Oldal 1/2
+
-
TL-AU630-R
Manual
Before using the product, please
thoroughly read this manual and
keep it for future reference.
ENG
Design Pat. Pending
Copyright© 2015 CATEYE Co., Ltd.
TLAU63R-150302 1
HOW TO INSTALL BATTERY
1
(SP-11) x 1
Light unit FlexTight™ bracket Dial AA dry-cell battery
HOW TO MOUNT
2
Rubber gasket
FlexTight™ bracket
1
1
ø
12 – 32 mm
Lever
44
or
Attach securely in the mounting position.
Lens
Rubber
gasket
Slot
Close the lens with the slot facing to
the body slot.
Coin
AA (LR6) x 1
Dial
2
2
3
3
23
AUTOMATIC LIGHTING TAIL-
LIGHT CHARACTERISTICS
• The light automatically turns on when
the sensor detects light or vibrations
during nighttime riding.
• The light also remains on for approxi-
mately 50 seconds after the bicycle
comes to a complete stop, which
provides safety when waiting for a
traffic signal to change and in similar
situations.
PRECAUTIONS ON USE
• Check periodically to ensure that the
light unit is attached securely.
• Stop your bicycle to operate the switch.
• Keep the light away from children.
• This unit is not totally waterproof.
Please wipe and dry it completely after
using in rain. Otherwise, it may cause
failure.
• If the light unit or parts become dirty
with mud, etc., clean with a soft cloth
which is moistened with mild soap.
Never apply paint thinner, benzine or
alcohol; damage will result.
PRECAUTIONS WHEN REPLAC-
ING THE BATTERY
• Do not press the switch when removing
or installing the lens or batteries.
• Be sure to install batteries in the correct
direction.
• Install the rubber gasket correctly to
maintain waterproof features.
• Remove and store batteries when you
will not use the light for a long period of
time. Otherwise, batteries may leak
liquid, which may result in failure.
INSTALLATION PRECAUTIONS
• Be sure to tighten the dial by hand.
When you tighten it too hard with a tool,
the screw thread may be stripped.
• Check the bracket frequently to be sure
it is properly tightened at all times.
• Round off the cut edge of the bracket
strap to prevent injury.
2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka
546-0041 Japan
Attn: CATEYE Customer Service Section
Phone : (06)6719-6863
Fax : (06)6719-6033
E-mail : support@cateye.co.jp
URL : http://www.cateye.com
[For US Customers]
CATEYE AMERICA, INC.
2825 Wilderness Place Suite 1200, Boulder CO
80301-5494 USA
Phone : 303.443.4595
Toll Free : 800.5.CATEYE
Fax : 303.473.0006
E-mail : service@cateye.com
SPECIFICATIONS
Battery : AA dry-cell battery x 1
Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)
Dimensions/weight : 2-19/32” x 29/32” x 1-11/16”
(66 x 23 x 43 mm) / 1.6 oz
(44 g) (Including batteries)
* The specifications and design are subject to change
without notice.
MAINTENANCE
Frequently wipe the lens clean of dirt. If the lens is
extremely dirty, it will be difficult for light to reach the
light sensor, which may lead to the light turning on
even during the daytime.
LIMITED WARRANTY
2-year Warranty: Light unit only
CatEye products are warranted to be free of defects
from materials and workmanship for a period of 2
years from original purchase. If the product fails to
work during normal use, CatEye will repair or replace
the defect at no charge. Service must be performed
by CatEye or an authorized retailer. To return the
product, pack it carefully and enclose the warranty
certificate (proof of purchase) with instruction for
repair. Please write or type your name and address
clearly on the warranty certificate. Insurance,
handling and transportation charges to CatEye shall
be borne by person desiring service. For UK and
REPUBLIC OF IRELAND consumers, please return to
the place of purchase. This does not affect your
statutory rights.
SPARE/OPTIONAL PARTS
Please register your CatEye product on the website.
http://www.cateye.com/en/support/regist/
5342280
FlexTight™ bracket
(SP-11)
5342410
FlexTight™ bracket
(SP-12-R)
5342460
Clip
(C-2)
5446510
RM-1 bracket
5445620
Rear rack bracket
3980060
SR-2 bracket
(for fi'zi:k
ICS-compatible
saddles)
HOW TO USE
3
Lighting mode switch
Click
ON
OFF
Rapid
Approx. 20 h
Constant
Approx. 3 h
Flash
Approx. 80 h
Press and hold the switch to turn the power on or off.
When the power turns off, the LED flashes three times.
Power mark
Switch
* With the product turned on and the light off, click the button to turn on
the light for 5 seconds.
* The lighting mode will be recorded, and the light will turn on in this
mode the next time as well.
Press and hold
The light automatically turns on or off
when the sensor detects light or
vibrations.
* If the light does not turn on
automatically, the battery is dead.
CO.,LTD.
