Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Deutschland
+49 711 347-0
www.festo.com
male female
© 2022 all rights reserved to Festo SE & Co. KG
All available documents for the product www.festo.com/ .- sp
8177389
202 -211
[8 ]177391
enclosed sealing Ø 8 - 10,5mm
Ø 10,5 - 13mm
AWG 14 without wire-end ferrule
Cross-sectional area max. 1.50 mwith ferrule
max. 2.50 mwithout ferrule
AWG 16 with wire-end ferrule
Cable Assemblies and Fittings for Industrial
Control and Signal Distribution
Electrical connection 1 M12-L coded, 4 pins + FE
Rated voltage 63 V
Certificates C UL us – Recognized (OL) UL2238- E474609
Technical information
Power supply socket - 4PIN + FE
NECL-L12 5-C2-Q10G
/
NECL-S-L12 5-C2-Q10 G
3Scale drawing and tecnical information
2Assembly instruction
1Applicable documents
Assembly instruction
1. Clamp out screws until bores for single wires
are completely free.
2. Push sleeve, the suitable seal, and the
coble clamp onto the cable part by part.
3. Cut off cable coating.
4. Strip single cores and twist single wires.
5. Insert single wires into the holes and
tighten clamping screws (0,4 m).N
6. Push the sleeve to the contact insert,
press it on and screw it to the contact
insert.
7. Turn on pressing screw.
Contact arrangement (plug-in side)
