17 3061 0100_BEKO_USA/ 13-11-23.(14:53)
Dishwasher
Installation Manual
DIT25401
DDN25401X
DIN25401
DUT25401W
DUT25401X
DUT25401B
DDT25401X
DDT38532X WS
DDN25402X
DUT36522X
DUT36522W
DDT38532XIH
DDT38532X
DIT38532
DDN25402W
DDT38532XIH WS
DIT39434C2
DUT25401XHW
DUT25401WHW
DUT25401BHW
DDT38532XHW
DDT38532XIHHW
DDT39434XC2
DDT39434XIHC2
DIT38532 WS
USA
CONTENTS
INTRODUCTION 1
1. IMPORTANT SAFETY INSTRUCTIONS 1
1.1 INSPECT THE DISHWASHER 2
2. TOOLS WHICH MAY BE NEEDED 3
3. MATERIALS WHICH MAY BE NEEDED 3
4. MATERIALS SUPPLIED 4
5. DISHWASHER SPECIFICATIONS 5
5.1 TECHNICAL FEATURES 7
6. PREPARATIONS 7
6.1 FOAM RUBBER INSTALLATION 7
6.2 ELECTRICAL PREPARATION 7
6.3 STEAM PROTECTION FOIL 8
7. LEVELING 9
7.1 ADJUSTING HEIGHT 9
8. SIDE PLUGS, TRIM STRIPS, CORNER BRACKETS 10
8.1 INSTALLING THE SIDE PLUGS 10
8.2 INSTALLING THE SIDE TRIM STRIPS 10
8.3 PREPARATION FOR INSTALLING MOUNTING BRACKETS 11
9. CONNECTING THE WATER LINE 12
9.1 PREPARING THE WATER CONNECTION 12
9.2. PLACEMENT OF DISHWASHER INTO THE OPENING 13
10. PREPARING THE CUSTOM PANEL 15
10.1 INSTALLING THE CUSTOM PANEL HANDLE 18
10.2 PREPARING THE PRODUCT DOOR 18
10.3 INSTALLING THE CUSTOM PANEL 19
10.4 SECURING THE CUSTOM PANEL 20
11. SECURING TO THE CABINETRY 21
11.1 READJUSTING FOOT LEVELS 21
11.2 ATTACHING THE CORNER BRACKETS 22
11.3 SECURING THE CABINET TO THE COUNTER 23
12. CONNECTING THE DRAIN LINE 24
12.1 CONNECTION INFORMATION 24
12.2 DRAIN HOSE CONNECTION 25
12.3 DRAIN PREPARATION 25
13. FINISHING STEPS 27
13.1 INSTALLING THE TOE KICK BRACKETS 27
13.3 ADJUSTING A WOODEN TOE KICK 31
13.4 ELECTRICAL CONNECTION 32
13.5 GROUNDING INSTRUCTIONS 32
14. INSTALLER CHECKLIST 33
15. SELF HELP HINTS 33
To prevent accidents, which could cause serious injury or death, as well
as machine damage read these instructions before installation and / or
use.
1USA
INTRODUCTION
NOTICE :
Please read this installation manual
and particularly the safety instruction
completely and carefully. They will save
you time and effort and help to ensure
optimum dishwasher performance. Save
these instructions and pass them on to any
future user.
Be sure to observe all listed warnings
and cautions. Look particularly for the
icons with exclamation marks inside. The
information icon also will provide important
references.
WARNING CAUTION
Notice
WARNING:
Indicates a potentially hazardous situation
which, if not avoided, could result in death
or serious injury.
CAUTION:
Indicates a potentially hazardous situation
which, if not avoided, may result in injury.
It may also be used to alert against unsafe
practices.
NOTICE:
Indicates a potentially hazardous situation
which, if not avoided, may result in damage
to the dishwasher, the table-ware, the
equipment or the environment.
1. IMPORTANT SAFETY
INSTRUCTIONS
In addition to these instructions, the
dishwasher shall be installed:
•In accordance with all local codes or, in
absence of a local code,
•In the United States, with the National
Electric Code,
•In Canada, with the Canadian Electric
Code C22.1-latest edition/Provincial
and Municipal codes and/or local
codes.
WARNING
When installing the dishwasher,
follow basic precautions, including
the following:
•Installation and repair should be
performed by a qualified installer.
Work by unqualified persons could be
dangerous and may void the warranty.
NOTICE :
The dishwasher should be installed by an
insured licensed plumber, contractor or
trained installer. Installation performed
by persons other than this could result in
improper installation and property damage.
•Do not operate the appliance if
damaged, malfunctioning, partially
disassembled or if it has missing or
broken parts.
•Also follow the safety instructions of
the user manual.
•To reduce the risk of electric shock,
fire, or injury to persons, the installer
must ensure that the dishwasher is
completely enclosed at the time of
installation.
•Only connect the dishwasher to the
power supply when all installation and
plumbing work is complete.
•If the dishwasher is installed in a
location that experiences freezing
temperatures (e.g. in a vacation home,
cabin, etc.), you must drain all the
water from the dishwasher’s interior.
Water system ruptures that occur as
a result of freezing are not covered by
warranty.
•Dishwasher must be secured to
adjacent cabinetry using the brackets
