Canton Elektronik GmbH + Co. KG
Neugasse 21– 23 · 61276 Weilrod
Art. Nr. 20920 www.canton.de
Deutsch Deutsch
Der AR-400 ist ein von Dolby Laboratories lizensierter Speziallautsprecher,
der für den Einsatz als Deckenreflexionssystem in einem Heimkino Setup mit
Dolby Atmos® Technologie entwickelt wurde. Durch die Reflexion an der
Zimmerdecke werden durch ihn Schallereignisse über dem Hörer abgebildet
und es entsteht der Effekt eines dreidimensionalen Klangbildes.
Außerdem kann der AR-400, unterhalb der Zimmerdecke an der Wand
montiert, auch als hochwertiger Effektlautsprecher (z.B. Front-High) verwen-
det werden. In einem Stereo-Setup wird der AR-400 zum direktstrahlenden
Hauptlautsprecher und kann, in Verbindung mit einem Subwoofer, auch als
Stereo-Satellit eingesetzt werden. Hierbei wird der AR-400, mit dem Hochtö-
ner nach unten und oberhalb der Ohrhöhe hängend, an der Wand montiert.
Verwendung
Bei Verwendung als Deckenreflexionslautsprecher in einem System mit Dolby
Atmos® Technologie positionieren Sie den AR-400 liegend auf ihren Front-
bzw. Rear-Lautsprechern. Dabei muss die Stoffabdeckung nach oben und
die schmale Seite des Gehäuses in Richtung Hörplatz zeigen. Ein optimales
Hörerlebnis stellt sich dann bei einer Deckenhöhe zwischen 2,20 und 3,70
Meter ein. Beachten sie für eine optimale Aufstellung auch die Hinweise der
Dolby Laboratories unter www.dolby.de und lesen Sie für die korrekte Ein-
stellung des Geräte-Setups die Anleitung ihres Steuergerätes.
Durch die im Gehäuse integrierte Halterung kann der AR-400 problemlos,
mit nur einer Schraube, an der Wand montiert werden. Für ein stabiles An-
liegen an der Wand empfehlen wir hier die Verwendung der mitgelieferten
Gerätefüße auf der Rückseite des Lautsprechers.
Aufstellung
Technische Daten
Verwendung: Multifunktions-Lautsprecher
Prinzip: 2-Wege geschlossen
Nenn- / Musikbelastbarkeit: 60 / 100 Watt
Wirkungsgrad: 86 dB
Übertragungsbereich: 50...30.000 Hz
Übergangsfrequenz: 3.200 Hz
Tieftonchassis: 1 x 160 mm, Aluminium (Wave-Sicke)
Hochtonchassis: 1 x 25 mm, Gewebe
Besonderheiten: Dolby Atmos® lizensiert
Integrierte Wandhalterung
Impedanz: 4...8 Ohm
Abmessungen (BxHxT): 17 x 26 x 14,5 cm
Gewicht: 3,6 kg
Kartoninhalt: Canton AR - 400 (Paar)
Gerätefüße
Stoffabdeckung
Bedienungsanleitung
In Lizenz von Dolby Laboratories gefertigt. Dolby, Dolby Atmos und das
Doppel-D-Symbol sind Warenzeichen von Dolby Laboratories.
Canton Elektronik GmbH + Co. KG
Neugasse 21– 23 · 61276 Weilrod
Art. Nr. 20920 www.canton.de
English English
The AR-400 is a specialist loudspeaker licensed by Dolby Laboratories and
developed for use as a ceiling reflection system in a home cinema setup with
Dolby Atmos® technology. The reflection off the ceiling creates sound events
above the listener to produce the effect of a three-dimensional sound.
In addition, the AR-400, mounted on the wall beneath the ceiling, can also
be used as a high quality sound effect speaker (e.g. a front high speaker). In
a stereo setup the AR-400 acts as a direct main speaker and can be used in
connection with a subwoofer as a stereo satellite. In this case the AR-400 is
mounted on the wall above ear height with the tweeter facing down.
Application:
To use the AR-400 as a ceiling reflection speaker in a system with Dolby
Atmos® technology simply position it on your front resp. rear speakers. The
fabric cover must point upwards and the narrow side of the cabinet must
point in the direction of the listener. The optimal sound experience is created
with a ceiling height of between 2.20 and 3.70 metres. For the perfect setup
please refer to the instructions of Dolby Laboratories at www.dolby.de and
read the instructions of your control unit to ensure the correct setup of the
device.
The bracket built into the cabinet makes it easy to mount the AR-400 on the
wall with a single screw. For stable wall installation we recommend that the
Setup:
Technical Data:
Type: Multifunction-speaker
Principle: 2-way closed
Nom. /Music power handling: 60 / 100 watts
SPL (1 watt / 1 m): 86 dB
Frequency response: 50...30.000 Hz
Crossover frequency: 3.200 Hz
Woofer: 1 x 160 mm (6“), aluminium (Wavesurround)
Tweeter: 1 x 25 mm (1“), fabric
Special Features: Dolby Atmos® technology
Integrated wallmount
Impedance: 4...8 ohms
Dimensions (WxHxD): 17 x 26 x 14.5 cm
6.7“ x 10.2“ x 5.7“
Weight: 3.6 kg
Carton content: Canton AR-400 (Pair)
Equipment feet
Fabric grill
Manual
Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos,
and the “double-D“ symbol are trademarks of Dolby Laboratories.
