the

hood .

In order that the minimum distance between the supporting

surface for the cooking pots on gas hob and low-voltage

components present in the hood is at least 65cm as required by

the regulations in force, it is necessary that the lower part of the

hood is at least 60cm away from the work top.

If the mounting instructions of the gas cooker indicate a wider

distance, respect it. The unit must not be mounted above cookers

tted with top radiant plate.

Respect all the air discharge regulations.

The air must not be discharged in a pipe used to discharge

exhaust fumes produced by gas- fed equipments or fuel-fed

equipments (this does not apply to ltering hoods).

The room must be adequately ventilated when the hoods is used

together with other gas-fed or fuel-fed equipments.

The hood is equipped with all the necessary fastenings for its

installation, which are suitable for most surfaces. Anyway, ask

to a professional to verify that the installation surface is strong

enough. Installation must be carried out by qualied installers

according to present regulations.

For an easy access, it is advisable to move possible furniture

under the installation area. For mounting the hood follow the

illustrations in .Fig. 1

To remove the bottom panel follow the illustrations on Fig. 2

To install the cover follow illustrations on Fig. 3

2 ELECTRICAL CONNECTIONS

This equipment must be connected to a grounding plant. Two

types of electrical connection can be used:

• Using a standard plug to be connected to the power cable

and inserted in a mains socket which must be accessible (so

that the plug can be disconnected when servicing is carried

out). Make sure that the plug is accessible also after the

complete installation of the equipment.

• By means of a xed mains connection, tting a bipolar

switch, which ensures the disconnection, with an opening

distance of the contacts allowing a complete disconnection

on the conditions of the overvoltage III category, according

to installation regulations. The ground connection (yellow-

green wire) must not be interrupted.

Refer to the plate inside the hood for the mains voltage and

frequency ratings.

3 USE

This cooker hood can be employed as exhausting or ltering.

Exhausting (Fig. 4). The carbon lters should not be installed on

the hood in exhausting version.

Kitchen smokes are driven outside through a ue joined to the

exhaust pipe ue connector..

Pipes must be communicating with the exterior of the house. The

diameter of the outlet of the hood is 150mm. A 150-125 reduction

is provided with the hood.

This pipe must not under any circumstances be connected to

cooker, boiler or burner exhaust pipes, etc.

Filtering (Fig. 5). The fumes pass through the carbon lters to be

puried and recycled into the kitchen through a pipe connected

to the outlet of the hood up to the hole on the top of the cabinet.

This hole must be free and communicating with the kitchen.

In the ltering version you must install the two carbon lters on

the sides of the aspirator. To install the carbon lters you must

rst remove the metal grease lters (Fig. 6) and then install

carbon lters by turning them counterclockwise (Fig. 7).

4 OPERATION

The hood is supplied with a multispeed motor.

The hood should be run at low speed under normal conditions

and at higher speeds only when there is a heavy build-up of

fumes or odours.

Ideally, the hood should be switched on as soon as cooking is

started and then kept on until all odours have been eliminated.

The controls consist of these commands. Press TL to turn on the

light, press T1 to swich on the hood at rst speed and to switch

off the aspirator, press T2-T3-T4 to select functioning speeds.

By pressing of the command T1 the motor starts running at the

1st speed. The commands

T2-T3-T4 switch the motor on respectively at the 2nd, 3rd and

4th speed. In order to switch the motor off press T1 once if set

at the 1st speed, twice if set at the 2nd, 3rd and 4th speed. With

the button T4, select the maximum speed of the extraction fan

for 5 minutes (LED blinking), after which the extraction fan will

automatically switch to the 3rd speed.

Adjustable and delayed self switching off

While the hood is working, keep the TL command pressed until

all LEDs start blinking. By pressing one of the LEDs (T1, T2, T3,

T4) you can program the delayed self switching off, as follows:

T1 corresponds to 5 minutes

T2 corresponds to 10 minutes

T3 corresponds to 15 minutes

T4 corresponds to 20 minutes

During the time of the self switching, you can change and set

any speed.

Filters maintenance reminder

Aluminium anti-grease lters

Once the hood is switched off, after 30 hour functioning, all the

leds of the speed LEDs switch on with a xed light for 30 seconds

to remind that aluminium anti-grease lter need cleaning.To set

the timer to zero, keep the button T4 pressed with the aspirator

switched off, otherwise the timer will remain set on 30 hour

functioning and the reminder will occur again when the hood is

switched off again.

Charcoal lter (for ltering hoods)

Once the hood is switched off, after 120 hour functioning, all

LEDs blink for 30 seconds to remind that the charcoal lter need

cleaning.

To set the timer to zero, keep the button T4 pressed with the

aspirator switched off, otherwise the timer will remain set on

120 hour functioning and the reminder will occur again when the

hood is switched off again.

INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS FOR COOKER HOODS

MODEL HU60-HU80 230 Vac - 50 Hz

5 MAINTENANCE

Always disconnect the hood from the mains before carrying out

any maintenance or cleaning operation

In order to remove the remaining glue or any impurity, the cooker

hood must be cleaned immediately after installation and after

having removed the protective lm.

The cooker hood must be cleaned frequently both internally and

externally (at least once a month).

Do not let dirt gather on the inner and outer surfaces of the hood.

To clean the exterior of the hood do not use either acid or basic

products, or abrasive sponges.

Clean the hood with a sponge dampen in warm water and a little

quantity of neutral detergent

(for example dishwasher detergent), in order to remove possible

particles of grease. Rinse with a damp cloth, removing all the

detergent carefully, following the satin nish direction on the steel

surface.

Drying is very important, especially in areas where water is

particularly hard and leaves limestone.

Particular attention should be paid to the metallic anti-grease

lters that are designed to trap particles of fat contained in the

fumes. The metallic anti-grease lters must be washed at least

once a month with detergent in hot water (or in the dish-washer).

ATTENTION: the grease collected in the lters can easily

catch re and it is therefore

extremely important to clean the metallic lters on a regular basis

as per instructions.

The charcoal lters are designed to collect unpleasant

odours in the cooking fumes. The air is then released

puried in the environment. The charcoal lters must not

be washed, but replaced 2 or 3 times a year, depending on

how much the hood is used. New lters are to be requested

directly to the manufacturer. In order to replace the charcoal

lters, you should remove the anti-grease lters. Your have

then to take off the charcoal lters placed at the two sides

of the aspirator. Turn the lters until they unfasten from

aspirator (Fig.7). Invert the operation in order to install the

new charcoal lters.

The hood features a LED light that, in addition to offering a

good lighting and a signicant energy savings, is guaranteed

to last on average 10 times more than traditional lights. For

replacement, contact the Assistance Service.

6 WARNINGS

The present instruction manual is an integral part of the appliance

itself, therefore it must be carefully kept and ALWAYS accompany

it, even in case of its assignment to another owner or user or in

case the cooker hood is moved to another installation plant.

Any eventual adjustment to the electrical system, which may be

necessary to install the cooker hood, must be carried out only

by competent people. Any repair carried out by no competent

people may cause damages. For any repair or needed technical

action make reference to a Technical Assistance Center, which is

authorized to carry out the replacement of the spare parts.

Always make sure that all the electrical parts (lights, exhaustion

unit) are disconnected when the appliance is not in use.

By storms take off the main switch of the house electrical system.

The using of the cooker hood must not be other than the use of

exhausting units for cooking damps on domestic kitchens. The

manufacturer does not accept any liability for damages caused

by people, animals or things, by installation and maintenance

mistakes or by any illegitimate use.

Make sure that the voltage (V) and the frequency (Hz) ratings

indicated on the plate inside the cooker hood correspond to the

ones available in the installation place.

We remind that the use of products functioning with electrical

energy implies the observance of some essential security rules,

as follows:

• This equipment is not intended for people (children

included) with reduced mental or motor capacities, with lack

of experience or knowledge, unless they are supervised or

unless a person responsible for their security, gives them

instructions regarding the use of the equipment. Children

must be supervised in order to be sure that they do not play

with the equipment.

• Any cleaning action is forbidden if the appliance hasn’t been

disconnected from the main power supply and if the main

switch of the house electrical system is not off. If cleaning

is not carried out according to these instructions, a re may

break out.

• Do not pull, take off or twist the cable coming out from the

appliance, even though this has been disconnected from the

main power supply.

• Do not sprinkle or throw any water directly on the appliance.

• Do not stick any sharp tool inside the exhausting holes and

into the air discharge.

• Do not take out the lters in order to reach the internal

sides of the appliance in case the main switch of the house

electrical system is not off.

• Do not singe or ambé directly underneath the cooker hood.

Take particular care when frying to ensure that the oil does

not catch re.

Termékspecifikációk

Márka:	Ilve
Kategória:	Páraelszívó
Modell:	HU80

Szüksége van segítségre?

Ha segítségre van szüksége Ilve HU80, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek

Az Ön neve*

Az Ön e-mail címe*

Írja ide kérdését

Útmutatók Páraelszívó Ilve

26 December 2024

26 December 2024

26 December 2024

26 December 2024

26 December 2024

26 December 2024

30 Augusztus 2024

Ilve IVG901X1 Útmutató

29 Augusztus 2024

Ilve X370GM Útmutató

29 Augusztus 2024

Ilve XBBQ120 Útmutató

29 Augusztus 2024

Útmutatók Páraelszívó

Legújabb útmutatók Páraelszívó

Silverline SOW 900 S Útmutató

30 Március 2025

Atag WM 5 Útmutató

30 Március 2025

Smeg CA60EPX Útmutató

30 Március 2025

CATA C GLAS H BK Útmutató

30 Március 2025

Smeg STH650X Útmutató

30 Március 2025

Elica PIX BL/F/42 Útmutató

30 Március 2025

Electrolux KCC84450CZ Útmutató

30 Március 2025

Etna 4191 inox Útmutató

29 Március 2025

Miele da 249 1 Útmutató

29 Március 2025

Miele DA 420 UL Útmutató

29 Március 2025
