Használati útmutató Cougar Immersa Pro Ti

Cougar fejhallgató Immersa Pro Ti

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Cougar Immersa Pro Ti (2 oldal) a fejhallgató kategóriában. Ezt az útmutatót 4 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/2
Ultra-Light Suspended Headband Support Structure
Ultra Lightweight Suspended Leatherlike Headband
Extra-Large (100 mm) Circumaural Leatherlike Ear Pads
Retractable Microphone for Gaming
4 Pole Audio and Microphone Jack (3.5mm)
Control unit with volume control and microphone on/off functionality
How to adjust the microphone
When stretching the headphones before placing them in your head,
please pay attention to avoid stretching them beyond their physical limits
to avoid damaging the product.
Caution
4 pole to dual (microphone + audio) 3 pole adaptor
HEADPHONES
Drivers
Sensitivity at 1KHz
Impedance at 1KHz
Frequency response
Cable Length
Max. Input Power
40mm
20Hz - 20KHz
32Ω +/- 15%
97dB ± 3dB
100mW
2m
The above specifications may vary by country or region
Type
Frequency
Sensitivity at 1KHz
Noise Cancelling
MICROPHONE
100Hz to 10kHz
Impedance 2.2kΩ
-47dB ± 3dB
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan,
Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail: service@cougargaming.com
More information you will find at
cougargaming.com
Compucase Enterprise Co.,Ltd.
All rights reserved.
Made in China
This manual was created by Compucase Enterprise and may not be completely
or partially copied, passed on, distributed or stored without written consent by
Compucase Enterprise.
COUGAR® is a registered brand of Compucase Enterprise Other product and
company names mentioned in this documentation may be brands or
trademarks of their respective owners.
Compucase Enterprise reserves the right to make changes concerning the
contents of the manual and the technical data of the product without
previous announcement.
All ot her reg is tered trad emarks b elo ng
to th eir re sp ect ive compa nies.
DISCLAIMERS
● COUGAR does not authorize or endorse the user of COUGAR products as a
part of, together with, or connected to, life support devices, medical equipment
in general, military equipment, traffic or transportation-related equipment or
disaster prevention systems.
● COUGAR is not liable for any damage, expense, loss, cost, injury or any other
result derived from the use of COUGAR products not specifically for PC
gaming in the compatible operative systems indicated by COUGAR.
● COUGAR is not liable for any damage, expense, loss, cost, injury or any other
result due to use of COUGAR products not in strict accordance with the
instructions provided by COUGAR in the instruction manual.
● Software, instruction manuals, consumables (for example mouse pads, mouse
feet, etc.), boxes or other external packaging are not covered by the warranty.
● For inquiries about the warranty, please contact us at service@cougargaming.com
CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED
● Any fault or damage caused by natural disasters (including storm, fire, flood,
thunder, earthquake, etc).
● Any fault or damage caused by accidental factors and man-made reasons
(including hit, scrape, crash, moving, compression, stain, corrosion, use of
incurred on unsuitable voltage, computer virus, riot, misuse, malicious damage, etc).
● Use in an improper operating environment (including high temperature, high
humidity, water inflow, etc).
● Inability to provide the product warranty card, purchase receipt or invoice to
prove the product is still within the warranty period and the shipping date of
the product is out of warranty.
●
The warranty card or product serial number has been altered or its number is hard to identify.
● The warranty period has expired.
● Any fault or damage caused by non-compliance with regulations stated on
the user manual or improper, rough and careless treatment.
● Any fault or damage caused by use of parts not certified by COUGAR
original manufacturer.
● The problem is caused by improper repair or adjustment by the buyer or any
manufacturer without authorization from COUGAR.
● The product is not acquired from an authorized distributor of the company
or is acquired from illicit sources.
● Paper carton, instruction and other accessories are not warranted.
WARRANTY AGREEMENT
●
If the product has defects in material or manufacture, COUGAR will provide
product repair and replacement service within the warranty period.
●
Our warranty service is based on the date of the invoice or warranty card
(must be affixed with the store stamp).
If you lose the aforementioned evidence, we will apply the original shipping
date of the product as the beginning date of warranty period. The shipping
date will be identified by the product serial number(S/N).
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR IMMERSA Ti gaming headset
Warranty : 1 Year
This warranty gives you specific legal rights. You may also have other rights
granted under local law. These rights may vary.
SINGLE JACK DEVICES
●
Audio: 3.5 mm audio jack.
●
Audio + Microphone: 3.5 mm audio + microphone integrated jack.
Dual Jack Devices (for usage with the audio/mic splitter adapter)
●
Audio + Microphone: Separate 3.5 mm audio and microphone jacks
● Диафрагма с титановым покрытием:
уникальное качество звука
● 40-мм драйвер: высококачественный
стереозвук
●
Ультра-толстые (35 мм) и сверхбольшие
(100 мм) амбушюры с эффектом памяти
● Выдвижной кардиоидный микрофон с
драйвером в 9,7 мм
● Ультралегкий кожаный дизайн
● Автоматические всенаправленные
адаптивные ушные оболочки
● 3х-4х-полюсный адаптер для
дополнительной совместимости
РУССКИЙ
中 文
● 镀钛振膜：绝佳音质表现
● 40mm驱动单元喇叭：优质立体音效
● 35mm极厚与100mm特大记忆棉耳罩
● 9.7cm伸缩式心型指向性麦克风
● 超轻量悬吊式仿皮革头带设计
● 全方位自动角度调整耳罩结构
● 四转三极3.5厘米转接头提升兼容性
● Diafragma Revestido com Titânio:
Qualidade Sonora Única
● Driver 40mm: Som Estéreo de Alta
Qualidade
● Almofadas de Ouvido Ultra-grossas
(35mm) e Extra-Grandes
(100mm) com Espuma com Memória
● Microfone Cardióide Retrátil de 9,7 mm
● Design de Alça de Cabedal Suspenso
Ultra Leve
● Conchas de Orelha Adaptativas
Omnidirecionais Automáticas
● Adaptador de 4 Pólos para 3 Pólos para
Compatibilidade Extra
PORTUGUÊS
● Audio immersivo 7.1 virtual surround
360°
● Driver al neodimio da 50 mm
● Padiglioni extra-large da 100 mm per
maggiore isolamento e comfort
● Supporto cougar uix: comando
equalizzatore e retroilluminazione
● Retroilluminazione rgb a 16,8 milioni
di colori con 5 diverse modalità
● tecnologia di cancellazione del rumore
ITALIANO
ESPAÑOL
●
Diafragma Recubierto de Titanio:
Sonido Único
●
Altavoz de 40mm: Sonido Estéreo de
Alta Calidad
●
Almohadillas Auriculares Extragruesas
(35mm) y Extragrandes (100mm) con
Espuma Viscoelástica
●
Micrófono Cardioide Retraíble de 9,7mm
●
Diseño Ultraligero con Diadema
Suspendida y Banda de Cuero Sintético
●
Copas con Adaptación Omnidireccional
Automática
●
Adaptador de 4 Polos a 3 Polos para
Mayor Compatibilidad
● 티타늄 코팅 진동판 : 독특한 사운드 품질
● 40mm 드라이버 : 고품질 스테레오 사운드
● 메모리 폼이 달린 초박형 (35mm) 및
초대형 (100mm) 이어 패드
● 9.7mm 개폐식 단일 지향성 마이크
● 초경량 가죽 헤드밴드 디자인
● 무지향성(자동) 적응형 헤드
● 호환성을 높인 4 극 - 3 극 어댑터
日本語
● チタンのコーティングを施したダイヤフラム:
はっきりとしたオーディオを再生します
● 40mmドライバ：高品質のステレオサウンド
● 厚くて（35mm）、大型（100mm）
のメモリフォームイヤーパッド
● 9.7mm伸縮式カーディオイド指向性マイク
● 超軽量且つ革のような素材を使用
したサスペンドヘッドバンドデザイン
● 無指向性アダプティブイヤーシェル
● マルチプラットフォーム対応：4極→3極変換
アダプタ付きの3.5mmコネクタ
FRANÇAIS
● Diaphragme revêtu de titane : Qualité
sonore unique
● Haut-parleur 40 mm : Son stéréo de
haute qualité
● Coussinets dʼoreilles ultra-épais
(35 mm) et de très grandes dimensions
(100 mm) avec mousse à mémoire de forme
● Micro cardioïde rétractable 9,7 mm
●
Arceau suspendu ultra léger imitation cuir
● Coques dʼoreilles adaptatives
omnidirectionnelles automatiques
● Adaptateur 4 pôles vers 3 pôles pour
une compatibilité supplémentaire
HUNGARIAN
● Titánium bevonatú kettős membrán:
egyedi hangminőség
● 40 mm-es meghajtó: kiváló minőségű
sztereó hangzás
● Rendkívül vékony (35 mm-es) és
rendkívül nagy (100 mm-es) fülpárna
memóriahabbal
● 9,7 mm-es visszahúzható kardioid
mikrofon
● Rendkívül könnyű, felfüggesztett, bőr
hatású fejpánt
●
Automatikus, egyirányú, adaptív fülkagyló
● 4 és 3 pólusú adapter a fokozott
kompatibilitáshoz
POLISH
● Membrana pokryta tytanem:
wyjątkowa jakość dźwięku
●
40mm Driver: High-quality Stereo Sound
● Grube (35 mm) I duże (100 mm) gąbki
uszne z efektem pamięci
● Składany mikrofon kardioidalny 9,7 mm
● Ultralekki pałąk pokryty ekoskórą
● Automatyczne dookólne adaptacyjne
nauszniki
● Przejściówka 4-biegunowa do
3-biegunowej zapewnia zgodność
●
Titanium-Coated Diaphragm: Unique
Sound Quality
●
40mm Driver: High-quality Stereo Sound
●
Ultra-thick (35mm) and Extra-Large
(100mm) Ear Pads with Memory Foam
●
9.7mm Retractable Cardioid Microphone
●
Ultra Lightweight Suspended
Leatherlike Headband Design
●
Automatic Omni-Directional Adaptive
Ear Shells
●
4 Pole to 3 Pole Adapter for Extra
Compatibility
ENGLISH
●
Titanbeschichtete Membran:
Einzigartige Klangqualität
●
40-mm-Treiber: Hochwertiger
Stereoklang
●
Extrem dicke (35 mm) und extrem
große (100 mm) Ohrpolster mit
Memory Foam
●
9,7 mm langes ausziehbares
Nierenmikrofon
●
Extrem leichtes aufgehängtes
lederartiges Bügeldesign
●
Automatische omnidirektionale adaptive
Ohrmuscheln
●
4-Pol-zu-3-Pol-Adapter für zusätzliche
Kompatibilität
DEUTSCH
COUGAR IMMERSA Ti Gaming Headset User Manual
4 to dual (microphone + audio) 3 pole adaptor
Warning! In order to
avoid permanent hearing
damage, please always
use your headset at safe
volume levels. Exposure
to high sound levels for
extended periods of time
may cause permanent
hearing damage and
even loss.
год и месяц изготовления продукции указаны в серийном номере
продукта. (существует 2 способа определения даты изготовления,
оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые
две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был 1702
произведен в феврале 2017 года.
После S/N: если указаны буквы, то две буквы представляют
цифры из таблицы ниже, и означают год,
последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был AG02
произведен в феврале 2017 года.
● Например,
AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
1 3 4 5 6 8 9 02 7
A
B

Termékspecifikációk

Márka: Cougar
Kategória: fejhallgató
Modell: Immersa Pro Ti

Szüksége van segítségre?

Ha segítségre van szüksége Cougar Immersa Pro Ti, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek


Útmutatók fejhallgató Cougar

Cougar

Cougar Immersa Essential Útmutató

19 Augusztus 2024
Cougar

Cougar Immersa Pro Útmutató

19 Augusztus 2024
Cougar

Cougar Phontum Pro Prix Útmutató

19 Augusztus 2024
Cougar

Cougar Phontum Essential Útmutató

19 Augusztus 2024
Cougar

Cougar Omnes Essential Útmutató

18 Augusztus 2024
Cougar

Cougar Havoc BT Útmutató

18 Augusztus 2024
Cougar

Cougar PHONTUM Útmutató

18 Augusztus 2024
Cougar

Cougar HX330 Útmutató

18 Augusztus 2024
Cougar

Cougar Attila Útmutató

18 Augusztus 2024
Cougar

Cougar Immersa Útmutató

18 Augusztus 2024

Útmutatók fejhallgató

Legújabb útmutatók fejhallgató

Steelseries

Steelseries Arctis Nova 5X Útmutató

10 Április 2025
NACON

NACON RIG 900 MAX HX Útmutató

9 Április 2025
Meze Audio

Meze Audio POET Útmutató

9 Április 2025
Sennheiser

Sennheiser CX 5.00G Útmutató

8 Április 2025
Anchor Audio

Anchor Audio PRO-540/1D3S Útmutató

6 Április 2025
Trust

Trust Nouna 25277 Útmutató

3 Április 2025
PowerLocus

PowerLocus P2 Útmutató

3 Április 2025
Sennheiser

Sennheiser RS 120-W Útmutató

2 Április 2025
Celly

Celly SHEER Útmutató

2 Április 2025
Behringer

Behringer SD251-CL PRO Útmutató

1 Április 2025
