TL-LD710G K
Rubber base for Sharp Aero
For posts with a more acute
angle, use the rubber base
for Sharp Aero.
OPTION
16°
Always charge the product before use.
Attach the light securely to the seatpost.
* The light can be used even when mounted upside
down.
* Mount the light between 250 mm and 1200 mm
above the ground.
ENG
Copyright© 2017 CATEYE Co., Ltd.
TLLD710GK-171220
1
HOW TO CHARGE
HOW TO USE
1
HOW TO MOUNT
2
3
1
2
1
2
Seatpost
Switch (Indicator)
Press and hold
ON OFF
WARNING!!!
•
Check periodically to ensure that the light unit is
attached securely. Do not use a damaged rubber band.
• Always attention to the remaining battery power
by checking the indicator periodically while using.
CAUTION!
• This light detects deceleration through the use of
acceleration sensor. Please note that activation of
the Kinetic function depends on the degree of
deceleration, the light may not react or the
reaction may be delayed.
• Stop your bicycle to operate the switch.
• Keep the light away from children.
• This unit is not totally waterproof. Please wipe
and dry it completely after using in rain.
Otherwise, it may cause failure.
• If the light unit or parts become dirty with mud,
etc., clean with a soft cloth which is moistened
with mild soap. Never apply paint thinner, benzine
or alcohol; damage will result.
Manual
Before using the light, read this
manual thoroughly and keep it for
future reference.
Light unit USB cable
(MICRO USB)
Rubber band
(Large/Small)
USB cable
To PC or USB battery charger
Charging
Charging is completed
Standard
charging time Approx. 2 h
(USB 2.0)
Switch (Indicator)
Rubber band
LITHIUM-ION BATTERIES
Cautions on recharging
• We recommend using 500+mAh (USB2.0) USB
battery charger.
• Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 5 and 40°C
• Before charging, be sure that no dust or other
foreign objects attach to the USB plug.
•
Do not subject the light to vibrations while charging.
• When your PC is in sleep state, the unit cannot
be charged.
• Once charging is complete, be sure to
disconnect the USB plug.
• Charging time is approximate values, and will
vary depending on the environmental and
usage conditions.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable
battery to deteriorate faster. Do not place the
light inside a vehicle or near a heater.
• If the illumination time is significantly reduced
even after proper charging, the rechargeable
battery may be nearing the end of its service
life. Dispose of the battery as described in
“Cautions for dispose”.
Cautions on storage
Cool and dry storage is recommended.
For long period storage, it is important to charge
the battery 30 minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove the
internal rechargeable battery and dispose of it
according to local regulations.
When the remaining battery power is low, the lighting mode
switch turns on. Charge the light as soon as possible.
Caution:
• The light must not be covered.
• If any of LEDs is broken, stop use of the light.
* Illumination times are reference times for when the Kinetic function is not being used.
Kinetic function
When bicycle deceleration is detected while the
light is on, the light will illuminate for approxi-
mately 2.5 seconds in the High mode.
The light will remain on in the High mode as
long as deceleration is detected.
Run time: Approx. 8 h
Constant
High
K 1459
ø
21.5 – 32 mm
2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka 546-0041 Japan
Attn : CATEYE Customer Service Section
Phone : (06)6719-6863
Fax : (06)6719-6033
E-mail : support@cateye.co.jp
URL : http://www.cateye.com
CO.,LTD.
SPARE / OPTIONAL PARTS
Battery : Rechargeable lithium-ion polymer battery
(400 mAh)
Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times :
About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight : 2-59/64” x 1-13/64” x 1-19/64” (74.5 x 30.5
x 33 mm) / 1.13 oz (32 g)
*
The specifications and design are subject to change without notice.
5447010
Rubber band
5342730
USB cable
(MICRO USB)
5447030
Rubber base
5447040
Rubber base for
Sharp Aero
SPECIFICATIONS LIMITED WARRANTY
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials
and workmanship for a period of 2 years from original purchase. If
the product fails to work during normal use, CatEye will repair or
replace the defect at no charge. Service must be performed by
CatEye or an authorized retailer. To return the product, pack it
carefully and enclose the warranty certificate (proof of purchase)
with instruction for repair. Please write or type your name and
address clearly on the warranty certificate. Insurance, handling
and transportation charges to CatEye shall be borne by person
desiring service.
