Oldal 1/24
For R410A Series
Unitary Ducted Split AC
Air Conditioners
Owner's Manual
Thank you for choosing Air Conditioners, please read this owner’s manual carefully before
operation and retain it for future reference.
Model
Contents
Safety Considerations 1 ...................................................................................
1. Installation of the Wired Controller 2 ............................................................
2. Wiring Terminals of the Wired Controller 2 ...................................................
3. Main Page 3 .................................................................................................
4. Function Setting.........................................................................................3
4.1 “ON/OFF” 3 .............................................................................................
4.2 “System” 4 ................................................................................................
4.3 “Fan” 4 ......................................................................................................
4.4 “▼/▲” (Temperature Adjustment) ..........................................................4
4.5 “SET” (Parameters/Functions View and Setting) ...................................5
4.6 “Enter/Hold” 9 ...........................................................................................
4.7 Lock Function 10 ......................................................................................
4.8 Error Display 10 ........................................................................................
5. Installation Instructions ............................................................................ 11
5.1 Physical Dimension ............................................................................ 11
5.2 Installation Recommendations 12 ...........................................................
5.3 Installation 13 ..........................................................................................
1
Unitary Ducted Split AC
Safety Considerations
Improper installation, adjustment, alteration, service, maintenance, or use can cause explosion,
fire, electrical shock, or other conditions which may cause death, personal injury, or property
damage. Consult a qualied installer, service agency, or your distributor or branch for information or
assistance. The qualied installer or agency must use factory--authorized kits or accessories when
modifying this product. Refer to the individual instructions packaged with the kits or accessories
when installing. Follow all safety codes. Wear safety glasses, protective clothing, and work
gloves. Use quenching cloth for brazing operations. Have re extinguisher available. Read these
instructions thoroughly and follow all warnings or cautions included in literature and attached to
the unit. Consult local building codes and National Electrical Code (NEC) for special requirements.
Recognize safety information. This is the safety--alert symbol .When you see this symbol on the
unit and in instructions or manuals, be alert to the potential for personal injury. Understand these
signal words; DANGER, WARNING, and CAUTION. These words are used with the safety--alert
symbol. DANGER identies the most serious hazards which will result in severe personal injury
or death. WARNING signies hazards which could result in personal injury or death. CAUTION is
used to identify unsafe practices which may result in minor personal injury or product and property
damage. NOTE is used to highlight suggestions which will result in enhanced installation, reliability,
or operation.
WARNING
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury or death.
Before installing, modifying, or servicing system,main electrical disconnect switch must be in
the OFF position. There may be more than 1 disconnect switch. Lock out and tag switch with a
suitable warning label.
This product must not be disposed together with the domestic waste.
This product has to be disposed at an authorized place for recycling of
electrical and electronic appliances.
