Package Contents
1
2
Insert the case connector into
the short tube the tighten the screws
using included Allen key
Fixed clamp
Holder
Holder connector
Lock
Key
Tube connector
Key slot
Insert the tube connector
into the long tube then
tighten the screws
using included Allen key
Sliding clamp
Stylus
Short tube
Holder connector
Long tube
Base connector
Base
3Insert the long tube into
the base connector then
tighten the screws
using included Allen key
Security Kiosk Dual Stand for 7-14 Inch Tablets
support@ctadigital.com
1) Place the stand on a flat surface and orient the holder vertically,
with the fixed end at the bottom and the sliding end on top.
2) Pull back the lock catch at the rear of the holder. Place tablet corner
diagonally into the fixed clamp end, then push sliding end down until it is firmly cradling tablet.
1) Attach cable end to any permanent fixture using loop.
2) With key inside, insert lock end to slot on stand base or back of holder.
3. Turn key and remove from lock to attach cable to stand.
Using the holder
Cable management system
3) Push the lock catch back in, then turn the key to lock in place.
ATTACHED TO BASE
Fixed clamp
Key slot
Sliding clamp
Push sliding clamp
support@ctadigital.com
