Diese Scheinwerfer können
auch mit größerem Sockel
(siehe Abbildung) ausge-
stattet sein. Es handelt sich
um die Modelle
„Typ 170N2",
„Typ 170N2Di",
„Typ 1702Di" sowie
„Typ 170SN2" und
„Typ 170SN2Di"
(kleine äußerliche Ände-
rungen in der Bauform vor-
behalten).
„LUMOTEC senso",
Typ 170SN2,
und „LUMOTEC
senso plus",
Typ 170SN2Di,
mit Sensor und
3fach-Schalter für Naben-
dynamos.
Auch dieser Scheinwerfer ist mit
einem doppeladrigen, innenmon-
tiertem Kabel ausgestattet, das
unbedingt zum Anschluss an den
Dynamo verwendet werden muss!
(Weitere Hinweise siehe „LUMO-
TEC N".) Bei Einsatz eines (stän-
dig mitlaufenden) Nabendyna-
mos schaltet sich bei Dämme-
rungsbeginn und Dunkelheit die
komplette Fahrradlichtanlage
automatisch ein.
Das Rücklicht ist an den Steckkon-
takten des Scheinwerfers ange-
schlossen. Der Hell-Dunkel-Sensor
(S) ist im Scheinwerfersockel inte-
griert, und zwar neben dem drei-
stufigen Schalter (L), der folgen-
de Funktionen besitzt:
Stellung „1": In dieser Stellung
ist die Fahrradlicht-
anlage elektrisch
an den Naben-
dynamo angekop-
pelt und leuchtet
während der Fahrt
ständig - auch bei
Tage.
Stellung „0": Die Fahrradlicht-
anlage ist vom
Nabendynamo
getrennt und leuch-
tet - auch bei
Dunkelheit - nicht.
Stellung „S": Jetzt ist der Sensor
des Scheinwerfers
aktiviert.
Bei beginnender
Dämmerung und
bei Dunkelheit
schalten sich
Scheinwefer und
Rücklicht auto-
matisch ein.
Der Scheinwerfer „LUMOTEC
senso plus" besitzt unsere bekan-
nte elektronische Standlichtfunk-
tion, die - wie unter „LUMOTEC
plus" beschrieben - funktioniert.
These headlamps are also
available with a larger
base (as shown),
i.e. options
‘Typ 170N2’,
‘Typ 170N2Di’,
‘Typ 1702Di’ as well as
‘Typ 170SN2’ and
‘Typ 170SN2Di’
(minor exterior design
modifications reserved).
‘LUMOTEC senso’,
Typ 170SN2,
and ‘LUMOTEC
senso plus’,
Typ 170SN2Di,
with sensor and 3-position
switch for hub dynamos.
This headlamp, too, is equipped
with a twin-wire internal cable
that is absolutely required for
connection to the dynamo! (For
further information refer to
‘LUMOTEC N’.) When using a
(continuously running) hub dyna-
mo, the complete bicycle lighting
system is switched on automati-
cally in twilight and in the dark.
The rear light is connected to the
plug contacts of the headlamp.
The light-dark sensor (S) is inte-
grated in the headlamp base next
to the three-position switch (L)
which features the following func-
tions:
Position „1”: In this position, the
bicycle lighting
system is electrical-
ly coupled to the
hub dynamo and
shining permanent-
ly while riding -
also in daylight.
Position „0”: The bicycle lighting
system is separa-
ted from the hub
dynamo and inac-
tive - also in the
dark.
Position „S”: The headlamp
sensor has been
activated.
When twilight sets
in as well as in the
dark, both the
headlamp and
rear light are swit-
ched on automati-
cally.
The ‘LUMOTEC senso plus’ head-
lamp includes our well-known
electronic standlight feature.
Refer to the ‘LUMOTEC plus’
product description for more
detailed information on its func-
tion.
Ces phares peuvent aussi
être équipés d’un socle plus
grand (voir l’illustration).
Il s’agit des modèles
«type 170N2»,
«type 170N2Di»,
«type 1702Di» ainsi que
«type 170SN2» et
«type 170SN2Di»
(sous réserve de légères
modifications du design
extérieur de la construc-
tion).
«LUMOTEC senso»,
type 170SN2,
et «LUMOTEC
senso plus»,
type 170SN2Di,
munis de capteur et d’un
commutateur à 3 positions
pour dynamos dans le
moyeu.
Ce phare également est équipé
d’un câble double fil, monté à l’in-
térieur, qui doit obligatoirement
être utilisé pour le raccordement à
la dynamo ! (autres informations,
voir «LUMOTEC N».)
En cas d’utilisation d’une dynamo
dans le moyeu (connectée en
permanence), le système d’éclai-
rage complet du cycle se connec
te automatiquement dans le clair-
obscur et dans l’obscurité. Le feu
arrière est raccordé aux contacts
à fiches du phare. Le capteur de
clair-obscur (S) est intégré dans
l’embase du phare; le commuta-
teur à 3 paliers (L) offre les fonc-
tions suivantes :
Position «1»: Le système d’éclai-
rage est connecté
électriquement à la
dynamo dans le
moyeu, et demeure
allumé en perma-
nence pendant le
roulement, même
de jour.
Position «0»: Le système d’éclai-
rage du cycle est
déconnecté de la
dynamo dans le
moyeu et n’est pas
allumé, même dans
l’obscurité.
Position «S»: Maintenant, le cap-
teur du phare est
activé. Le phare et
le feu arrière s’allu-
ment automatique-
ment dans le clair-
obscur et dès le
début de l’obscuri-
té.
Le phare «LUMOTEC senso plus»
est équipé de notre feu de
position électronique éprouvé, qui
fonctionne comme décrit sous
«LUMOTEC plus».
Deze koplampen kunnen
ook van een grotere beve-
stiging (zie afbeelding)
voorzien zijn.
Dit betreft de modellen
„Type 170N2”,
„Type 170N2Di”,
„Type 1702Di” alsmede
„Type 170SN2” en
„Type 170SN2Di”
(onder voorbehoud van
geringe uitwendige wijzi-
gingen aan de constructie).
“LUMOTEC senso”,
Type 170SN2,
en “LUMOTEC
senso plus”,
Type 170SN2Di,
met sensor en 3-standen-
schakelaar voor naaf-
dynamo’s.
Ook deze koplamp is van een
tweeaderige, inwendig gemon-
teerde draad voorzien, die in
ieder geval voor het aansluiten
op de dynamo moet worden
gebruikt! (Voor verdere opmer-
kingen worden verwezen naar
„LUMOTEC N”.)
Bij gebruik van een (permanent
meedraaiende) naafdynamo
wordt bij invallen van de scheme-
ring en in de duisternis het com-
plete fietslichtsysteem automa
tisch ingeschakeld. Het achterlicht
is op de stekkercontacten van de
koplamp aangesloten.
De licht/donker-sensor (S) is in de
bevestiging van de koplamp
geÔntegreerd, en wel naast de
3-standen-schakelaar (L), die de
volgende functies heeft:
Stand „1”: In deze stand is
het fietslicht-
systeem elektrisch
met de naaf-
dynamo verbon-
den en brandt tij-
dens het rijden
voortdurend - ook
overdag.
Stand „0”: Het fietslicht-
systeem is van de
naafdynamo elek-
trisch losgekop-
peld en brandt -
ook bij duisternis -
niet.
Stand „S”: Nu is de sensor
van de koplamp
geactiveerd. Bij
het invallen van de
schemering en bij
duisternis worden
de koplamp en het
achterlicht auto-
matisch ingescha-
keld.
De koplamp „LUMOTEC senso
plus” beschikt over onze bekende
elektronische standlichtfunctie.
Masse
Mass
Masse
Massa
Strom
Current
Courant
Stroom
zum Rücklicht
to the rear light
au feu arriére
naar het achterlicht
Doppelkabel
zum Nabendynamo
Twin cable to hub
dynamo
Double câble pour
le dynamo dans le
moyen
Dubbele draad
voor naafdynamo
Schalter · Switch
Commutateur · Schakelnaar
LUMOTEC N2 / plus
1
0
S
LUMOTEC senso / plus
Kennen Sie unsere Fahrrad-
Rücklichter 4D-lite plus,
Toplight plus, DToplight
plus Seculite plus,und
die im Stand weiterleuchten?
Ohne Akku, ohne Batterie! -
Fragen Sie Ihren Fachhändler!
BUSCH & MÜLLER also
manufacture the bicycle rear lights
“4D-lite plus”, “Toplight
plus”, “DToplight plus” and
“Seculite plus”, that keep
on shining even when stationary
without requiring batteries or
accumulators.
Connaissez-vous nos feux arrière
de bicyclette 4D-lite plus,
Toplight plus, DToplight
plus Seculite plus,et
qui éclairent même à l’arrêt?
Sans accu, sans pile! - N’hésitez
pas à consulter votre revendeur
spécialisé!
Kent u onze achterlichten de
4D-lite plus, Toplight plus,
DToplight plus en de
Seculite plus, die bij stilstand
blijven branden? Zonder accu,
zonder batterij. - Voor informatie
kunt u zich wenden tot uw fiets-
sepcialist.
BITTE BEACHTEN:BITTE BEACHTEN:BITTE BEACHTEN:BITTE BEACHTEN:
Der Scheinwerfer ist ausschließlich mit dem mitgelieferten Halter mittig an der
Gabelkrone eines Fahrrads zu befestigen. Vor jedem Fahrtantritt ist zu
überprüfen, ob der Scheinwerfer sicher und fest an seinem Halter und der
Halter ebenso sicher und fest an der Gabelkrone des Fahrrads sitzt. Nur unter
den vorgenannten Bedingungen gilt der Scheinwerfer als sachgemäß befestigt.
Wir haften nicht für Schäden, die auf eine unsachgemäße Befestigung
zurückzuführen sind.
PLEASE NOTE:
PLEASE NOTE:PLEASE NOTE:
PLEASE NOTE:
The headlight may only be mounted centrically on the bicycle’s fork crown using
the included mounting bracket. Prior to every ride, a secure and sturdy
connection of the headlight to its mounting bracket and of the mounting
bracket to the fork crown must be checked and ensured. Only when the
aforementioned conditions are met, the headlight is considered to be mounted
properly. We are not liable for any damage that may be attributed to improper
mounting.
Termékspecifikációk
Márka: | Busch + Müller |
Kategória: | Megkönnyebbülés |
Modell: | BASIC |
Szüksége van segítségre?
Ha segítségre van szüksége Busch + Müller BASIC, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók Megkönnyebbülés Busch + Müller
30 Augusztus 2024
30 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
29 Augusztus 2024
Útmutatók Megkönnyebbülés
- Megkönnyebbülés Ikea
- Megkönnyebbülés Nedis
- Megkönnyebbülés Milwaukee
- Megkönnyebbülés LG
- Megkönnyebbülés Philips
- Megkönnyebbülés Theben
- Megkönnyebbülés Livarno Lux
- Megkönnyebbülés Makita
- Megkönnyebbülés Auriol
- Megkönnyebbülés HQ
- Megkönnyebbülés TP-Link
- Megkönnyebbülés Emos
- Megkönnyebbülés Geemarc
- Megkönnyebbülés JBL
- Megkönnyebbülés Viessmann
- Megkönnyebbülés Xiaomi
- Megkönnyebbülés GoGen
- Megkönnyebbülés Crivit
- Megkönnyebbülés ORNO
- Megkönnyebbülés Medisana
- Megkönnyebbülés Be Cool
- Megkönnyebbülés Conceptronic
- Megkönnyebbülés Eurolite
- Megkönnyebbülés Intellytech
- Megkönnyebbülés Vivanco
- Megkönnyebbülés Duronic
- Megkönnyebbülés Hama
- Megkönnyebbülés Dyson
- Megkönnyebbülés Knog
- Megkönnyebbülés Westinghouse
- Megkönnyebbülés BeamZ
- Megkönnyebbülés V-TAC
- Megkönnyebbülés COLBOR
- Megkönnyebbülés Omnitronic
- Megkönnyebbülés Toolcraft
- Megkönnyebbülés Klein Tools
- Megkönnyebbülés American DJ
- Megkönnyebbülés Denver
- Megkönnyebbülés Black & Decker
- Megkönnyebbülés Gardena
- Megkönnyebbülés DiO
- Megkönnyebbülés NGS
- Megkönnyebbülés Lenoxx
- Megkönnyebbülés Godox
- Megkönnyebbülés Gembird
- Megkönnyebbülés OK
- Megkönnyebbülés Metabo
- Megkönnyebbülés Osram
- Megkönnyebbülés Behringer
- Megkönnyebbülés Powerfix
- Megkönnyebbülés Biltema
- Megkönnyebbülés Novy
- Megkönnyebbülés Chamberlain
- Megkönnyebbülés Showtec
- Megkönnyebbülés RYOBI
- Megkönnyebbülés Futurelight
- Megkönnyebbülés Chauvet
- Megkönnyebbülés MaxCom
- Megkönnyebbülés Kogan
- Megkönnyebbülés Honeywell
- Megkönnyebbülés Sigma
- Megkönnyebbülés Velleman
- Megkönnyebbülés Media-Tech
- Megkönnyebbülés Tesy
- Megkönnyebbülés Trotec
- Megkönnyebbülés ION
- Megkönnyebbülés Gre
- Megkönnyebbülés Mio
- Megkönnyebbülés Chacon
- Megkönnyebbülés Elro
- Megkönnyebbülés Delta Dore
- Megkönnyebbülés Infinity
- Megkönnyebbülés Trust
- Megkönnyebbülés Konig
- Megkönnyebbülés ARRI
- Megkönnyebbülés GlobalTronics
- Megkönnyebbülés DeWalt
- Megkönnyebbülés Steinel
- Megkönnyebbülés IFM
- Megkönnyebbülés Eheim
- Megkönnyebbülés JMAZ Lighting
- Megkönnyebbülés Corsair
- Megkönnyebbülés Schneider
- Megkönnyebbülés Brandson
- Megkönnyebbülés Stanley
- Megkönnyebbülés Impact
- Megkönnyebbülés Nitecore
- Megkönnyebbülés Cameo
- Megkönnyebbülés Cotech
- Megkönnyebbülés Martin
- Megkönnyebbülés Siig
- Megkönnyebbülés Artecta
- Megkönnyebbülés Kathrein
- Megkönnyebbülés HQ Power
- Megkönnyebbülés Elation
- Megkönnyebbülés Beper
- Megkönnyebbülés Melinera
- Megkönnyebbülés Blizzard
- Megkönnyebbülés Varta
- Megkönnyebbülés Olight
- Megkönnyebbülés Kino Flo
- Megkönnyebbülés Adj
- Megkönnyebbülés OneConcept
- Megkönnyebbülés ILive
- Megkönnyebbülés Nordlux
- Megkönnyebbülés Neewer
- Megkönnyebbülés EasyMaxx
- Megkönnyebbülés Heitronic
- Megkönnyebbülés Lexon
- Megkönnyebbülés Astro
- Megkönnyebbülés XQ-lite
- Megkönnyebbülés Blackburn
- Megkönnyebbülés Kern
- Megkönnyebbülés Smartwares
- Megkönnyebbülés Aqara
- Megkönnyebbülés Fluval
- Megkönnyebbülés Hazet
- Megkönnyebbülés CSL
- Megkönnyebbülés Perfect Christmans
- Megkönnyebbülés Vivitar
- Megkönnyebbülés Lume Cube
- Megkönnyebbülés Fiilex
- Megkönnyebbülés Fenix
- Megkönnyebbülés Digipower
- Megkönnyebbülés Profoto
- Megkönnyebbülés Generac
- Megkönnyebbülés Manfrotto
- Megkönnyebbülés Rosco
- Megkönnyebbülés Ansmann
- Megkönnyebbülés All Solar Lights
- Megkönnyebbülés Reflecta
- Megkönnyebbülés Qazqa
- Megkönnyebbülés Brennenstuhl
- Megkönnyebbülés KonstSmide
- Megkönnyebbülés LivarnoLux
- Megkönnyebbülés Tiger
- Megkönnyebbülés Miomare
- Megkönnyebbülés Eglo
- Megkönnyebbülés Lucide
- Megkönnyebbülés Caliber
- Megkönnyebbülés SilverStone
- Megkönnyebbülés Kichler
- Megkönnyebbülés Anslut
- Megkönnyebbülés Sun Joe
- Megkönnyebbülés Halo
- Megkönnyebbülés Aukey
- Megkönnyebbülés KlikaanKlikuit
- Megkönnyebbülés Maginon
- Megkönnyebbülés Steren
- Megkönnyebbülés Perel
- Megkönnyebbülés Audiosonic
- Megkönnyebbülés Lumie
- Megkönnyebbülés Livarno
- Megkönnyebbülés Watshome
- Megkönnyebbülés Black Diamond
- Megkönnyebbülés In Lite
- Megkönnyebbülés Maul
- Megkönnyebbülés Näve
- Megkönnyebbülés Goobay
- Megkönnyebbülés Massive
- Megkönnyebbülés Yongnuo
- Megkönnyebbülés Gamma
- Megkönnyebbülés Laser
- Megkönnyebbülés Steinhauer
- Megkönnyebbülés QTX
- Megkönnyebbülés Reer
- Megkönnyebbülés Belux
- Megkönnyebbülés EVE
- Megkönnyebbülés Ikan
- Megkönnyebbülés Blumfeldt
- Megkönnyebbülés GVM
- Megkönnyebbülés Jung
- Megkönnyebbülés Harvia
- Megkönnyebbülés Genaray
- Megkönnyebbülés Nanlite
- Megkönnyebbülés Ecomed
- Megkönnyebbülés Ranex
- Megkönnyebbülés Wentronic
- Megkönnyebbülés Peerless
- Megkönnyebbülés Nexxt
- Megkönnyebbülés Bora
- Megkönnyebbülés Ibiza Sound
- Megkönnyebbülés Stairville
- Megkönnyebbülés Litecraft
- Megkönnyebbülés Garden Lights
- Megkönnyebbülés Shada
- Megkönnyebbülés Swisstone
- Megkönnyebbülés Handson
- Megkönnyebbülés Aputure
- Megkönnyebbülés ColorKey
- Megkönnyebbülés KS
- Megkönnyebbülés Dydell
- Megkönnyebbülés Trump Electronics
- Megkönnyebbülés Panzeri
- Megkönnyebbülés Merlin Gerin
- Megkönnyebbülés Botex
- Megkönnyebbülés Unitec
- Megkönnyebbülés Ludeco
- Megkönnyebbülés Paulmann
- Megkönnyebbülés Heirt
- Megkönnyebbülés Kanlux
- Megkönnyebbülés LYYT
- Megkönnyebbülés Wetelux
- Megkönnyebbülés SLV
- Megkönnyebbülés Handy Century
- Megkönnyebbülés Century
- Megkönnyebbülés Esotec
- Megkönnyebbülés Mtx Audio
- Megkönnyebbülés Berger & Schröter
- Megkönnyebbülés Lideka
- Megkönnyebbülés Ibiza Light
- Megkönnyebbülés IXL
- Megkönnyebbülés Fun Generation
- Megkönnyebbülés Karma
- Megkönnyebbülés Pegasi
- Megkönnyebbülés Lightway
- Megkönnyebbülés Wireless Solution
- Megkönnyebbülés NUVO
- Megkönnyebbülés LightZone
- Megkönnyebbülés Varytec
- Megkönnyebbülés Luxform Lighting
- Megkönnyebbülés Canarm
- Megkönnyebbülés GP
- Megkönnyebbülés DistriCover
- Megkönnyebbülés Ledar
- Megkönnyebbülés LightPro
- Megkönnyebbülés FlinQ
- Megkönnyebbülés Obsidian
- Megkönnyebbülés FeinTech
- Megkönnyebbülés Gumax
- Megkönnyebbülés Doughty
- Megkönnyebbülés ActiveJet
- Megkönnyebbülés Enlite
- Megkönnyebbülés Gingko
- Megkönnyebbülés Raya
- Megkönnyebbülés DTS
- Megkönnyebbülés Expolite
- Megkönnyebbülés LSC Smart Connect
- Megkönnyebbülés ETC
- Megkönnyebbülés Meteor
- Megkönnyebbülés Maxim
- Megkönnyebbülés Integral LED
- Megkönnyebbülés Amaran
- Megkönnyebbülés Ideen Welt
- Megkönnyebbülés Casalux
- Megkönnyebbülés Briloner
- Megkönnyebbülés Retlux
- Megkönnyebbülés Adam Hall
- Megkönnyebbülés Hoftronic
- Megkönnyebbülés Musicmate
- Megkönnyebbülés Light4Me
- Megkönnyebbülés Illuminex
- Megkönnyebbülés Sonoff
- Megkönnyebbülés Lirio By Philips
- Megkönnyebbülés Raytec
- Megkönnyebbülés Gewiss
- Megkönnyebbülés Hella Marine
- Megkönnyebbülés Bright Spark
- Megkönnyebbülés Sengled
- Megkönnyebbülés Enttec
- Megkönnyebbülés Ledino
- Megkönnyebbülés Ikelite
- Megkönnyebbülés Sonlux
- Megkönnyebbülés Atmospheres
- Megkönnyebbülés Dainolite
- Megkönnyebbülés DOTLUX
- Megkönnyebbülés Ape Labs
- Megkönnyebbülés Insatech
- Megkönnyebbülés GEV
- Megkönnyebbülés Kinotehnik
- Megkönnyebbülés Litegear
- Megkönnyebbülés DCW
- Megkönnyebbülés HERA
- Megkönnyebbülés BB&S
- Megkönnyebbülés Astera
- Megkönnyebbülés Temde
- Megkönnyebbülés Excello
- Megkönnyebbülés Varaluz
- Megkönnyebbülés Aveo Engineering
- Megkönnyebbülés Prolycht
- Megkönnyebbülés Magmatic
- Megkönnyebbülés DeSisti
- Megkönnyebbülés Cineo
- Megkönnyebbülés Zylight
- Megkönnyebbülés Smith-Victor
- Megkönnyebbülés Light & Motion
- Megkönnyebbülés LUPO
- Megkönnyebbülés Altman
- Megkönnyebbülés EXO
- Megkönnyebbülés Setti+
- Megkönnyebbülés Portman
- Megkönnyebbülés Fotodiox
- Megkönnyebbülés Bearware
- Megkönnyebbülés Litepanels
- Megkönnyebbülés Aplic
- Megkönnyebbülés Rayzr 7
- Megkönnyebbülés Beghelli
- Megkönnyebbülés ET2
- Megkönnyebbülés Quoizel
- Megkönnyebbülés WAC Lighting
- Megkönnyebbülés Golden Lighting
- Megkönnyebbülés Weeylite
- Megkönnyebbülés Crystorama
- Megkönnyebbülés Valerie Objects
- Megkönnyebbülés OttLite
- Megkönnyebbülés Sonneman
- Megkönnyebbülés Zero 88
- Megkönnyebbülés AFX
Legújabb útmutatók Megkönnyebbülés
16 Október 2024
16 Október 2024
15 Október 2024
15 Október 2024
13 Október 2024
12 Október 2024
9 Október 2024
8 Október 2024
8 Október 2024
8 Október 2024
