Fingerprint Access Control Terminal
User Manual
Fingerprint Access Control Terminal·
·
·
··User Manual
i
User Manual
© 2018 Hangzhou Hikvision Digital Technology Co., Ltd.
This manual is applied for ngerprint access control terminal.
Name
Model
Fingerprint Access
Control Terminal
DS- T 3F K1 80
DS MF- T 3K1 80
DS-K1T803MF(L)
DS- T 3 K1 80 EF
DS-K1T804F
DS-K1T804F-1
DS MF-K1T804
DS MF-K1T804 -1
DS-K1T804 EF
DS-K1T804 -1 EF
It includes instrucons on how to use the Product. The soware embodied in the Product is
governed by the user license agreement covering that Product.
About this Manual
This Manual is subject to domesc and internaonal copyright protecon. Hangzhou Hikvision
Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be
reproduced, changed, translated, or distributed, parally or wholly, by any means, without the
prior wrien permission of Hikvision.
Trademarks
and other Hikvision marks are the property of Hikvision and are registered
trademarks or the subject of applicaons for the same by Hikvision and/or its aliates. Other
trademarks menoned in this manual are the properes of their respecve owners. No right of
license is given to use such trademarks without express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL.
HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE
USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION
CONTAINED HEREIN. YOUR USE OF THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE
WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY
AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER
ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY
WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS
THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS
USED WITH ILLEGITIMATE PURPOSES.
Fingerprint Access Control Terminal·
·
·
··User Manual
ii
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Support
Should you have any questions, please do not hesitate to contact your local dealer.
Fingerprint Access Control Terminal·
·
·
··User Manual
iii
Regulatory Informaon
FCC Informaon
Please take attenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the RE Direcve 2014/53/EU, the EMC Direcve 2014/30/EU, the RoHS
Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more informaon see:
www.recyclethis.info
Fingerprint Access Control Terminal·
·
·
··User Manual
iv
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery informaon. The battery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier or to a
designated collecon point. For more informaon see: www.recyclethis.info
Use only power supplies listed in the user instructions:
Model
Manufacturer
Standard
DSA-12PFT-12FUK 120100
Dee Van Enterprise Co., Ltd.
BS
DSA-12PFT-12FAU 120100
Dee Van Enterprise Co., Ltd.
AS
DSA-12PFT-12FIN 120100
Dee Van Enterprise Co., Ltd.
IS
DSA-12PFT-12FUS 120100
Dee Van Enterprise Co., Ltd.
IEC
DSA-12PFT-12 FBZ 120100
Dee Van Enterprise Co., Ltd.
NBR
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB- B) standards requirements. 3(
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d'en compromettre le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émetteur radio peut
fonconner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à
l'intenon des autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communicaon sasfaisante.
Fingerprint Access Control Terminal·
·
·
··User Manual
v
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
Safety Instruction
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Warnings Cauons and :
Warnings: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Warnings
All the electronic operaon should be strictly compliance with the electrical safety regulaons,
fire prevenon regulaons and other related regulaons in your local region.
Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
Please make sure that the power has been disconnected before you wire, install or dismantle
the device.
When the product is installed on wall or ceiling, the device shall be rmly xed.
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauons
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiation. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operating temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
Warnings Follow
these safeguards to
prevent serious
injury or death.
Cauons Follow
these precauons
to prevent
potenal injury or
material damage.
Fingerprint Access Control Terminal·
·
·
··User Manual
vi
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the battery manufacturer.
You can view the device License via the website:
hp://opensource.hikvision.com/Home/List?id=46
Fingerprint Access Control Terminal·
·
·
··User Manual
vii
Table of Contents
Chapter 1 Overview ................................................................................................................. 1
1.1 Introducon 1 .........................................................................................................................
1.2 Main Features 1 ......................................................................................................................
1.2.1 -K1T803F/MF/EF/MF(L) and DS-K1T804F/MF/EF Features 1 DS .........................................
1.2.2 -K1T804F/MF/EF-1 Features DS ........................................................................................ 2
1.3 Appearance .......................................................................................................................... 3
1.4 Keypad Descripon 4 ..............................................................................................................
Chapter 2 Installaon .............................................................................................................. 5
Chapter 3 Device Wiring .......................................................................................................... 6
3.1 Terminal Descripon ............................................................................................................ 6
3.2 Device Wiring ....................................................................................................................... 8
3.2.1 External Device Wiring Overview (Without Secure Door Control Unit) .......................... 8
3.2.2 External Device Wiring Overview (With Secure Door Control Unit) ................................ 9
Chapter 4 Basic Operaon .....................................................................................................10
4.1 Device Acvaon ................................................................................................................ 10
4.1.1 Acvang via Device ...................................................................................................... 10
4.1.2 Acvang via SADP Soware ......................................................................................... 11
4.1.3 Acvang via Client Soware ........................................................................................13
4.2 Login ................................................................................................................................... 16
4.3 Parameters Conguraon .................................................................................................. 16
4.3.1 Communicaon Sengs ................................................................................................ 16
4.3.2 System Sengs .............................................................................................................. 19
4.3.3 Seng Time ................................................................................................................... 23
4.4 User Management .............................................................................................................. 23
4.4.1 Adding User .................................................................................................................... 24
4.4.2 Managing User ............................................................................................................... 28
4.5 Access Control System Conguraon ................................................................................. 29
4.5.1 Congure Access Control Parameters ............................................................................ 30
4.5.2 Conguring Holiday Group ............................................................................................. 31
4.5.3 Conguring Week Plan ................................................................................................... 33
4.5.4 Conguring Schedule Template .....................................................................................35
Fingerprint Access Control Terminal·
·
·
··User Manual
viii
4.6 Aendance Conguraon .................................................................................................. 37
4.6.1 Conguring Department ................................................................................................ 37
4.6.2 Conguring Shi ............................................................................................................. 39
4.6.3 Conguring Holiday ........................................................................................................ 42
4.6.4 Conguring Shi Schedule ............................................................................................. 44
4.6.5 Report Management ...................................................................................................... 48
4.7 Other Management ............................................................................................................50
4.7.1 Transferring Data ............................................................................................................ 50
4.7.2 Searching Log ................................................................................................................. 51
4.7.3 Tesng ............................................................................................................................52
4.7.4 System Informaon ........................................................................................................ 52
Chapter 5 Client Operaon ....................................................................................................54
5.1 Funcon Module ................................................................................................................ 54
5.2 User Registraon and Login ............................................................................................... 54
5.3 System Conguraon ......................................................................................................... 56
5.4 Access Control Management ............................................................................................. 56
5.4.1 Adding Access Control Device ........................................................................................ 58
5.4.2 Viewing Device Status .................................................................................................... 68
5.4.3 Eding Basic Informaon ............................................................................................... 69
5.4.4 Network Sen gs............................................................................................................ 70
5.4.5 -485 Sengs RS ............................................................................................................... 72
5.4.6 Wiegand Setngs ........................................................................................................... 73
5.4.7 M1 Card Encrypon ....................................................................................................... 74
5.4.8 Remote Conguraon .................................................................................................... 74
5.5 Organizaon Management ................................................................................................84
5.5.1 Adding Organizaon ....................................................................................................... 84
5.5.2 Modifying and Deleng Organizaon ............................................................................ 84
5.6 Person Management .......................................................................................................... 85
5.6.1 Adding Person ................................................................................................................ 85
5.7 Schedule and Template ...................................................................................................... 95
5.7.1 Week Schedule ............................................................................................................... 96
5.7.2 Holiday Group ................................................................................................................97
Fingerprint Access Control Terminal·
·
·
··User Manual
ix
5.7.3 Template ......................................................................................................................... 99
5.8 Permission Conguraon ................................................................................................. 101
5.8.1 Adding Permission ........................................................................................................ 102
5.8.2 Applying Permission ..................................................................................................... 103
5.9 Advanced Funcons ......................................................................................................... 104
5.9.1 Access Control Parameters ........................................................................................... 105
5.9.2 Card Reader Authencaon ......................................................................................... 107
5.10 Searching Access Control Event .......................................................................................109
5.10.1 Searching Local Access Control Event ...................................................................... 110
5.10.2 Searching Remote Access Control Event .................................................................. 110
5.11 Access Control Event Conguraon ................................................................................. 110
5.11.3 Access Control Event Linkage ................................................................................... 111
5.11.4 Event Card Linkage ................................................................................................... 112
5.12 Door Status Management ................................................................................................ 113
5.12.1 Access Control Group Management ........................................................................ 114
5.12.2 Controlling Door Status ............................................................................................ 115
5.12.3 Conguring Status Duration for Door 117 ......................................................................
5.12.4 Real-me Card Swiping Record ................................................................................ 118
5.12.5 Real-me Access Control Alarm ............................................................................... 119
5.13 Arming Control ................................................................................................................. 121
5.14 Time and Aendance ....................................................................................................... 121
5.14.1 Shi Schedule Management .................................................................................... 122
5.14.2 Aendance Handling ................................................................................................ 129
5.14.3 Advanced Sengs .................................................................................................... 133
5.14.4 Aendance Stas cs................................................................................................ 138
Appendix A Tips for Scanning Fingerprint ............................................................................... 142
Appendix B Input Method Operaon ...................................................................................... 143
Appendix C Attendance Record Delete Rule ............................................................................ 144
C.1 Enabling Record Delete .................................................................................................... 144
C.2 Disabling Record Delete ................................................................................................... 144
Appendix D Overview of Device Parameters ............................................................................ 145
D.1 Access Control Terminal Parameters ................................................................................ 145
Fingerprint Access Control Terminal·
·
·
··User Manual
x
D.2 Aendance Parameters .................................................................................................... 146
Appendix E Attendance Report Table ...................................................................................... 147
E.1 Descripon of Attendance Report File Name .................................................................. 147
E.2 Aendance Report Table Descripon .............................................................................. 148
Appendix F Custom Wiegand Rule Descripons ...................................................................... 151
Fingerprint Access Control Terminal·
·
·
··User Manual
1
Chapter 1 Overview
1.1 Introduction
DS-K1T803 Series and DS-K1T804 Series Fingerprint Access Control
Terminal is designed with a 2.4-inch LCD display screen. Oine
operaon, wired network (TCP/IP) and wireless network
transmission modes are supported as well. (The models with -1 do
not support the wireless network funcon.)
Note: The gure on the le is for reference only. Refer to the
actual product as the standard.
1.2 Main Features
1.2.1 -K1T803F/MF/EF/MF(L) and DS-K1T804F/MF/EF Features DS
Doorbell ringtone setngs funcon
2.4-inch LCD display screen
Transmission modes of wired network (TCP/IP) and wireless network
Max. 3,000 users, 3,000 ngerprints and 100,000 access control events storage
Export the report and upgrade the device via the USB disk.
Adopts the opcal ngerprint module, supporng 1:N mode (ngerprint, card + ngerprint)
and 1:1 mode (card + ngerprint) (DS-K1T803F and DS-K1T804F does not support swiping
card.)
Terminal authencaon and user authencaon
Mulple authencaon modes card, ngerprint, card + ngerprint, card + password, :
ngerprint + password, card + ngerprint + password, and so on. (DS-K1T803F and
DS-K1T804F does not support swiping card.)
EM card reading ( -K1T803EF/DS-K1T804 ) DS EF
Mifare card reading, including card No. reading (DS-K1T803MF/ -K1T804 ) DS MF
CPU card reading, including CPU card serial No
Secure door control unit accessing via RS-485 connection
Fingerprint Access Control Terminal·
·
·
··User Manual
2
Tampering detecon, unlocking overme alarm, invalid card swiping over mes alarm,
duress card alarm, and so on
Accurate data and me display provided by built-in electronic clock
Check the device running status via the Watchdog. When excepon status occurs, the
system will reboot automacally
Data can be permanently saved aer power-o
Remotely control via the iVMS-4200 client soware
Collects ngerprint informaon locally or via ngerprint recorder
Note: Device with the model of DS-K1T803MF(L) supports collecng or applying ngerprint
pictures locally.
Supports the third party arming
Supports transming data via EHome to realize the whole network transming.
Acvates via device
1.2.2 -K1T804F/MF/EF-1 Features DS
Doorbell ringtone setngs func on
2.4-inch LCD display screen
Transmission modes of wired network (TCP/IP)
Max. 3,000 users, 3,000 ngerprints and 100,000 access control events storage
Export the report and upgrade the device via the USB disk.
Adopts the opcal ngerprint module, supporng 1:N mode (ngerprint, card + ngerprint)
and 1:1 mode (card + ngerprint) ( -K1T804-1 does not support swiping card.) DS
Terminal authencaon and user authencaon
Mulple authencaon modes card, ngerprint, card + ngerprint, card + password, :
ngerprint + password, card + ngerprint + password, and so on. (DS-K1T804-1 does not
support swiping card.)
EM card reading ( -K1T804 -1) DS EF
Mifare card reading, including card No. reading (DS-K1T804 -1) MF
CPU card reading, including CPU card serial No.
Secure door control unit accessing via RS-485 connection
Tampering detecon, unlocking overme alarm, invalid card swiping over mes alarm,
duress card alarm, and so on
Accurate data and me display provided by built-in electronic clock
Check the device running status via the Watchdog. When excepon status occurs, the
system will reboot automacally
Data can be permanently saved aer power-o
Remotely control via the iVMS-4200 client soware
Collects ngerprint informaon locally or via ngerprint recorder
Supports the third party arming
Fingerprint Access Control Terminal·
·
·
··User Manual
3
Supports transming data via EHome to realize the whole network transming.
Acvates via device.
1.3 Appearance
Table 1-1 Descripon of DS-K1A801 Series Model
No.
Descripon
1
Keypad
2
Door Bell Buon
3
Fingerprint Reading Module
4
2.4-inch LCD Display Screen Indicator
5
USB Interface/Reset Buon (Inside of the Cover)
6
Tamper-proof Buon
7
Ethernet Port
8
RS-485/Wiegand Wiring Terminal
9
12V Power Interface
10
Door Lock Wiring Terminal
11
Alarm Wiring Terminal
Fingerprint Access Control Terminal·
·
·
··User Manual
4
1.4 Keypad Description
Table 1-2 Descripon of Keys
No.
Descripon
1
Exing Key: Press the buon to exit the menu.
2
Direcon Keys: Use to move the cursor in the menu.， ， ，
3
Numeric Keys/Leer Keys:
Press to input numbers or leers.
Long press Key 6 for 3s to enter One-Touch Wi-Fi Sengs mode. You can
set the Wi-Fi for the device via the App on the phone. Press Key 6 again to
exit the mode aer seng Wi-Fi completely.
Note: The models with -1 do not support One-Touch Wi-Fi Sengs mode.
4
OK Key: Press to conrm operaons. Press and hold the key for 3s to login the
main interface.
5
Deleng Key:
Press to delete the leers or numbers one by one in the textbox.
Long-press to clear all contents in the textbox.
6
Eding Key: Press to enter the eding status.
Press to shi among Chinese, numbers/lowercases, numbers/uppercases and
symbols.
Fingerprint Access Control Terminal·
·
·
··User Manual
5
Chapter 2 Installation
Before You Start:
Make sure that the device in the package is in good condition and all the assembly parts are
included.
Make sure that the wall is strong enough to withstand three times the weight of the device.
Steps:
1. Install 120 86 gang box into the wall. Or
2. Route the cables through the cable hole of the
mounting plate.
3. Secure the device mounting plate on the gang
box with two screws (supplied).
4. Connect the corresponding cables.
5. Align the terminal with mounting plate.
Push the terminal in the mounting plate
from bottom up Fasten the terminal with .
the buckles on the plate.
4. Tighten the screws to fix the terminal on the
mounting plate and complete the installation.
Note: The pictures in this documentation are for references only, refer to the actual product.
Fingerprint Access Control Terminal·
·
·
··User Manual
6
Chapter 3 Device Wiring
3.1 Terminal Description
Fingerprint Access Control Terminal·
·
·
··User Manual
7
Table 3-1 Terminal Description
Line
Group
No.
Funcon
Color
Terminal
Name
Descripon
Line
Group A
A1
Power Input
Red
+12V
12V DC Power Supply
A2
Black
GND
GND
Line
Group B
B1
Alarm Input
Yellow/Blue
IN1
Alarm Input 1
B2
Yellow/Black
GND
GND
B3
Alarm Output
Yellow/Purple
NC
Alarm Output Wiring
B4
Yellow/Brown
COM
B5
Yellow/Red
NO
Line
Group C
C1
RS-485
Communication
Port
Yellow
485 +
RS-485 Wiring
C2
Blue
485 -
C3
Wiegand
Green
W0
Wiegand Wiring 0
C4
White
W1
Wiegand Wiring 1
C5
Orange
WG_OK
Wiegand
Authenticated
C6
Purple
WG_ERR
Wiegand
Authentication Failed
C7
Brown
WG_ BEEP
Tampering Alarm
Wiring
C8
Grey
WG_TAMP
ER
Buzzer Wiring
C9
Black
GND
GND
Line
Group D
D1
Lock
White/Purple
NC
Lock Wiring
D2
White/Yellow
COM
D3
White/Red
NO
D4
Yellow/Green
SENSOR
Door Contact Signal
Input
D5
White/Black
GND
GND
D6
Yellow/Grey
BUTTON
Exit Door Wiring
Line
Group E
E1
Door Bell
White/Brown
BELL+
Door Bell Wiring
Fingerprint Access Control Terminal·
·
·
··User Manual
8
3.2 Device Wiring
3.2.1 External Device Wiring Overview (Without Secure Door Control Unit)
Note: The external power supply and the access control terminal should use the same GND cable.
Fingerprint Access Control Terminal·
·
·
··User Manual
9
3.2.2 External Device Wiring Overview (With Secure Door Control Unit)
Note: The external power supply and the secure door control unit should use the same GND cable.
Fingerprint Access Control Terminal·
·
·
··User Manual
10
Chapter 4 Basic Operation
The suggested working ow is as follows:
Device Activation: Acvate the device before rst using.
Login: Hold the OK buon for 3s to login the device main interfac e.
Parameters Configuration: Congure the communicaon, the system, and the me.
User Management: Add, edit and delete the users in the ngerprint access control terminal. You
are able to set the user ID No. name, card number ngerprint, password, department, etc.
Access Control Configuration: Congure the access control parameters and control the door
status.
Attendance Configuration: Congure the aendance parameters and control the users
aendance.
Note: The device has congured the default department, the default shi, the default shi
schedule and the default system informaon. You are able to use the device directly after adding
the user.
4.1 Device Activation
Purpose:
You should acvate the device before the rst login. After powering on, the system will switch to
Device Acvaon interface.
Acvaon via the device, SADP tool and the iVMS-4200 client soware are supported.
The default values of the terminal are as follows:
The default IP address: 192.0.0.64
The default port No.: 8000
The default user name: admin
4.1.1 Activating via Device
If the device is not acvated before rst login, the system will enter the Device Acvaon interface
aer powering on.
Fingerprint Access Control Terminal·
·
·
··User Manual
11
Steps:
1. Create a device password for acvaon.
2. Conrm the password.
3. Press the OK key to acvate the device.
Note: For details about entering and operang the input method, see Appendix B Input Method
Operaon.
STRONG PASSWORD RECOMMENDED– W highly recommend you create a strong e
password of your own choosing (using a minimum of 8 characters, including upper case
leers, lower case leers, numbers, and special characters) in order to increase the
security of your product. And we recommend you reset your password regularly,
especially in the high security system, reseng the password monthly or weekly can
beer protect your product.
4.1.2 Activang via SADP Soware
Purpose:
SADP soware is used for detecng the online device, acvang the device, and reseng the
password.
Get the SADP soware from the supplied disk or the ocial website, and install the SADP
according to the prompts. Follow the steps to acvate the control panel.
Steps:
1. Run the SADP soware to search the online devices.
2. Check the device status from the device list, and select an inacve device.
Fingerprint Access Control Terminal·
·
·
··User Manual
12
3. Create a password and input the password in the password eld, and conrm the password.
STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong
password of your own choosing (using a minimum of 8 characters, including upper case
leers, lower case leers, numbers, and special characters) in order to increase the
security of your product. And we recommend you reset your password regularly,
especially in the high security system, reseng the password monthly or weekly can
beer protect your product.
4. Click Acvate to save the password.
5. Check the acvated device. You can change the device IP address to the same network
segment with your computer by either modifying the IP address manually or checking the
checkbox of Enable DHCP.
Fingerprint Access Control Terminal·
·
·
··User Manual
13
6. Input the password and click the button to acvate your IP address modicaon. Modify
4.1.3 Activa via Client Soware ng
Purpose:
The client soware is versale video management soware for mulple kinds of devices.
Get the client soware from the supplied disk or the ocial website, and install the soware
according to the prompts. Follow the steps to acvate the control panel.
Steps:
1. Run the client soware and the control panel of the soware pops up, as shown in the gure
below.
Fingerprint Access Control Terminal·
·
·
··User Manual
14
2. Click Device Management to enter the Device Management interface.
3. Check the device status from the device list, and select an inacve device.
4. Check the device status from the device list, and select an inacve device.
5. Click the Activate buon to pop up the Acvaon interface
6. In the pop-up window, create a password in the password eld, and conrm the password.
STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong
password of your own choosing (using a minimum of 8 characters, including upper
case leers, lower case leers, numbers, and special characters) in order to increase
the security of your product. And we recommend you reset your password regularly,
especially in the high security system, reseng the password monthly or weekly can
beer protect your product.
Fingerprint Access Control Terminal·
·
·
··User Manual
15
7. Click button to start activation. OK
8. Click the Modify Netinfor button to pop up the Network Parameter Modification interface.
9. Change the device IP address to the same network segment with your computer by either
modifying the IP address manually.
10. Input the password and click the button to save the settings. OK
You will enter the initial interface.
Notes:
In the initial interface, the icons , , , and the upper-right corner represents at
network is online, network is armed, EHome is online, and Wi-Fi is connected respectively. If
there on the first three icons, it represents network is offline, network is not armed, are
and EHome is offline respectively. When the Wi-Fi is not connected, the Wi-Fi icon will have no
color inside.
The picture displayed above is the initial interface. It may vary according to different models: If
the device model contains -1, the interface will not contain the Wi-Fi ico n.
Fingerprint Access Control Terminal·
·
·
··User Manual
16
4.2 Login
Steps:
1. For the first time login, long-press the OK key for 3s and input the device password (the
password for activation) to enter the main interface.
You can manage the user, the department, the shift, the holiday, the shift schedule, the report,
the communication, the system, the time, etc.
If you have configured the admin in the User interface, for different device models, there are
different login methods:
DS-K1T803F, DS-K1T804F, and DS-K1T804F-1
1) Long-press OK key for 3s to enter the Login interface.
2) Move the cursor to select FP, Employee ID & PWD, or Device PWD.
3) Press the OK key.
4) Scan the fingerprint, input the employee ID and the password, or input the device
password to enter the main interface.
DS-K1T803MF/EF, DS-K1T803MF(L), DS-K1T804MF/EF, DS-K1T804MF/EF-1
1) Long-press OK key for 3s to enter the Login interface.
2) Move the cursor to select FP, Card, Employee ID & PWD, or Device PWD.
3) Press the OK key.
4) Scan the fingerprint, input the card No., input the employee ID and the password, or input
the device password to enter the main interface.
Note: For details about entering and operating the input method, see Appendix B Input Method
Operation
4.3 Parameters Configuration
4.3.1 Communication Settings
Purpose:
You can set the network parameters, the Wiegand parameters and the Wi-Fi.
Fingerprint Access Control Terminal·
·
·
··User Manual
17
Note: The picture displayed above is the Communicaon Setngs interface. The models with -1
does not support Wi-Fi funcon. And the Wi-Fi module’s icon will not be displayed in the interface.
Setting Network
You can set the device network parameters, including the IP address, the subnet mask, the gateway
address, and the DHCP.
Steps:
1. Move the cursor to the and press the OK key to enter the Network interface. Network
2. Edit the IP address, the subnet mask, the gateway, and the DHCP.
Note: The device’s IP address and the PC’s should be in the same network segment.
3. Press the ESC key and select Yes to save the parameters.
Fingerprint Access Control Terminal·
·
·
··User Manual
18
Seing Wiegand Parameters
Purpose:
You are able to set the Wiegand Direction (Send/Receive) and the Wiegand mode (Wiegand
26/Wiegand 34).
Steps:
1. Move the cursor to Wiegand, and press the OK key to enter the Wieagand interface.
2. Edit the Wiegand parameters, including the Wiegand direction and the Wiegand mode.
Wiegand Direcon:
If select “Send”, the terminal can connect to the access controller to upload the card No.
bia the Wiegand 26 or the Wiegand 34 mode.
If select “Receive”, the terminal can connect to the Wiegand card readers. No need to
configure the Wiegand mode. The default mode contains Wiegand 26/34 and the
Hikvision private Wiegand protocol.
Wiegand Mode:
Wiegand 26 and Wiegand 34 can be selected. The default Wiegand mode is Wiegand 34.
Fingerprint Access Control Terminal·
·
·
··User Manual
19
Seing Wi-Fi
Purpose:
You can enable the Wi-Fi and configure the Wi-Fi parameter.
Steps:
1. Move the cursor to Wi-Fi, and press the OK key to enter the Wi-Fi interface.
2. Move the cursor to the icon and press the OK key to enable the WLAN.
3. Select a network and press the OK key to enter the Wi-Fi Setting interface.
4. Input the Wi-Fi password, and configure the IP mode the IP address, the subnet mask and the
gateway.
Note: The password supports numbers, uppercase letters, lowercase letters and symbols.
5. Press the ESC key and select Yes to save the parameters and exit the interface.
4.3.2 System Setngs
Purpose:
Fingerprint Access Control Terminal·
·
·
··User Manual
20
You are able to set the system parameters, manage the data, restore default parameters and
upgrade the device.
Seing System Parameters
Purpose:
Set the system parameters, including the device time format, the keypad audio, the voice prompt,
the voice volume, the sleeping, the attendance repeating time interval, the attendance record over
threshold prompt, the secure door control panel and the record delete.
Time Format:
MM/DD/YYYY MM.DD.YYYY - -YYYY DD/MM/YYY、 、DD MM 、
DD.MM.YYYY YYYYMMDD YYYY- - YYYY/MM/DD、 、 MM DD、
YYYY.MM.DD and MM- -YYYY are available.DD
Keypad Sound:
Move the cursor to or and press the OK key to enable
or disable the keypad sound.
Voice Prompt:
Move the cursor to and press the OK key to enable or
or disable the prompt audio.
Note: The icon represents the keypad sound is enabled. The
icon represents the keypad sound is disabled.
Voice Volume:
High, Medium and low can be selected.
Sleeping:
Set the device sleeping waiting time (Minute). If you set the sleeping
Fingerprint Access Control Terminal·
·
·
··User Manual
21
time to 30min, the device will sleep after 30 min without any
operation.
Note: If you set the sleeping time to 0, the function is disabled.
Time Interval:
Set the attendance repeating time interval (Second) of a person. The
attendance will be invalid, the authentication will be failed, and the
door will not be open if the user swipe the card repeatedly within
the time interval. (Set the authentication mode to Card).
Note: The time interval should be between 0 and 255s.
Attendance
Record Prompt:
If the attendance record memory reaches the configured value, the
system will pop up a prompt to remind you.
Note: The maximum attendance record memory is 150,000.
Secure Door
Control Panel:
Enable/disable the secure door control panel. The terminal connects
to the secure door control panel via the RS-485. And the terminal
will receive the magnetic signals, the door opening button signal and
the input/output alarm signals via the secure door control panel.
When disabling the function, the terminal can control these signals
directly.
Record Delete:
When enabling the function, the terminal will delete the first 3000
attendance records, if the memory reaches the configure threshold,
to save the new attendance records. By default, the function is
enabled. For detailed information, see C.2 Disabling Record Delete.
Managing Data
Purpose:
You are able to delete the storage data of the device, including the event, the attendance data, the
user, and the permission.
Steps:
1. Move the cursor to and press the OK key to enter the Data interface. Data
2. Select a data type and press the OK key to delete.
Delete Event Only:
Delete all recorded events in the device.
Delete Attendance
Delete all attendance data in the device or delete
Fingerprint Access Control Terminal·
·
·
··User Manual
22
Data Only:
attendance data by time.
Delete User Only:
Delete all user data in the device, including the attendance
records.
Clear Permission:
Clear the admin management permission. The admin will
turn to the normal user. The user will not be deleted.
Restoring Settings
Purpose:
You can restore Factory Defaults or Default Settings.
Steps:
1. Move the cursor to Reset and press the OK key to enter the Reset interface.
Figure 1. 1 Reset Interface
2. Select Factory Defaults Default Settings or .
Factory Defaults:
All parameters of the device will restore to the factory
condition.
Default Settings:
All parameters, excluding the communication parameters
and the remote user management, will restore to the factory
condition.
Fingerprint Access Control Terminal·
·
·
··User Manual
23
Upgrading Device
The system can read the upgrading le from the plugged USB disk. Press OK to upgrade the device.
Aer upgrading is completed, the device will reboot automacally.
Notes:
The upgrading le should be put in the root directory.
The upgrading le name should be digicap.dav.
4.3.3 Setng Time
Purpose:
You are able to set the device me and the DST.
Steps:
1. Move the cursor to in the main interface and press the OK key to enter the Time Time
interface.
2. Edit the parameters.
Date:
The displayed date on the device.
Time:
The displayed me on the device.
DST:
Select to enable or disable the DST. When the DST is enabled, you can
set the DST bias me, the start me and the end me.
DST Bias: you can select 30min, 60min, 90min and 120min.
Start: Set the start me of the DST.
End: Set the end me of the DST.
3. Press the ESC key and select Yes to save the sengs and exit the interface.
Note: The available conguraon duraon is from 2000.01.01 to 2037.12.31.
4.4 User Management
Purpose:
You are able to add, edit, delete and search the user.
Fingerprint Access Control Terminal·
·
·
··User Manual
24
Move the cursor to User in the main interface and press the OK key to enter the User List interface.
4.4.1 Adding User
You can add users by eding the ID No., the user name, the card No. You can also scan the user
ngerprint, set the password, the department, the role, the schedule template, the authencaon
mode and the duress card.
Steps:
1. Press the key to enter the New (new user) interface and input the ID No.
Notes:
The ID No. refers to the user attendance serial No.
The ID No. should be between 1 and 99999999 and should not start with 0.
The ID No. can be used for once.
By default, the ID No. will be increased in sequence.
Fingerprint Access Control Terminal·
·
·
··User Manual
25
2. Enter the new user name.
Notes:
For details about using the input method, see Appendix B Input Method Operaon
The user name supports up to 32 characters.
Each user name can be used for once.
3. Enter the card No.
Notes:
The card No. is required.
The card No. can be 0.
The card No. can start with 0 when it contains more than one numbers. E.g. 012345.
The card No. can be used for once.
The device of DS-K1A801F series supports manually entering the card No. The device of
DS-K1A801MF and DS-K1A801EF series supports manually entering card No. and swiping
card to get the card No.
4. Move the cursor to Register and press the OK key scan the ngerprint.
Place the nger on the scanner, rise and conrm your ngerprint by following the voice
prompt.
Notes:
The same ngerprint cannot be repeatedly registered.
The same ID No. supports adding up to 10 ngerprints.
The device supports the opcal ngerprint recording.
You can also scan the ngerprint via the external device and apply the ngerprint to the
device by the client soware. (Device with the model of DS-K1T803MF(L) only supports
collecng or applying ngerprint pictures locally.)
For detailed informaon about scanning the ngerprint, see Appendix A Tips for Scanning
Fingerprint.
Fingerprint Access Control Terminal·
·
·
··User Manual
26
5. Move the cursor to and press the OK key to edit the user password. Set
1) Enter the password and conrm the password in the Set Password interface.
2) Press the ESC key and select Yes to save the password.
Note: Up to 8 numbers can be entered.
6. Move the cursor to and press the OK key to select a department. Select
Figure 1. 2 Select Department Interface
Note: For detailed informaon about eding the department, see Secon 4.6.1 Conguring
Department.
Fingerprint Access Control Terminal·
·
·
··User Manual
27
7. Move the cursor and press the OK key to select the user role.
Admin: The admin has all permissions to operate the device.
User: The user can check attendance in the inial interface.
Notes:
All people can enter the main interface to operate if there is no Admin congured.
Aer conguring the admin, you have to authorize the admin ID to enter the main
interface.
You can user the USB interface to import the user informaon. For details, see Imporng
Data.
8. Move the cursor to Select Template and press the OK key to enter the Select Template
interface. Select a template.
Notes:
For details about conguring Schedule Template, see Secon 4.5.4 Conguring Schedule
Template.
By default, the terminal selects Template 1.
9. Move the cursor to select an authorize mode.
You can select Card/Fingerprint, Card, Fingerprint, Card &Password, Card and Fingerprint,
Fingerprint &Password, Card & Fingerprint & Password, Card/Password (The password here
refers to the card ID No. and the user password.), and Controller.
Note: By default, the terminal selects Controller. Congure the Terminal Authencaon in the
Access Control System module. For details, see Secon 4.5.1 Congure Access Control
Parameters.
10. Select to enable/disable Duress Card funcon. When the funcon is enabled, the user linked
card will be a duress card. You are able to use the duress card to open the door and report a
duress event.
11. Press the ESC key and select Yes to save the sengs and exit the interface.
Fingerprint Access Control Terminal·
·
·
··User Manual
28
4.4.2 Managing User
Searching User
Purpose:
Enter the user ID No. or the user name to search the target user.
Steps:
1. Enter the user ID or the user name in the searching bar of the user list interface,
2. Press the OK key to search.
Eding the User
Steps:
1. Select a target user in the user list and press the OK key.
2. Select Edit User in the User Conguraon interface.
3. Follow Secon 4.4.1 Adding User to edit the user informaon.
4. Press the ESC key and select Yes to save the sengs and exit the interface.
Note: The user ID No. cannot be edited.
Fingerprint Access Control Terminal·
·
·
··User Manual
29
Deleng the User
Select Delete User and press the OK key to delete the target user and its informaon.
Or press Delete Password and press the OK key to delete the target user password.
Or press (Fingerprint) and press the OK key to clear the target user ngerprint. Clear FP
Or press and press the OK key to delete the user card No. Clear Card
4.5 Access Control System Configuration
Purpose:
Congure the access control permission, including the access control parameters, the holiday
group, the week plan and the schedule template.
The suggested conguraon ow is as follows:
Access Control
Parameters:
Congure the terminal access control parameters, including the
terminal authencaon, the sub reader authenticaon, the door
magnec status, the lock acon me duration, the door- en op
meout alarm, and the authencaon mes exceeded.
Holiday Group:
Congure the holiday group for the access control function. In the
seng duraon, the door cannot be controlled.
Week Plan:
Congure the week plan for the access control funcon. The door
can be controlled during the congured me.
Schedule Template:
Set the congured week plan and the holiday group. The door
can be controlled in the congured me duraon.
Fingerprint Access Control Terminal·
·
·
··User Manual
30
4.5.1 Congure Access Control Parameters
Steps:
1. Select ACS (Access Control System) in the access control system interface to enter the
parameters seng interface.
2. Edit the parameters.
Terminal
Authencaon:
Congure the terminal authenticaon mode, including
“Card/FP (Fingerprint)”, “Card”, “Fingerprint”, “Card and PW
(Password)”, “Card and FP (Fingerprint)”, “FP (Fingerprint) and
PW (Password)”, “Card and FP (Fingerprint) and PW
(Password)”, and “Card/PW (Password) (The password here
refers to the card ID No. and the user password)”.
Sub Reader
Authencaon:
Congure the sub reader authencaon mode, including
“Card/FP (Fingerprint)”, “Card”, “Fingerprint”, “Card and PW
(Password)”, “Card and FP (Fingerprint)”, “FP (Fingerprint) and
PW (Password)”, “Card and FP (Fingerprint) and PW
(Password)”, and “Card/PW (Password) (The password here
refers to the card ID No. and the user password)”.
Door Magnec:
Congure the door magnec status, including Remain Closed
and Remain Open.
Note: By default, the magnec status is Remain Closed.
Lock Acon
Time:
Congure the acon me aer the door opening. Aer the
acon me, the door will be locked.
Note: Available lock acon me duration is from 1 to 255s.
Door-Open
Timeout Alarm:
Congure the maximum me duraon for door opening. If the
door-open me has exceeded the congured value, it will
trigger an alarm.
Auth Times
Exceeded
Alarm
Congure the maximum mes for authencaon.
Fingerprint Access Control Terminal·
·
·
··User Manual
31
Super
Password:
Set the device super password. Aer saving the sengs, you
can input the super password in the inial interface to access
the door.
3. Press the ESC key and select Yes to save the sengs and exit the interface.
4.5.2 Conguring Holiday Group
Purpose:
Congure the access control system holiday schedule. The door can be open during the holiday.
Adding Holiday Gro up
Steps:
1. Select Holiday and press the OK key to enter the Holiday Group list interface.
2. Press the key to enter the Holiday Group interface.
3. Edit the holiday group name.
4. Select New ACS Holiday to enter the New (New Holiday) interface.
Fingerprint Access Control Terminal·
·
·
··User Manual
32
5. Congure the holiday parameters, including the holiday No. the holiday name, the holiday start
me and the end me and the holiday period for the access control devices.
Notes:
Up to 8 periods can be congured.
Press the ESC key and select Yes to save the parameters and exit the interface.
6. Press the ESC key and select Yes to save the parameters and exit the interface. The congured
holiday group will be displayed in the holiday group list.
Searching Holiday Group
Purpose:
Search the target holiday group by entering the holiday group name.
Steps:
1. Enter the target holiday group name in the searching bar.
2. Press the key to search. OK
Eding and Deleng Holiday Group
Steps:
1. Select a holiday group and select in the Holiday Group Manage conguraon interface. Edit
Or select a holiday group and select Delete in the Holiday Group Manage conguraon
interface.
Termékspecifikációk
| Márka: | Hikvision |
| Kategória: | Beléptető rendszer |
| Modell: | Fingerprint Access Control Terminal |
Szüksége van segítségre?
Ha segítségre van szüksége Hikvision Fingerprint Access Control Terminal, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók Beléptető rendszer Hikvision
1 Április 2025
1 Április 2025
1 Április 2025
1 Április 2025
1 Április 2025
1 Április 2025
1 Április 2025
29 Március 2025
29 Március 2025
28 Március 2025
Útmutatók Beléptető rendszer
- Beléptető rendszer Bosch
- Beléptető rendszer Vimar
- Beléptető rendszer Speco Technologies
- Beléptető rendszer DSC
- Beléptető rendszer Dahua Technology
- Beléptető rendszer Burg Wächter
- Beléptető rendszer Viking
- Beléptető rendszer APC
- Beléptető rendszer Honeywell
- Beléptető rendszer Velleman
- Beléptető rendszer EQ-3
- Beléptető rendszer Delta Dore
- Beléptető rendszer ZKTeco
- Beléptető rendszer Abus
- Beléptető rendszer Chief
- Beléptető rendszer Marmitek
- Beléptető rendszer LiftMaster
- Beléptető rendszer Panduit
- Beléptető rendszer Provision-ISR
- Beléptető rendszer Axis
- Beléptető rendszer Optex
- Beléptető rendszer EverFocus
- Beléptető rendszer ACTi
- Beléptető rendszer Yale
- Beléptető rendszer Eminent
- Beléptető rendszer Techly
- Beléptető rendszer Steren
- Beléptető rendszer GeoVision
- Beléptető rendszer Safescan
- Beléptető rendszer Satel
- Beléptető rendszer EQ3
- Beléptető rendszer ETiger
- Beléptető rendszer ASSA ABLOY
- Beléptető rendszer Suprema
- Beléptető rendszer HID Identity
- Beléptető rendszer Indexa
- Beléptető rendszer ONE Smart Control
- Beléptető rendszer Approx
- Beléptető rendszer Gewiss
- Beléptető rendszer SOREX
- Beléptető rendszer Atlantis Land
Legújabb útmutatók Beléptető rendszer
27 Március 2025
6 Január 2025
1 Január 2025
30 December 2025
22 December 2024
16 December 2024
16 December 2024
16 December 2024
16 December 2024
13 December 2024
