Outdoor Fireplace

Model No. WAD931SP

Manufactured in China for:

Blue Rhino Global Sourcing, Inc.

Winston-Salem, NC USA

1.800.762.1142, www.bluerhino.com

OWNER’S MANUAL

Table of Contents

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2

Exploded View & Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Tending the Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Extinguishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Inspecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Save these instructions for future reference. If you are assembling this unit for

someone else, give this manual to him or her to read and save for future reference.

WARNING

FOR YOUR SAFETY:

1. Improper installation, adjustment, alteration,

service or maintenance can cause injury or

property damage.

2. Read the installation, operation, and

maintenance instructions thoroughly before

installing or servicing this equipment.

3. Failure to follow these instructions could

result in ﬁre or explosion, which could cause

property damage, personal injury or death.

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only

(outside any enclosure)

Made from 75% Bagasse

(Environmentally Friendly Sugar

Cane Pulp By-product)

Outdoor Fireplace Model No. WAD931SP

DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion

causing damage to property.

WARNING:

This appliance is for outdoor use only, and shall NOT be used in a

building, garage or any other enclosed area.

Do NOT use this outdoor fireplace for indoor heating. TOXIC carbon

monoxide fumes can accumulate and cause asphyxiation.

This outdoor fireplace is NOT for commercial use.

This outdoor fireplace is safety certified for use in the United States and

Canada only. Do not modify for use in any other location. Modification

will result in a safety hazard and will void the warranty.

This outdoor fireplace is NOT to be operated by children.

Do NOT operate, light or use this appliance within ten (10) feet (3.05 m)

of walls, structures or buildings.

Do NOT store or use gasoline or other flammable vapors or liquids

within 25 feet (7.62 m) in the vicinity of this or any other appliance.

Do NOT use in an explosive atmosphere. Keep outdoor fireplace

area clear and free from combustible materials, gasoline and other

flammable liquids.

Apartment Dwellers: Check with management to learn the requirements

and fire codes for using an outdoor fireplace in your apartment complex.

If allowed, use outside on the ground floor with a ten (10) foot (3.05 m)

clearance from walls or rails. Do not use on or under balconies.

Always use in accordance with all applicable local, state and national

codes. Contact your local fire department for details on outdoor burning.

When using this outdoor fireplace, exercise the same precautions you

would with any open fire.

This outdoor fireplace is NOT to be used in or on boats or recreational

vehicles.

Do NOT use this outdoor fireplace under any overhead or near any

unprotected combustible constructions. Avoid using near or under

overhanging trees and shrubs.

Do NOT use this outdoor fireplace without reading the entire “Owner’s

Manual”.

This outdoor fireplace is for use with dry, seasoned hardwood. It will

burn hotter, more completely and create less smoke.

Do NOT burn charcoal briquets, lump charcoal, manufactured logs,

driftwood, trash, leaves, paper, cardboard, plywood, painted, stained or

pressure treated wood. Avoid using softwoods such as pine or cedar

which can throw sparks.

Do NOT use gasoline, kerosene, diesel fuel, lighter fluid or alcohol to

light or relight fires.

Do NOT alter this outdoor fireplace in any manner. Any alteration will

void your warranty.

Do NOT use this outdoor fireplace until it is COMPLETELY assembled and

all parts are securely fastened and tightened.

The use of alcohol, prescription or non-prescription drugs may impair

the consumer’s ability to properly assemble and/or safely operate this

outdoor fireplace.

Do NOT use this outdoor fireplace near automobiles, trucks, vans or

recreational vehicles.

Always use this outdoor fireplace on a hard, level, non-combustible

surface such a concrete, rock or stone. An asphalt or blacktop surface

may not be acceptable for this purpose. Do NOT use on wooden decks.

Do NOT wear flammable or loose clothing when operating this outdoor

fireplace.

Do NOT use in windy conditions.

Do NOT lean over this outdoor fireplace when lighting or while in use.

Do NOT use this outdoor fireplace unless spark guards are securely

in place.

Keep all electrical cords away from a hot fireplace.

All surfaces of this outdoor fireplace are hot when in operation. To avoid

burns, do NOT touch fireplace until it has completely cooled (about 45

minutes) unless you are wearing protective gear (potholders, gloves,

BBQ mittens, hot pads & etc.). Never touch ashes or coals to see if they

are hot.

Do NOT leave a lit outdoor fireplace unattended, especially around

children and pets.

Always empty this outdoor fireplace before each use.

Do NOT attempt to move or store this outdoor fireplace until all ashes

and coals are completely extinguished.

Do NOT remove ashes or coals until they are completely and fully

extinguished and the outdoor fireplace has completely cooled (about

45 minutes).

Do NOT place wood directly into bottom of the outdoor fireplace. Place

wood only on the wood grate provided.

Do NOT overload the fireplace. Do not add additional firewood until the

fire burns down. NOTICE: If any portion of the bowl, lid or spark guards

of this outdoor fireplace are glowing red it is overloaded.

Do NOT place a hot spark guard or hot fireplace tools onto combustible

surfaces such as grass, wooden deck or furniture.

Avoid breathing smoke from the fire and avoid getting it into

your eyes.

This outdoor fireplace should be thoroughly inspected and cleaned on a

regular basis.

After a period of storage and/or non-use, check for signs of damage

and creosote build-up. Do NOT operate until necessary repairs and/or

cleanup are executed.

Do NOT use oven cleaner or abrasive cleaners as they will damage this

product.

Do NOT clean any part of this outdoor fireplace in a self cleaning oven

as it may damage the finish.

Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The

use of any part that is NOT factory authorized can be dangerous and will

void your warranty.

Use heat-resistant gloves or hot pads when contacting handles.

Use long, sturdy fireplace tools when adding or moving logs.

Use protective gloves when assembling this product.

Do not force parts together as this can result in personal injury or

damage to the product.

Deaths, serious injury or damage to property may occur if the above is

not followed exactly.

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Parts List

1Handle 55-09-900

2Spark Guard 55-09-901

3Wood Grate 55-09-902

4Bowl 55-09-903

5Hearth 55-09-915

6Base Support 55-09-909

7Leg (4) 55-09-908

Hardware

ANut M6 Black Nickel Plated 1 pc

BNut M8 Black Nickel Plated 12 pcs

CLock Washer M8 Black Nickel Plated 12 pcs

Exploded View
